  • Page 1 MPS I C Interface User Manual Revision 1.0 Monolithic Power Systems www.monolithicpower.com...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS – 目录 1. INTRODUCTION ....................... 2 1.1 What is the MPS I2C GUI? ....................2 1.2 System Requirements ......................2 2. INSTALLATION ......................3 2.1 Installing the MPS IIC GUI ....................3 2.2 Installing the USB Driver ..................... 3 3.

  • Page 3: Introduction

    1.1 What Is the MPS I C GUI? The MPS I C Interface system is a system that helps customers easily use MPS parts with an I C function. The system includes an EVB board, an I2CBUS KIT between the PC and IC, and a computer with Windows 7 or higher system (see Figure 1 and Figure 2).

  • Page 4: Installation

    2. INSTALLATION The MPS IIC GUI.rar can be downloaded from the MPS website. Extract it into a directory. 2.1 Installing the MPS IIC GUI Double click the .exe file and flow the set-up guide (see Figure 3). For this example, we’ll be using the MP5515.
  • Page 5 Connect the MPS I2CUSB KIT to your PC through the black USB cable. Windows will find the new hardware and open a dialog box to instruct you on installing the driver. 2. Select “Install from a list or specific location (Advanced)” and press “next”.
  • Page 6 3. Browse to the location that you extracted the “.rar” file before and choose either the “x86 Driver” or the “x64 Driver” folder, depending on your system type, and press “next”. Contact your system administrator is you need to know your PC’s system type. 4.

  • Page 7: Usage

    3. USAGE 3.1 Hardware Connection Use the colored wires to connect the EVB to the MPS I2CBUS KIT (see Figure 4). Please refer to the specific part datasheet for EVB pin definitions. Figure 4: EVB to MPS I2CBUS KIT Wire Connection Refer to the EVB datasheet to start up the EVB and connect it to the PC via the IICBUS KIT.
  • Page 8 Start the software. It will check the EVB connection automatically. If the connection is not successful, a warning will appear at the bottom. Otherwise, the address will be listed in the “Slave Address.” 2. Select the part number, then, the control information will be seen in the “Register Control.”...
  • Page 9 3. Find the item you want to change, select the value, and the changed information of the item will appear on the right side. Click the “Read All” button to update all the item’s values.
