Summary of Contents for V-ZUG DWVMR9
- Page 1 Operating instructions DWVMR9 Range hood...
- Page 2 The model number corresponds to the first alphanumerics on the identification plate. These operating instructions apply to: Type Product family Size system DWVMR9 62009 Variations depending on the model are noted in the text. © V-ZUG Ltd, CH-6302 Zug, 2018...
-
Page 3: Table Of Contents
Contents Safety precautions 4 Symbols used............ 4 General safety precautions........ 4 Appliance-specific safety precautions .... 4 Instructions for use.......... 5 Appliance description 7 Appliance description ........... 7 Extraction model ............ 7 Recirculation model .......... 7 Equipment ............... 7 Construction ............ 7 Operating and display elements...... -
Page 4: Safety Precautions
Safety precautions Symbols used Cleaning and user mainten- ance shall not be undertaken Denotes important safety precau- tions. by children without supervi- Failure to observe said precautions sion. can result in injury or in damage to ▪ If an appliance is not the appliance or fittings! equipped with a mains cable Information and precautions that... -
Page 5: Instructions For Use
1 Safety precautions ▪ The extracted air must not be motels and other accommod- fed into a chimney which is ation establishments; in bed used for exhausting fumes and breakfast establishments. from appliances burning gas ▪ Do not operate the appliance or other fuels. - Page 6 1 Safety precautions ▪ Use original spare parts only. Caution: Burns hazard! ▪ Retain these operating instructions for ▪ Do not leave the appliance unattended future reference. when deep-frying on the cooking sur- Note on use face. The cooking oil in the deep-frying ▪...
-
Page 7: Appliance Description
Appliance description Appliance description The appliance is designed for use in the home for extracting cooking fumes and smells from above the cooking surface. The model can be used to extract or recirculate air. Extraction model A fan draws cooking fumes and smells from above the cooking area. The metal grease filters clean the extracted air, which is passed through a connecting pipe fitted with an in- tegrated non-return valve and through the air duct to the outside. -
Page 8: Operating And Display Elements
3 Operating the appliance Operating and display elements Switching off Power level 1 Power level 2 Power level 3 Intensive level Illumination ON/OFF Flashing: Clean grease filter / saturation indicator for filter Flashing: Saturation indicator for activated charcoal filters (recirculation model), de- pending on use: –... -
Page 9: Intensive Level
3 Operating the appliance Intensive level The intensive level can be selected in stand-by mode. ▸ Press the button to switch the intensive level on for five minutes. – The button and the button for the power level that was running when the intens- ive level was started illuminate. -
Page 10: Care And Maintenance
4 Care and maintenance Care and maintenance Cleaning the housing Take care that no water gets into the housing of the appliance! If water gets into the housing, it can cause damage. Do not use abrasive cleaners, scouring pads, steel wool, etc. for cleaning, as they can damage the surface. Remove the screw fuse or switch off the circuit breaker. -
Page 11: Activated Charcoal Filter Display
4 Care and maintenance If no dishwasher is available: ▸ Clean the grease filters in hot water and detergent. ▸ Soak the grease filters in hot water and detergent for about two hours, then clean with a washing-up brush and rinse well with clean water. Installing ▸... -
Page 12: Standard Activated Charcoal Filter
4 Care and maintenance Standard activated charcoal filter Removing the activated charcoal filters ▸ Swing the glass panel 1 up. ▸ Press down the grip 2, swing the grease filter 3 forwards and lift it out of the bracket 4. ▸... -
Page 13: Cleaning The Long-Life Activated Charcoal Filters
4 Care and maintenance ▸ Insert the grease filter 3 into the bracket 4 at the bottom. ▸ Press down the grip 2 and engage the grease filter 3 in the bracket at the top. ▸ Swing the glass panel 1 down. ▸... -
Page 14: Trouble-Shooting
5 Trouble-shooting Trouble-shooting What to do if … … the illumination is not working Possible cause Solution ▪ Fuse or automatic circuit ▸ Replace the fuse. breaker for electrical installa- ▸ Reset the automatic circuit breaker. tions in the home is defect- ive. -
Page 15: Accessories And Spare Parts
6 Accessories and spare parts Accessories and spare parts Please give model number and exact designation when ordering parts. Metal grease filter for extraction and recir- culation model Activated charcoal filter for recirculation model Long-life activated charcoal filter set with plastic receptacle for recirculation model. -
Page 16: Disposal
8 Disposal Disposal Packaging Never allow children to play with packaging material due to the danger of injury or suffocation. Store the packaging material in a safe location or dispose of it in an environmentally-friendly way. Safety Render the appliance unusable to prevent accidents caused by improper use (e.g. through children playing): ▸... -
Page 17: Index
Index Accessories ............15 Recirculation model..........7 Activated charcoal filter ........12 Resetting the filter saturation indicator Activated charcoal filter display ................ 9 Activating............ 11 Deactivating .......... 11 Appliance description ........7 Safety precautions Appliance disposal .......... 16 Appliance-specific .......... 4 Before using for the first time....... 5 Correct use ............ 5 Cleaning... - Page 18 Notes...
-
Page 19: Service & Support
Your repair order Call the free service number 0800 850 850 to contact your nearest V-ZUG service centre. You can arrange an on-site visit by us by phone if you wish. General queries, accessories and service agreement V-ZUG will be happy to help you with any general administrative or technical queries, to accept your orders for accessories and spare parts and to inform you about our pro- gressive service agreements. - Page 20 – Replace standard activated charcoal filters – Clean and replace long-life activated charcoal filters J62009013-R02 V-ZUG Ltd, Industriestrasse 66, CH-6302 Zug Tel. +41 58 767 67 67, Fax +41 58 767 61 61 info@vzug.com, www.vzug.com Service Centre: Tel. 0800 850 850...
