Sima UDC-2 Instruction Manual

Safety and Maintenance
DO NOT use charger inside a drawer, closed cabinet, on a carpet
or cover with a cloth. The charger will become slightly warm in
normal use, but if contained, heat may damage the charger and
battery pack.
DO NOT atttempt to open the charger, there are no serviceable
parts. Doing so will void the warranty.
DO NOT allow moisture of any kind to come in contact with the
charger. NEVER IMMERSE IN LIQUID!
DO NOT store where it may be exposed to extreme temperatures;
avoid placing in direct sunlight. High temperatures can shorten the
life of electronic devices, damage batteries and warp metal or
plastics.
DO NOT short circuit the output terminal or contacts.
DO NOT drop the unit, a jolt can cause permanent damage and is
not covered by the warranty If the charger must be cleaned, be
sure it is unplugged. Wipe the unit with a clean cloth, lightly
dampened with mild detergent. Use a clean cloth, lightly dampened
with rubbing alcohol to clean the metal contacts.
Trouble Shooting
Possible Cause/Solution
Problem
Confirm the AC or cigarette adapter is firmly
No Indicator
connected at both ends. Confirm that wall outlet is
Lightswith
working. Check fuse in car cord (un-screw tip of
battery mounted
cigarette lighter adapter).
• Battery is already fully charged.
• Battery mounted incorrectly; remove and
re-mount battery. Clean battery/charger contacts.
Normal operation due to advanced switching
Hissing noise in
circuitry.
Charging Mode
If you have trouble installing your battery
or if it is not listed on this chart,
do not call the store where you purchased the UDC-2.
Call Sima customer service at 800-345-7462
Battery Chart
Brand Volt Batt. type Model Number
Canon 6V NiCad/NiMH BP-E77/711/714/718/722/729
Canon 7.2V Lithium Ion BP-80/85
Canon 7.2V Lithium Ion BP-608/617
Canon 7.2V Lithium Ion BP-911/914/915/924/927/930/941/945
Hitachi 6V NiCad/NiMH VM-BP82/82A/83/84/84A
Hitachi 7.2V Lithium Ion VM-BPL13A/27A/30A/60A
Hitachi 7.2V Lithium Ion DZ-BP16/28
JVC 6V NiCad/NiMH BN-V11U/12U/14U/140U/22U/50U/60U Base
BN-V20U/25U
JVC 7.2V Lithium Ion BN-V607/615U
JVC 7.2V Lithium Ion BN-V812/814U
Panasonic 6V NiCad/NiMH PV-BP15/17/18/ VW-VBS1E/S2E
Panasonic 7.2V Lithium Ion VW-VBD1/PV-BP5/AG-BP25
Panasonic 7.2V Lithium Ion CGR-D120/220/320/S602/
PV-BP8A/VW-VBD20
CGA_DU07/14/21
RCA 6V NiCad/NiMH BB-45/75L/060/120/FB120/1260
RCA 7.2V Lithium Ion BB-55L/65L/85L
Sharp 6V NiCad/NiMH BT-80
Samsung 7.2V Lithium Ion SB-L110/220
Samsung 7.2V Lithium Ion SB-L160/320/480
SONY 6V NiCad/NiMH NP-55/66/67/68/77/78/98
SONY 7.2V Lithium Ion NP-FF50/70
SONY 7.2V Lithium Ion NP-F100/200/300
SONY 7.2V Lithium Ion NP-F330/530/550/730/730H/750/750
SP/930/950/960
SONY 7.2V Lithium Ion NP-FM30/50/70/90/91/QM50/70/90
Warranty Statement
Sima Products Corporation ("Company") warrants that if this product proves to be defective to the original purchaser
in material or workmanship within 90 days from the date of original retail purchase, the company will, at the
company's option, either repair or replace same without charge (but no cash refund will be made).
To enforce this warranty, ship your unit, freight pre-paid, including reasonable proof of date and place of purchase
and description of problem to:
Attn: Customer Service
c/o Sima Products Corporation
140 Pennsylvania Ave. Bldg #5
Oakmont, PA 15139
Exclusions: This Limited Warranty covers all defects in material and workmanship in the product, except damage
resulting from accident, misuse, abuse, attempted repair by anyone other than the Company, neglect or from their
normal and ordinary use of the product. The Company accepts no liabilities or obligations for consequential or
incidental damage arising out of or in connection with the use or performance of the product. The Limited Warranty
provides you with specific legal rights, you may have additional legal rights provided to you under the laws of your
state or federal laws.
Universal Battery Charger
use with Camcorders
Model UDC-2
Tray
Works with these
camcorders:
Base
A
Sony JVC
C
RCA Canon
C
Base
Sharp Hitachi
A
& more!
C
Base
A
A
Base
A
C
C
C
Base
A
Base
Includes 3 adapter trays to charge
C
C
Lithium - ion,
Base
Ni-Cad
A
A
and NIMH batteries
A
A
A
Includes AC & DC adapters
©2004 Sima Products Corporation
140 Pennsylvania Ave.
800-345-7462 Fax 412-828-9338 www.simacorp.com
for
www.simacorp.com
800-345-7462
Bldg #5 Oakmont, PA 15139
PN217001
