- Page 1 STB2 Boombox User Guide...
-
Page 2: Box Contents
Box Contents: When you unpack your STB2 Boombox, it should include everything as shown below: Boombox AC Power Adapter Indoor/Outdoor Windowsill Antenna AC Power Cord If anything is missing or damaged, or if any component of the STB2 Boombox fails to operate, notify your SIRIUS dealer immediately. -
Page 3: Safety Precautions
Take the following precautions to keep the Boombox components in proper working order: • Installation must be performed according to this user guide. Sirius Satellite Radio is not responsible for issues arising from installations not performed according to the procedures in this user guide. - Page 4 Boombox Controls & Features Windowsill Antenna Storage Battery Cover Latch 1. Power On/Low Battery Light: This light is 2. Power On/Off Button: Turns the Boombox 3. AUX Button: This button toggles between input 4. Volume Up/Down Buttons (+/–): Increases or 5.
-
Page 5: Installation
Installation AC Power Connection: If you are using the AC power adapter, connect the AC power cord to the AC power adapter first. Then plug the AC power cord into an outlet. Antenna Connection: Plug the windowsill antenna connector into the ANT connector on the rear of the Boombox, pushing firmly until the connector is fully seated. - Page 6 (where the SIRIUS logo is printed) has a clear 360 degree view of the sky. If you cannot obtain a clear 360 degree view of the sky outdoors, or you will be locating the antenna indoors, then you will need to place the antenna in a WEST window (or outdoor location) which has a clear view of the sky in the direction of the satellites, and aim...
- Page 7 located in (1 to 5). Then find the direction in which you need to have a window (or outdoor location) with a clear view of the sky: Area 1: You will need a window/location with a clear view of the sky facing EAST or NORTHEAST or SOUTHEAST Area 2: You will need a window/location with a clear view of the sky facing NORTH or...
-
Page 8: Operation
Operation Once the Boombox has been installed according to the preceding directions, power on the Boombox by pressing the Power On/Off button on the front panel. The light on the front panel of the Boombox should light green to indicate the power is on. If the receiver does not power on at the same time, press the Power On/Off button on the receiver. -
Page 9: Troubleshooting
Troubleshooting PROBLEM Starmate Replay receiver power is off Boombox does not turn on Batteries are not installed, or installed incorrectly Boombox does not operate on When the AC power adapter is connected to the Boombox, the battery operation is disabled batteries Battery level is low Intermittent operation... - Page 10 STB2 Boombox Specifications Nominal Output Power per Channel ... 5 Watts RMS Total Harmonic Distortion (THD) ... 0.3% at 1 Watt Frequency Response ... 30Hz to 20kHz Signal-to-Noise Ratio (S/N) ... >65dB Maximum Headphone Output Impedance ... 32 Ohms Headphone Output Level (Variable) ... 200mV (Maximum) Headphone Connector Type ...
-
Page 11: Warranty Return
12 MONTH LIMITED WARRANTY Sirius Satellite Radio Inc. (the “Company”) warrants to the original retail purchaser of this product that should this product or any part thereof, under normal use and conditions, be proven defective in material or workmanship within 12 months from the date of original purchase, such defect(s) will be repaired or replaced with new or reconditioned product (at the Company’s option) without charge for... - Page 12 SIRIUS Satellite Radio Inc. 1221 Avenue of the Americas New York, NY 10020 1-888-539-7474 www.sirius.com © 2006 SIRIUS Satellite Radio. “SIRIUS” and the SIRIUS dog logo are registered trademarks of Sirius Satellite Radio Inc. STB2 (011806a)
