Simplicity 960 Parts Manual

Simplicity 960 Parts Manual

9hp large frame two-stage snowthrowers
Hide thumbs Also See for 960:
Table of Contents

Advertisement

Quick Links

See also: Operator's Manual
960 Large Frame
9HP Snowthrowers
Mfg. No.
Description
1694435
960M, 9HP Snowthrower (CE)
1694439
960E, 9HP Snowthrower
Two-Stage Snowthrowers
Parts Manual
TP 400-3890-01-LW-S
11/2003
Rev.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 960 and is the answer not in the manual?

Questions and answers

Related Manuals for Simplicity 960

Summary of Contents for Simplicity 960

  • Page 1 960 Large Frame Two-Stage Snowthrowers 9HP Snowthrowers Mfg. No. Description 1694435 960M, 9HP Snowthrower (CE) 1694439 960E, 9HP Snowthrower Parts Manual 11/2003 Rev. TP 400-3890-01-LW-S...

  • Page 3: Table Of Contents

    Auger and Impeller Group - 24" ... 16 Auger Housing and Chute Group - 24" ... 18 Traction Drive Group ... 20 Wheels & Tires Group ... 24 Decals Group - 960 ... 26 Torque Specification Chart ... Inside Back Cover Table Of Contents PAGES...

  • Page 4: Handles And Controls Group

    The above parts group applies to the following Mfg. Nos.: 1694439 - 960E 1694435 - 960M © Copyright 2003 Simplicity Manufacturing, Inc. All Rights Reserved. Apply adhesive to secure grips. Shift rod assembly (Ref. 57) must pivot freely on pivot blocks, (Ref. 58).
  • Page 5 The above parts group applies to the following Mfg. Nos.: 1694439 - 960E 1694435 - 960M © Copyright 2003 Simplicity Manufacturing, Inc. All Rights Reserved. DESCRIPTION ROD, Auger, 3 7/16 Long 10-24 SPRING, Extension, 3 7/16 Long NUT, Hex Machine Screw, 10-24...
  • Page 6 The above parts group applies to the following Mfg. Nos.: 1694439 - 960E 1694435 - 960M © Copyright 2003 Simplicity Manufacturing, Inc. All Rights Reserved. Apply adhesive to secure grips. Shift rod assembly (Ref. 57) must pivot freely on pivot blocks, (Ref. 58).
  • Page 7 The above parts group applies to the following Mfg. Nos.: 1694439 - 960E 1694435 - 960M © Copyright 2003 Simplicity Manufacturing, Inc. All Rights Reserved. DESCRIPTION NUT, Hex Whiz Lock Flange, Small, 1/4-20 SUPPORT, Worm CARRIAGE BOLT, 5/16 x 3/4 G5...

  • Page 8: Engine And Frame Group - 9Hp Electric Start

    The above parts group applies to the following Mfg. Nos.: 1694439 - 960E © Copyright 2003 Simplicity Manufacturing, Inc. All Rights Reserved. Position idler pulley (Ref. 25) at center of slot in clutch arm (Ref. 22). Use 0-2 washers between Ref.
  • Page 9 * See your local Briggs & Stratton distributor for Parts & Service. ** Not a Service Part. The above parts group applies to the following Mfg. Nos.: 1694439 - 960E © Copyright 2003 Simplicity Manufacturing, Inc. All Rights Reserved. DESCRIPTION BELT, Traction BELT, Drive Auger GUARD, Belt NUT, Speed, 5/16-18 LOCKWASHER, Ext.
  • Page 10 The above parts group applies to the following Mfg. Nos.: 1694439 - 960E © Copyright 2003 Simplicity Manufacturing, Inc. All Rights Reserved. Position idler pulley (Ref. 25) at center of slot in clutch arm (Ref. 22). Use 0-2 washers between Ref.
  • Page 11 The above parts group applies to the following Mfg. Nos.: 1694439 - 960E © Copyright 2003 Simplicity Manufacturing, Inc. All Rights Reserved. DESCRIPTION CORD, Electrical, 3 Prong (Not a Service Part) GUARD, Muffler CAPSCREW, Hex Washer Head Taptite, #10-24 x 1/2...

  • Page 12: Engine And Frame Group - 9Hp Manual Start

    The above parts group applies to the following Mfg. Nos.: 1694435 - 960M © Copyright 2003 Simplicity Manufacturing, Inc. All Rights Reserved. Position idler pulley (Ref. 25) at center of slot in clutch arm (Ref. 22). Use 0-2 washers between Ref.
  • Page 13 * See your local Briggs & Stratton distributor for Parts & Service. The above parts group applies to the following Mfg. Nos.: 1694435 - 960M © Copyright 2003 Simplicity Manufacturing, Inc. All Rights Reserved. DESCRIPTION BELT, Traction BELT, Drive Auger GUARD, Belt NUT, Speed, 5/16-18 LOCKWASHER, Ext.
  • Page 14 The above parts group applies to the following Mfg. Nos.: 1694435 - 960M © Copyright 2003 Simplicity Manufacturing, Inc. All Rights Reserved. Position idler pulley (Ref. 25) at center of slot in clutch arm (Ref. 22). Use 0-2 washers between Ref.
  • Page 15 * See your local Briggs & Stratton distributor for Parts & Service. The above parts group applies to the following Mfg. Nos.: 1694435 - 960M © Copyright 2003 Simplicity Manufacturing, Inc. All Rights Reserved. DESCRIPTION CAP, Hex, 1/4-18NPT LOCKWASHER, 1/4 SUPPORT, Engine Riser...

