- Page 1 ® G2‐0503N 12 VDC S P ’ M © Copyright 2016 The Bosworth Company Doc M-PR-09-33.111516...
- Page 2 Guzzler G2-0503N SapPuller Pump Exploded View 2M 21 10 10 7E 6B 6B 7D 7G 10 10 1M Doc M-09-33-111516...
- Page 3 Guzzler G2-0503N SapPuller Pump - Exploded View 1G Pump Inlet Flange‐1/2 in smooth 1M Pump Inlet Manifold 2G Pump Outlet Flange‐1/2 in smooth 2M Pump Outlet Manifold 3B Bu on & Stainless Steel Washer 4 Clevis 4B Connec ng Rod 5 Pump Body 6B Intermediate Ring 7D Pump Housing 7E Housing Cover Plate 7G Pump Support Bracket & Leg 10 Coupler Nut (4) & Nylon Sleeve (4) 12 Misc. Hardware (10‐24 Screws & PS-G2 Nuts) (10) (connects 1 pump body to housing) ...
- Page 4 Guzzler G2-0503N SapPuller Pump Assembly & Safety Information Assembling your Guzzler G2-0503N SapPuller Pump Your Guzzler G2‐0503N SapPuller pump ships with the outlet manifold and motor support leg disconnected from and packed separately in the box with the pump. To assemble your pump, simply attach the outlet manifold to the twin pump bodies by slipping the manifold elbow and “T”...
-
Page 5: Installation And Operating Information
Installation and Operating Information It is best to install your Guzzler G2 SapPuller pump at or above collection tank level to avoid shortening diaphragm life. Your Guzzler G2 SapPuller pump should be securely mount- ed to a mounting surface prior to operation. The support bracket of the pump has a mounting leg with two holes that accommodate a 1/4 in (6.4 mm) diameter bolt or screw. - Page 6 Installation and Operating Information The motor on your Guzzler G2 SapPuller Pump has a maximum service temperature of 104°F (40°C). Ensure that the motor is protected from the elements, but that it also has adequate airflow during operation to prevent over- heating.
- Page 7 Changing the Diaphragm and Valves (Optional) When replacing the diaphragm it is best to remove and repair only one pump body before a emp ng to remove the other body. Close a en on should be paid to the orienta on of various parts. The use of witness marks may be helpful during the reassembly.
-
Page 8: Changing The Diaphragm
Changing the Diaphragm Installing a new Diaphragm 10. Place the new diaphragm onto the clevis and se- cure it with the bu on (rounded edge side toward diaphragm), washer & screw. Note: Be sure to place the diaphragm on the clevis so that the ridge running along the diaphragm’s circumference is facing toward you. (Figure 11) (The other side of the diaphragm’s outer edge is flat.) Be sure the screw is ght. We recommend using blue Loc te on the screw to help ensure it does not come loose during pump opera on. Install the new diaphragm on the clevis. 11. Place the pump body up against the diaphragm Figure 11 and align it with the holes in the housing. (Figure 12) Be sure that the dia- phragm’s outer lip sits in the groove running around the circumference of the pump body. (Figure 13) (Note: Ensure the pump body is installed in the correct orienta on, with the outlet facing up.) ... -
Page 9: Removing The Valve
Changing Pump Valves Each pump body in the Guzzler G2 SapPuller pump features a pair of valves (a total of 4 for the pump). A valve is fastened between the pump body and each of its inlet and outlet ports. (Figure 14) Valves are typically replaced in pairs;... -
Page 10: Installing The Valve
flat side of the valve faces away from the pump body and toward the outlet flange. NOTE: IF THE UMBRELLA VALVES ARE NOT ORIENTED CORRECTLY IN THE PUMP FLANGES, THE PUMP WILL NOT FUNCTION PROPERLY AND COULD BE DAMAGED UPON OPERATION. Replacement Parts Your Guzzler G2 SapPuller pump comes with a pair of replacement diaphragms. Addi onally, The Bosworth Com‐ pany sells a full line of replacement parts for your pump, including replacement diaphragms and valves. You can order replacement parts directly through your distributor or by going on our website at www.thebosworthco.com Doc M-09-33-111516...
