Simplicity 1687393 Installation Instructions

Installation

Instructions

Kit Contents:

Ref Part No.
1 1733057
2 1716532
3 1736947
This kit contains the decals and modifications
necessary to convert an export CE snowthrower
into an ANSI compliant domestic product.
INSTALLATION
1. Remove the push nuts (B, Figure 1) securing the
chute wireform (A).
2. Remove and discard the wireform (A).
3. Replace the icon-based CE decals on the unit with
the text and icon ANSI decals from this kit as shown
in Figure 2.
4. Remove and replace the electric starter with Briggs &
Stratton electric starter kit 696611.

Figure 2. Decal Replacement

M A N U F A C T U R I N G .
Briggs & Stratton Yard Power Products Group
Copyright © 2007 Briggs & Stratton Corporation
Milwaukee, WI USA. All Rights Reserved
Qty. Description
1 Chute Warning Decal
1 Auger Warning Decal
1 Dash Panel Decal
Snowthrower Decal Conversion Kit
B

Figure 1. Remove Chute Guard

A. Chute Guard
B. Push Nuts
Part No. 1687393
A
Form No. 1736014
Revision: 00
TP 200-4832-00-SK-S
