K&K Sound PURE FLOATING BRIDGE Product Manual

P R O D U C T M A N U A L

PU RE F L OA T IN G B RID G E

This system is designed especially for instruments with floating bridges. The pickup and jack (externally

mounted) can be installed without modifications to the bridge or instrument.

The Pure Floating Bridge Pickup works well in passive mode. However, if a preamp is desired we

recommend the K&K Pure Preamp or the Pure XLR Preamp.

INSTALLATION

Please install the two pickups as shown in the photo, one under each bridge foot. Loosen the strings a bit,

lift one bridge foot and place one pickup (golden side to soundboard) under it. Then repeat the same on

the other bridge foot. Make sure the bridge is not pinching a cable, as the cables are slightly thicker than

the pickups.

The cables can be hidden under the strings and the tailpiece. The ¾" adjustable rubber sleeve on the

cables can be pulled tight towards the pickups to avoid mechanical cable noise.

92798 Cape Arago Hwy, Coos Bay, OR 97420 | 541-888-3517 | Toll Free 1-800-867-6863 | www.kksound.com