  • Page 16: Auger And Impeller Group - 24

    The above parts group applies to the following Mfg. Nos.: 1694439 - 960E 1694435 - 960M © Copyright 2003 Simplicity Manufacturing, Inc. All Rights Reserved. Torque to 30 -34 ft-lbs. 40 - 46 Nm. 29 29 End of hub to be flush with end of rolled down shaft (Ref.

  • Page 17: Auger And Impeller Group

    The above parts group applies to the following Mfg. Nos.: 1694439 - 960E 1694435 - 960M © Copyright 2003 Simplicity Manufacturing, Inc. All Rights Reserved. DESCRIPTION PULLEY, Auger Input SETSCREW, Square Head, 5/16-18 x 1/2 IMPELLER ASSEMBLY SETSCREW, Square Head, 3/8-16x 1/2...

  • Page 18: Auger Housing And Chute Group - 24

    The above parts group applies to the following Mfg. Nos.: 1694439 - 960E 1694435 - 960M © Copyright 2003 Simplicity Manufacturing, Inc. All Rights Reserved. Decal must cover gap at hinge pivot. Coat top and bottom of chute ring with grease.

  • Page 19: Auger Housing And Chute Group

    Footnotes The above parts group applies to the following Mfg. Nos.: 1694439 - 960E 1694435 - 960M © Copyright 2003 Simplicity Manufacturing, Inc. All Rights Reserved. DESCRIPTION PUSH NUT, 1/4 CARRIAGE BOLT, 5/16-18 x 3/4 WASHER, Nylon WASHER, Flat, 11/32...

  • Page 20: Traction Drive Group

    The above parts group applies to the following Mfg. Nos.: 1694439 - 960E 1694435 - 960M © Copyright 2003 Simplicity Manufacturing, Inc. All Rights Reserved. Mounted inside of frame. Lubricate with 5W 50 Synthetic oil. Mount to bracket in frame weldment.
  • Page 21 Footnotes The above parts group applies to the following Mfg. Nos.: 1694439 - 960E 1694435 - 960M © Copyright 2003 Simplicity Manufacturing, Inc. All Rights Reserved. DESCRIPTION CAPSCREW, Hex Head, 5/16-18 x 5/8 LOCKWASHER, 5/16 NUT, Hex, 5/16-18 RETAINER, Bearing...
  • Page 22 The above parts group applies to the following Mfg. Nos.: 1694439 - 960E 1694435 - 960M © Copyright 2003 Simplicity Manufacturing, Inc. All Rights Reserved. Mounted inside of frame. Lubricate with 5W 50 Synthetic oil. Mount to bracket in frame weldment.
  • Page 23 The above parts group applies to the following Mfg. Nos.: 1694439 - 960E 1694435 - 960M © Copyright 2003 Simplicity Manufacturing, Inc. All Rights Reserved. DESCRIPTION BUSHING ARM ASSEMBLY, Pivot w/Bushings (Includes Reference Numbers 41, 43 & BUSHING PULLEY, Traction...

  • Page 24: Wheels & Tires Group

    Wheels & Tires Group W985644 NOTE: Unless noted otherwise, use the standard hardware torque specification chart. The above parts group applies to the following Mfg. Nos.: 1694439 - 960E 1694435 - 960M TP 400-3890-01-LW-S © Copyright 2003 Simplicity Manufacturing, Inc. All Rights Reserved.
  • Page 25 The above parts group applies to the following Mfg. Nos.: 1694439 - 960E 1694435 - 960M © Copyright 2003 Simplicity Manufacturing, Inc. All Rights Reserved. DESCRIPTION CAPSCREW, Hex Head, 5/16-18 x 2 NUT, Hex Lock ESNA Light, 5/16-18 VALVE STEM & CAP HUB, Wheel, RH TIRE, 4.80-4.00-8...

  • Page 26: Decals Group - 960

    The above parts group applies to the following Mfg. Nos.: 1694439 - 960E 1694435 - 960M © Copyright 2003 Simplicity Manufacturing, Inc. All Rights Reserved. WARNING TO AVOID SERIOUS INJURY Read Owner s Manual befor e operating unit. Never allow childr en to operate snowthr ower Always dir ect dischar ge chute so as to avoid injur y to persons —...

  • Page 27: Decals Group

    The above parts group applies to the following Mfg. Nos.: 1694439 - 960E 1694435 - 960M © Copyright 2003 Simplicity Manufacturing, Inc. All Rights Reserved. DESCRIPTION DECAL, Auger Control DECAL, Speed Selector DECAL, Warning / Main Dash Panel (Export) DECAL, Warning / Main Dash Panel...

  • Page 29: Hardware Identification & Torque Specifications

    Hardware Identification & Torque Specifications Common Hardware Types Hex Head Capscrew Carriage Bolt Standard Hardware Sizing When a washer or nut is identified as 1/2”, this is the Nominal size , meaning the inside diameter is 1/2 inch; if a second number is present it represent the threads per inch When bolt or capscrew is identified as 1/2 - 16 x 2”, this means the Nominal size , or body diameter is 1/2 inch;...
  • Page 30 MANUFACTURING, INC. 500 N. Spring Street / PO Box 997 Port Washington, WI 53074-0997 USA www.simplicitymfg.com © Copyright 2003 Simplicity Manufacturing, Inc. All Rights Reserved. Printed In USA.

This manual is also suitable for:

960m960e
