Installation
Instructions
1
Figure 1. Contents
WARNING
Before beginning any service work turn off the
PTO, set the parking brake, turn off the ignition,
remove the key, and disconnect the spark plug
wire(s).
INSTALLATION
1. Attach bumper (A, Figure 2) to inside of frame (B)
securing with 5/16-18 x 7/8 capscrews (C)
and 5/16-18 flange lock nuts (D).
M A N U F A C T U R I N G , I N C .
500 N Spring Street / PO Box 997
Port Washington, WI 53074-0997 USA
A
Mfg. No./Part No. 1695285
2690642, 2690644, 2690645, 2690647
2
Kit Contents:
Ref
Part No.
1
1733975
3
2
1960686
3
1921333
C
D
Figure 2. Bumper Installation (Footrest and Spindles
Ghosted for Clarity)
A. Bumper
B. Frame
C. Capscrews, 5/16-18 x 7/8
D. Nut, Flange Lock, 5/16-18
Note: Lift front of bumper up while tightening hardware to
prevent wheels from contacting bumper.
Briggs & Stratton Yard Power Products Group
Copyright © 2007 Briggs & Stratton Corporation
Front Bumper
Axion and 150Z Series
Qty.
Description
1
Bumper Assembly
4
Nut, Flange Lock, 5/16-18
4
Capscrew, Hex, 5/16-18 x 7/8
B
Form No. 1734264-01
TP 200-4438-01-AT-SN
Milwaukee, WI USA. All Rights Reserved
C
Rev. 2/2007
