Summary of Contents for Sirius Satellite Radio Xact XS034
- Page 1 Sound Pad Portable Boom Box Instruction Manual Model XS034 To activate your Satellite Radio Receiver or for latest news and questions regarding SIRIUS ® Satellite Radio service visit sirius.com or call 1-888-539-SIRIUS (7474). For accessory & product information visit us at www.getxact.com.
- Page 2 KEEPONLISTENING...
- Page 3 ® © 2004 SIRIUS Satellite Radio Inc. "SIRIUS" and the SIRIUS Satellite Radio Inc. To activate your Satellite Radio Receiver or for latest news and questions regarding SIRIUS ® Satellite Radio service visit sirius.com or call 1-888-539-SIRIUS (7474).
-
Page 4: Cautions And Warnings
6. When outdoors, position your Boom Box and antenna where there are no obvious satellite radio signal obstructions such as high terrain, trees, overhangs, etc. - Page 5 SAFETY PRECAUTIONS Danger Be aware of the following precautions to prevent fire and avoid personal injury: 1. To avoid short circuits, never put or leave any metallic objects (coins, tools, etc.) inside the device. 2. If the device emits smoke or strange smells, turn the power off immediately and contact your dealer. 3.
-
Page 6: Table Of Contents
TABLE OF Introduction Product Overview Package Contents Components Guide Boom Box Setup Installing the Satellite Antenna Installing the Power Cable Installing Batteries Antenna Aiming SIRIUS ® Satellite Map Specifications Problem Solving Care and Maintenance Warranty CONTENTS Page 2 Page 2 Page 2 Page 3 Page 5... -
Page 7: Introduction
Radio. Please see these other available accessories below. • Xact Vehicle Kit: • Xact Home Kit: The easiest way to activate your Satellite Radio Receiver is to log on to sirius.com. You may also call 1-888-539-SIRIUS (7474). ® Radio. Model Number XS031... -
Page 8: Components Guide
The Xact Sound Pad Portable Boom Box provides a Power On/Off-Volume control. Headphone Jack: A stereo headphone jack allows you to listen to your Satellite Radio privately. Release Button: Press this button to release and remove the Stream | jockey II Satellite Receiver from the cradle. - Page 9 COMPONENTS Sound Pad Portable Boom Box Battery Door: Remove the door to insert the 6 “D” Batteries not included. Power Jack: Insert the 9v AC adapter in to the jack to power the Boom Box Satellite Antenna Input Jack: Plug the antenna wire in to the jack to obtain satellite signal on your Stream | jockey II Receiver.
-
Page 10: Boom Box Setup
Boom Box To set up your Xact Sound Pad Portable Boom Box Place the Stream | jockey II Satellite Receiver in the cradle as shown so that the guides are lined up with the Boom Box cradle. Then push the receiver down to engage the connectors. The receiver will lock in place. Turn on the power by rotating the VOL control clockwise from the off position. -
Page 11: Installing The Satellite Antenna
Installing the Satellite Antenna Install the Antenna into the Antenna Jack as shown. Installing the Power Cable Install the adapter into the Power Jack as shown. 9v DC JACK... -
Page 12: Installing Batteries
Installing Batteries (optional) Your Boom Box can also be used with 6 D-Cell batteries as shown: 1. Push the battery cover latches forward and remove the battery compartment cover 2. Insert the 6 D-Cell batteries follow the battery polarity as shown; then close the cover. Note: The batteries are bypassed automatically whenever the supplied DC Adapter is plugged into the power jack on the back of the Boom Box. -
Page 13: Antenna Aiming
Antenna Aiming feature found on the Stream | jockey II receiver. To access the Antenna Aiming Feature: Press the button on the Stream | jockey II receiver’s key pad. Press the Antenna Aiming selection and press Upon entering this option, two 10-segment horizontal bar graphs are displayed with a (-) sign to the left and a (+) sign to the right. -
Page 14: Specifications
Frequency Response Signal-to-Noise Ratio Speaker Impedance Headphone Output Impedance Headphone Output Level Headphone Connector Type Power Overall XS034 Dimensions Overall AC adapter Dimensions XS034 Weight 2.5 Watts Rms 1% at 1 Watt 30Hz to 20 KHz >60dB Maximum 3.2Ohms Nominal... -
Page 15: Problem Solving
Check that the Receiver is seated correctly. Check the Power Cable or Batteries. Make sure you have ® disconnected the Power adapter if you wish to use the batteries. Make sure you have contacted SIRIUS activate your Satellite Radio subscription 1-888-539-SIRIUS (7474). When using batteries the system works intermittently Check the batteries and replace if necessary. -
Page 16: Care And Maintenance
P P e e r r i i o o d d i i c c I I n n s s p p e e c c t t i i o o n n The XS034 Boom Box should be inspected periodically for external damage. At least once every 30 days of use, perform the following checks: •... -
Page 17: Warranty
WARRANTY W W a a r r r r a a n n t t y y I I n n f f o o r r m m a a t t i i o o n n X X A A C C T T C C o o m m m m u u n n i i c c a a t t i i o o n n One-Year Limited Warranty This limited warranty sets forth all XACT Communication responsibilities regarding your product. - Page 18 WARRANTY W W h h a a t t T T o o D D o o f f o o r r W W a a r r r r a a n n t t y y S S e e r r v v i i c c e e During the first thirty (30) days, a defective product is eligible for over-the-counter exchange at the retailer from whom it was purchased.
- Page 19 NOTES...
- Page 20 To activate your Satellite Radio Receiver or for latest news and questions regarding SIRIUS ® Satellite Radio service visit sirius.com or call 1-888-539-SIRIUS (7474). Call Toll Free 1-866-466-XACT (9228) or Visit our Website: www.getxact.com...
