Simplicity 3190E Safety Instructions & Operator's Manual

Simplicity 3190E Safety Instructions & Operator's Manual

Single stage snow thrower series 0
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
ENGINE HP
AUGER WIDTH
3 – 3.0 HP (Engine Horse Power)
Before operating your Snow Thrower, read this manual carefully and pay particular attention to the "IMPORTANT
SAFETY INSTRUCTIONS" on Pages 2 & 3. Remember that all power equipment can be dangerous if used improperly.
Also keep in mind that SAFETY requires careful use in accordance with the operating instructions and common
sense.
Safety Instructions & Operator's Manual for
MODEL NUMBER EXPLANATION
3
19 – 19" Auger Width

SNOW THROWER

19
0
E
SINGLE STAGE
SERIES 0
Model
Mfg. No.
3190M
1694382
3190E
1694383
ENGINE OPTIONS
SERIES DESIGNATION
0 -- Series Designation
E – 110 Volt Electric Start
M – Manual, Recoil Start
Manual No. 2-1806 (I.R. 2/6/03)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 3190E and is the answer not in the manual?

Questions and answers

Related Manuals for Simplicity 3190E

Summary of Contents for Simplicity 3190E

  • Page 1: Snow Thrower

    19 – 19” Auger Width SINGLE STAGE SNOW THROWER SERIES 0 Model Mfg. No. 3190M 1694382 3190E 1694383 ENGINE OPTIONS SERIES DESIGNATION 0 -- Series Designation E – 110 Volt Electric Start M – Manual, Recoil Start Manual No. 2-1806 (I.R. 2/6/03)
