Side mounted grass catcher for pacer series mower

Advertisement

Quick Links

Installation Instructions
Grass Bag Installation:
1. Bag MUST be installed at all times
when using Chute Adaptor.
2. Open latches
3. Slide Grass Bag over chute opening
until bead on bag opening is in latch.
4. Close latches on each side to secure
Grass Bag.
5. Place handle on rear of bag over pre-
viously installed Rod Hanger.
Replacement Parts List
Description
Grass Catcher Bag
Grass Bag Hanger Rod
Grass Bag Hanger Rod Bracket
Adapter Chute Bracket
Adapter Chute
Wingnut
Bag Attachment Latch
Blade
Manufacturing, Inc.
500 N Spring Street / PO Box 997
Port Washington, WI 53074-0997 USA
www.simplicitymfg.com
Side Mounted Grass Catcher
Part Number
1727063
1727064
1727065
1727066
1709135
1679163
1727067
1706739
Rev. 04/2004
© 2004 Simplicity Manufacturing, Inc.
TP 200-4078-00-AT-S
4
Installation
Instructions
Pacer
Side Mounted Grass Catcher
P/N 1694677
Installation Instruction Manual
Side Mounted Grass Catcher
Mfg. No. 1694677
For Pacer Series Mower

Advertisement

loading
Need help?

Need help?

Do you have a question about the 1694677 and is the answer not in the manual?

Questions and answers

Summary of Contents for Simplicity 1694677

  • Page 1 Grass Bag Hanger Rod Bracket Adapter Chute Bracket Adapter Chute Wingnut Bag Attachment Latch Blade Manufacturing, Inc. © 2004 Simplicity Manufacturing, Inc. 500 N Spring Street / PO Box 997 Port Washington, WI 53074-0997 USA www.simplicitymfg.com Part Number 1727063 1727064...
  • Page 2 Installation Instructions Side Mounted Grass Catcher Mulching Kit Removal: 1. Remove Mulching Baffle from mower by removing the hardware along the front face of the mower deck. 2. Remove Mulching Plate from dis- charge opening by removing the Wingnut. 3. Save Mulching Baffle, Mulching Plate, and related hardware.
