top mount dimensional drawings
Recommended airspaces:
If you do not have a
cupboard with a rear gap,
the recommended
(y)
(x)
clearance on top increases
from 50mm to 90mm (x)
and 32mm to 72mm (y).
W
H
Max. door
Model
height (H)
STM5200
1714
STM4400
1714
STM3900
1714
STM3600
1634
STM3300
1714
STM3000
1614
For further information please visit your retailer, call 1300 363 640 or visit our website at www.simpson.com.au
Refer to product information on page 15.
†
Recommended airspace
18mm
H1
Cabinet
Total height
height (H1)
(H2)
1702
1720
1702
1720
1702
1720
1622
1640
1702
1720
1602
1620
50mm
CABINET
DOOR
D D1
H2
Door width
Cabinet width
(W)
(W1)
803
790
690
703
703
690
690
703
595
608
608
595
W1
D2
W
90°
When positioned
in a corner area,
spacing of at least
350mm on the
350mm
fridge side will
allow the doors
to open enough
to enable the
removal of the
bins and glass
shelves.
Total depth
Cabinet depth
(D)
(D1)
703
612
612
703
641
550
550
641
550
641
641
550
Depth door
open (D2)
1450
1350
1288
1288
1193
1193
11
