Summary of Contents for Speco VMST7
-
Page 1: Quick Guide
Thank you for purchasing our product. Speco Technologies is constantly developing and improving products. We reserve the right to modify product design and specifications without notice and without incurring any obligation. 7” LCD CCTV Test monitor Quick guide ◎ connect battery before using... -
Page 2: Please Read Before Using
PRECAUTIONS Please read before using The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of insulated dangerous Voltage within the product’s enclosure that may be sufficient magnitude to constitute risk of electrical shock to persons. The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operation and maintenance (servicing) instructions in the literature accompanying the appliance. - Page 3 Components ② ① ③ ④ ⑤ ⑥ ⑦ 7”LCD CCTV Test monitor Power cord Power supply cable (for camera) Audio cord Storage Bag Quick guide battery...
- Page 4 Exploring your Test Monitor ① ① ② ⑦ ③ ④ ⑤ ⑥ Green light: Power on ①System indicator Red light: Charging Green light winking: Sleep mode ②Light sensor Auto adjusting back light ③Source Switch AUTO / TVI / AHD input ④Direction Up / Down / L / R direction for select options ⑤Menu...
- Page 5 ⑩ ⑧ ⑤ ⑨ ⑦ ⑥ ① ② ④ ③ ①Speaker Build-in speaker for testing ②Li-on battery 3400mAh, Li-ion Battery ③Led light Flashlight ④stand Easy for using on desk ⑤Power input DC 12V / 2A for charge ⑥ DC 12V / 500mA, supply temporary power for camera Power output ⑦...
- Page 6 Menu 1. Image adjust： Click “ Menu ” to enter adjust menu as below. a. AHD or TVI input b. AV input 2. System function： Click “ Menu ” →” ▼” to enter menu as below System will go to standby mode to save power automatically when no input.
- Page 7 3. Default Input & PTZ (If camera available)： Click “ Menu ” →” ▼” twice→” ► twice” to enter Default Input & PTZ function Change Default Input AUTO / AHD / TVI To control Tele/ Wide/ Far/ Near. Click “ Menu ” →” ▼” twice→” ►” →” ▼”→” ►” to enter PTZ Menu ( Camera OSD menu)
- Page 8 Test Function and Operation Press ◄ or ► button to switch function and ▲ or ▼ to select more options. 1. CABLE TEST：Open or Short circuit testing...
- Page 9 Don’t connect others I/O in AC/DC mode, measure AC/DC voltage in any types of I/O function or operate AC/DC measure function in charge mode. 2. PATTERN OUT (NTSC): Press ▲ or ▼ to switch 5 different modes. (NTSC V RAMP) (NTSC V COLOR) (NTSC H GRAY) (NTSC V GRAY) (NTSC H RAMP) 3.
-
Page 10: Specifications
3. System indicator will show charge status. Charge independently is better for battery life and fast short battery charger time. In addition, Charge voltage should not be below 2A. Caution! Do not use when charging battery. Dimension Specifications Panel Size 7'' TFT-LCD... - Page 11 Display Resolution 800 x 480 Input Support AHD / TVI / AV Brightness 400 cd / m² Signal Input BNC x 1 ( For AHD / TVI / AV ) Output signal BNC x 1 ( For CVBS Pattern test ) Power Output DC 12V / 500mA ( Supply the temporary power ) Pattern Output...
