- Page 1 SCH2P Sirius Satellite Radio Connect Tuner Installation and User Guide...
- Page 2 Congratulations on the purchase of your new SIRIUS Connect SCH2P Satellite Radio Tuner Your new SCH2P SIRIUS ® Connect Tuner is designed to work with SIRIUS-ready receivers. Consult the SIRIUS website at http://www.sirius.com for model compatibility. What is Sirius Satellite Radio? Over 120 channels of the best entertainment and completely commercial-free music for your car, home or office.
-
Page 3: Table Of Contents
Table of Contents Table of ConTenTS WaRnIng and SafeTy InfoRmaTIon Important Safety Instructions ......4 FCC Warning . -
Page 4: Warning And Safety Information
Warning and Safety Information Important Safety Instructions • Read these instructions. • Keep these instructions. • Heed all warnings. • Follow all instructions. • Do not use this apparatus near water. • Clean only with a dry cloth. • Do not block any of the ventilation openings. Install in accordance with the manufacturer’s instructions. -
Page 5: Fcc Warning
• DISCONNECTING POWER FROM THE DEVICE — The AC power cord provided with the device is used to disconnect the power from the device. Access to the power cord should remain easily accessible. FCC Warning This equipment may generate or use radio frequency energy. Changes or modifications to this equipment may cause harmful interference unless the modifications are expressly approved in this installation and user guide. -
Page 6: Package Contents
Package Contents The following items are included with your purchase of the SCH2P SIRIUS Connect Tuner. Unpack the kit carefully and make sure that everything shown is present. If anything is missing or damaged, or if the kit fails to operate properly, notify your dealer immediately. It is recom- mended that you retain the original carton and packing materials in case you need to ship your kit in the future. - Page 7 audio Cable audio Cable Rack mounting Hardware Rack mounting Hardware Package Contents...
-
Page 8: Controls And Connectors
Controls and Connectors Figure 1 and the table following identify and describe the displays, controls, and connectors of the SCH2P SIRIUS Connect Tuner. STANDBY INDICATOR standby SATELLITE SIGNAL STRENGTH INDICATOR LEFT/RIGHT AUDIO OUTPUT ANTENNA AUDIO OUTPUT Controls and Connectors TERRESTRIAL... - Page 9 Terrestrial signal strength indicator lights Displays the currently tuned channel Channel Used to tune the satellite radio channel Channel Tuning Knob Antenna Connects to the satellite antenna L - Audio - R Left/Right RCA-type analog audio output connectors Opt.
-
Page 10: Installation
Installation It is recommended that prior to starting the installation, you read this installation section com- pletely and then follow the instructions. In addition, consult the manual of the audio device or A/V system to which you will be connecting the tuner to determine the required installation configuration. -
Page 11: Connecting The Ac Power Cord
Connecting the AC Power Cord Connect the AC power cord to the AC power connector at the rear of the tuner, and plug it into a wall outlet. (Refer to Figure 1 on page 8.) Installing the Outdoor Antenna Before installing the outdoor antenna, read this entire section. A successful antenna installation consists of three steps: First, determining a location for the antenna;... - Page 12 Determining a Location for the antenna For correct operation and best reception of the SIRIUS signal, it is important that the outdoor antenna is located in a place where it will have a clear view of the SIRIUS satellites in the sky. Obstructions such as bushes, trees, other homes or buildings, overhangs, soffits, chimneys, gables, dormers, etc., will impair or prevent the antenna from receiving a signal.
- Page 13 If you cannot obtain a clear 360 degree view of the sky, then you must at least have a clear view of the sky in the direction of the SIRIUS satellites, as shown in the map in Figure 5. WEST Use the above map and find the area you are located in (1 to 5).
- Page 14 Choose a mounting location for the antenna which has an unobstructed view of the sky in the direction for your area. For example, suppose you live in Area 2. You determined that your antenna will need to have a clear view of the sky facing North or Northeast. The exact direction is determined by your specific location in Area 2 relative to the X on the map: If you live in Texas, you will need a more North facing clear view of the sky whereas if you live in southern California, you will need a more Northeast facing clear view of the sky.
- Page 15 Once you have determined a possible mounting location for your area, it is recommended that you put the antenna in place temporarily and connect the antenna to your the tuner and verify that your antenna is receiving a good SIRIUS signal. If a good SIRIUS signal is being received, 2 or 3 of the signal strength lights will be lit on the front of the tuner, either SAT or TER, or both.
