Samsung SIR-4150 User Manual

Samsung SIR-4150 User Manual

High resolution day & night ir camera
Hide thumbs Also See for SIR-4150:
Table of Contents

Advertisement

Quick Links

SALES NETWORK
SAMSUNG TECHWIN CO., LTD.
•
333-1, Sangdaewon 1-dong, Jungwon-gu, Seongnam-si,
Gyeonggi-do 462-807, Korea
TEL : +82-31-730-8931~3 FAX : +82-31-730-8950
SAMSUNG OPTO-ELECTRONICS UK, LTD.
•
Samsung House, 1000 Hillswood Drive, Hillswood Business
Park Chertsey, Surrey KT16 OPS
TEL : +44-1932-45-5308 FAX : +44-1932-45-5325
www.samsungtechwin.com
www.samsungcctv.com
TIANJIN SAMSUNG OPTO-ELECTRONICS CO., LTD.
•
7 Pingchang Rd, Nankai Dist. Tianjin 300190, P.R China
TEL : +86-22-2761-4724(33821) FAX : +86-22-2761-6514
P/No. : Z6806082001A
VAN 07. 07
High Resolution Day & Night IR Camera SIR-4150
Thank you for purchasing a SAMSUNG CCD CAMERA.
Before attempting to connect or operate this product,
please read these instructions carefully and save this manual for future use.
User's Manual
ENGLISH

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SIR-4150 and is the answer not in the manual?

Questions and answers

Related Manuals for Samsung SIR-4150

Summary of Contents for Samsung SIR-4150

  • Page 1 TEL : +44-1932-45-5308 FAX : +44-1932-45-5325 www.samsungtechwin.com www.samsungcctv.com High Resolution Day & Night IR Camera SIR-4150 Thank you for purchasing a SAMSUNG CCD CAMERA. Before attempting to connect or operate this product, please read these instructions carefully and save this manual for future use.

  • Page 2: Signal System

    • NTSC MODELS • PAL MODELS SIR-4150N SIR-4150P ■ MODEL DESCRIPTION • SIR-4150 X _ SIGNAL SYSTEM • SIGNAL SYSTEM N --> NTSC MODEL P --> PAL MODEL The lightning flash with an arrowhead symbol, within an equilateral triangle is intended to alert the user to the presence of uninsulated “dangerous voltage”...

  • Page 3: Table Of Contents

    Contents Features Warnings & cautions Components and Accessories Overview ■ Front ■ Bottom ■ Back Adjust to lens ■ Ajust to Lens’s ZOOM and Focus Connection ■ Connecting to a monitor ■ Connecting to power ■ RS-485 Communication control COLOR CCD CAMERA User’s Manual Operating Your Camera ■...

  • Page 4: Features

    Features Ultra High Sensitivity Outdoor Visibility range 30M If B/W mode, IR-LED is lighted, 0 Luxes' The built-in high sensitivity COLOR CCD enables a clear image even in 0Lux(B/W, Outdoor visibility range 30 M guarantees is IR-LED ON)or lower illumination. available.
  • Page 5 Precautions Do not install under extreme Do not install in high humidity temperature conditions. environment. Use only under temperature conditions May lower image quality. between -10˚C and +50˚C. Provide good ventilation when using in high temperature conditions. Do not install under unstable Avoid touching the camera lens.

  • Page 6: Components And Accessories

    Components and Accessories 1. High Resolution Day&Night IR Camera SIR-4150 2. CAMERA HOOD 3. HOOD ADAPTOR(2EA) 4. USER’S MANUAL 5. DC 12V/4A ADAPTOR 6. POWER CABLE COLOR CCD CAMERA User’s Manual Overview FRONT Hood Hood adaptor Fixing the hood onto the camera...

  • Page 7: Bottom

    Overview BOTTOM Mounting bracket screw hole Please use the screw hole when fixing the 1/4"-20 UNC (20 THREAD) camera onto the mounting bracket. L:4.5mm±0.2mm (ISO standard), Please use the clamp screw as specified below. or 0.197" (ASA standard) *The mounting bracket can be separated and attached to the top of the camera.

  • Page 8: Adjust To Lens

    Adjust to Lens Adjust to the lens's zoom and focus. 1. Please loosen a front cover fixing screw with picture and separate cover 2. Please unlock the Zoom or Focus lever to release it. 3. Adjust the zoom or focus lever by moving it to WIDE(NEAR)or TELE(FAR) position.