- Page 16 Remember to avoid blocking the antenna’s view of the sky as described in the previous section by locating the antenna too high under the eaves or soffit of the home or building. (Figure 8) INCORRECT VIEW OF THE SKY IS OBSTRUCTED BY THE SOFFIT AND GUTTER Once you have determined a suitable mounting location, use the mounting bracket as a tem-...
- Page 17 Roof mount When mounting the antenna on the roof of a home or building, mount the antenna as close to the peak of the roof as possible. Remember to avoid blocking the antenna’s view of the sky by locating it where a chimney, dormer, gable, etc., may obstruct the sky view. (Figure 9) The antenna mounting bracket should be oriented in a vertical position as shown in Figure 5, and mounted directly to the soffit or chimney of the building or home using the provided #10 screws.
- Page 18 mast mount The outdoor antenna can be mounted on most any mast or pole which does not exceed 2 inches in diameter using the provided U-bolts and mounting brackets. If you have a satellite TV dish, the outdoor antenna may be mounted on the same mast as the satellite dish, but remember that the dish cannot obstruct the antenna’s view of the sky in the direction which you determined from the map in the previous section.
- Page 19 Slide one of the U-bolts through the holes at the top of the mounting bracket. Then slide one of the mounting brackets over the two legs of the U-bolt. (Figure 12) Next, screw the hex nuts on each leg until they are snug. Do not yet tighten the hex nuts be- figure 11 figure 11 figure 12...
- Page 20 yond finger tight. Repeat this procedure with the other U-bolt. When all the hex nuts are snug, verify that the antenna is facing the correct direction and begin tightening each hex nut with a 3/8” wrench. Turn each hex nut one-half turn and then move to the next hex nut repeating this one-half turn pattern until all the hex nuts are equally tight.
- Page 21 cabLe instaLLation Once the antenna is mounted according to the previous instructions, you can continue with the cable portion of the installation: Using one of the RG-6 cables you purchased separately, slide the rubber boot over the cable connection. Attach the cable to the antenna and slide the rubber boot over the connection to provide a weatherproof seal.
- Page 22 Connect the other RG-6 cable you purchased separately to the oUT1 connector of the Splitter and route and connect the cable to the tuner. (Figure 15) Connect the provided terminator to the unused oUT2 connector on the splitter. (Figure 15) Installation figure 15 figure 15...
-
Page 23: Connecting The Tuner
Connecting the Tuner The tuner can be connected to your audio system using the DIN port on SIRIUS-Ready audio devices, the RS-232 port, or by using the Infrared connector. Each of these options are de- scribed in the following table. The control switch must be set to the correct position, 1, 2, or 3. Control Connector Switch Position... -
Page 24: Subscribing To The Sirius Service
When you have successfully subscribed to the SIRIUS service, and the tuner has been updated with your subscription information, you will be able to tune to all the channels. You are now ready to begin enjoying SIRIUS Satellite Radio’s digital entertainment! Installation... -
Page 25: Operation
Operation Consult the owners manual of your SIRIUS-Ready receiver for operating instructions. You can change channels using the receiver or A/V system to which you connected the tuner, or by using the tuner’s channel change knob. Note that while the channel display on the tuner will always show the currently tuned channel number, the receiver or A/V system connected to the tuner may not properly update its display if the tuner’s channel change knob is used to change channels. -
Page 26: Troubleshooting
Troubleshooting Symptom Tuner does not power The AC power cord is not connected, or the AC outlet into which it is plugged is not working. Check that the AC power cord is connected to the tuner. Try plugging the AC power cord into a different outlet. The satellite antenna is not connected to the tuner. -
Page 28: Specifications
Specifications Operational Frequencies Satellite ..........2322.293/2330.207 MHz Terrestrial . -
Page 29: Copyrights & Trademarks
Copyrights & Trademarks © 2007 Sirius Satellite Radio Inc. All Rights Reserved. ® “SIRIUS”, the SIRIUS dog logo, channel names and logos are trademarks of Sirius Satellite Radio Inc. All Rights Reserved. Hardware, subscription, and activation fee required. For full Terms & Conditions, visit http://sirius.com. -
Page 30: Sirius Id
SIRIUS ID Write down the SIRIUS ID (SID) of your SIRIUS radio in the space provided below. SID: _______________________________________ SIRIUS ID... - Page 31 SIRIUS Customer Service: 1-888-539-7474 customercare@sirius-radio.com SIRIUS Satellite Radio Inc. 1221 Avenue of the Americas New York, NY 10020 1-888-539-7474 http://www.sirius.com...
- Page 32 SIRIUS Satellite Radio Inc. 1221 Avenue of the Americas New York, NY 10020 (800) 869-5590 http://sirius.com SIRIUS SCH2P (091707)