  • Page 9: Connecting To Power

    Installation Connecting to Power The recommended adaptor specification for SIR-4150N/P is DC 12V/4A. Please check the standard power requirement before connecting to power. When the resistance value of copper wire is at [20°C(68°F)] Copper wire size(AWG) #24(0.22mm #22(0.33mm #20(0.52mm Resistance value(Ω/m) 0.078 0.050 0.030...

  • Page 10: Operating Your Camera

    Operating Your Camera Menu SETUP menu LENS • SHUTTER - - - - • • (condition and speed control) WHITE BALANCE control • • BACKLIGHT • • (Backlight compensation) • HIGH AGC (Auto Gain control) NORMAL • • SSNR • •...

  • Page 11: White Bal

    Operating Your Camera 1. Please press the SETUP button. • Settings can now be made. The SETUP menu is displayed on the monitor. SETUP 1.LENS 2.SHUTTER - - - 3.WHITE BAL. 4.BACKLIGHT 5.AGC NORMAL 6.SSNR 7.SENS-UP 8.SPECIAL 9.EXIT 2. Please select any function you wish to activate by using the UP and DOWN buttons.

  • Page 12: Shutter (Condition And Speed Control)

    Operating Your Camera SHUTTER (condition and speed control) Because SIR-4150 uses built-in dc lens, shutter speed is fixed at 1/60 basically. SETUP 1. LENS 2. SHUTTER - - - 3.WHITE BAL. 4.BACKLIGHT 5.AGC NORMAL 6.SSNR - - - - : Shutter speed is fixed at 1/60(1/50) FLK : Please select 'FLK' mode when flickering occurs on the screen, due to an imbalance between illumination and frequency.

  • Page 13: Backlight (Backlight Compensation)

    Operating Your Camera BACKLIGHT (Backlight Compensation) When there is a strong backlight behind the object, clear images of the background as well as the object can still be obtained by using the BACKLIGHT function. 1. Please position the arrow to point to 'BACKLIGHT' on the SETUP menu by using the UP and DOWN buttons.

  • Page 14: Ssnr (Samsung Super Noise Reduction)

    Operating Your Camera SSNR (Samsung Super Noise reduction) The background noise in the low light level decreases automatically as the level of gain changes. 1. Please position the arrow to point to 'SSNR' on the SETUP menu by using the UP and DOWN buttons.
  • Page 15 Operating Your Camera SPECIAL 1. Please position the arrow to point to 'SPECIAL' on the SETUP menu by using the UP and DOWN buttons. 2. Please select the mode you wish to operate by pressing the UP or DOWN button. SPECIAL 10.

  • Page 16: Motion Detection

    Operating Your Camera 5) When a name has been chosen, please select a position for the name display. Please move the cursor onto 'POS' and then press the SETUP button. The name will appear at the top left hand corner. FRONT DOOR to Locate, then SET to Locate, then SET...
  • Page 17 Operating Your Camera • Please adjust the size of the area to be observed by using the UP, DOWN, LEFT or RIGHT button. • Please press the SETUP button to save the changes and complete the setting. Note • There is no ‘MD’ output signal. ‘MD’ is on screen display only words. PRIVACY : Mask privacy area you do not wish to appear on the screen.

  • Page 18: Exit

    Operating Your Camera • SHARPNESS : The outline of the video image becomes cleaner and more distinctive as the level of SHARPNESS increases. If the level goes up excessively, however, it may affect the video image and generate noise. RESET : Returns to the level which was set by the manufacturer for shipment. RETURN : Returns to the SETUP menu.

  • Page 19: Specifications

    Specifications SIR-4150N POWER DC12V±10%, 460mA/ 5 .5W(LED ON) Sensor 1/3 inch, Sony Super HAD CCD Total Pixels 811(H) x 508(V) Effective Pixels 768(H) x 494(V) Scanning System 2:1 Interlace Synchronization Internal Fixed Frequancy H:15.734 KHz, V :59.94 Hz Resolution 520 Lines(Color) / 570 Lines(B/W) Video Output CVBS : 1.0Vp-p/75Ω...
  • Page 20 MEMO...
