Sim2 SMG45 D169 Technical Specifications

SMG45 D169
Technical specifications
PROJECTION SYSTEM
Technology
DMD™ Panel Resolution
Aspect Ratio (W:H)
Screen Brightness
Uniformity
Contrast Ratio
Number of colors
Color Temperature
Screen size Diagonal size
Width x Height
Lamp Type
Average Life
ELECTRONICS
Horizontal Frequency
Vertical Frequency
Analog Bandwidth
Graphic Standards
Video Standard
INPUT/OUTPUT SIGNALS
Graphic Inputs
Video Inputs
DVI Input / Output
Control Interface
ELECTRICAL DATA
Main Power Supply
Power Consumption
Max Current Absorption
Fuse
MECHANICAL DATA
Cabinet Dimensions
Net Weight
ENVIRONMENTAL DATA
Ambient Temperature
Storage and Transportation
Humidity
Max Altitude
SAFETY AND REGULATORY DATA
Standards Drop Test
Safety
EMC emission
EMC immunity
Accessories
Easywall 3
RC 2000
Wall or ceiling breacket on request
(*) Lamp life: the hours have been calculated under strict test conditions. Misuse or improper operating conditions may alter it.
Digital Light Processing™, DLP™ and DMD™ are registered trademarks of Texas Instruments.
Due to constant product development, specifications and design might be subject to change without notice. SMG45 D169 - World - October 2003
DLP™ - 1 chip DMD™ 0,7" 12° HD2
1280 x 720
16:9, Anamorphic, Letter Box, Panoramic, Pixel to Pixel, user
500 cd/m2
> 70% ANSI measurement
1000:1
16,777,216 colors
3 preset + 1 user selectable
45"
99,6 x 56,0 cm
VIP 120 W
6000 hours (50% survival @50% integral lm maintenance)*
15KHz - 110 KHz
48 Hz - 120 Hz
170 MHz @ -3dB for graphic signals;
8 MHz @ -2 dB for video signals
from VGA (640x480) to UXGA (1600x1200) with internal scaling
automatic recognition and decoding: PAL, NTSC, SECAM
internal motion-adaptive deinterlacing
1 x RGB+HV (or YPrPb) on 75 Ohm BNC connectors
1 x RGB+HV on HD15 connectors
- 1 x CVBS1 in on BNC1 connector
- 1 x CVBS out on BNC2
- 3 x CVBS in on BNC3-4-5 connectors
- 1x S-Video (in-out) on mini DIN4 Connectors .
ATSC HDTV is also supported on BNC or HD15 connectors
- 1x RGB HV15 KHz (from SCART output) su BNC 1-5
Analog RGBHV + Digital RGB (in/out)
Serial Interface RS232C on DB9 in connector
RS485 on DB9 in/out connectors
USB for control from a remote PC;
email:sales.largedisplay@sim2.it
IR Control Remote handset on request
100 Vac - 240 Vac +/- 10%; Line Frequency 48 - 62 Hz
Max 186 W (160 Kcal/h)
@120 V:1,5 Arms @230V: 0,8 Arms
T 3.15A H 5x20mm located on the rearprojector
WxHxD 109x87x34
40 Kg (without base)
50 Kg (with base)
Operating from 0° to +35°C
from -10°C to +55°C
SIM2 DEUTSCHLAND GmbH
from 10% HR to 90% (without condensation)
Operating 4000m
Transport 11000m
in compliance with IEC 68-2-31, IEC68-2-32
in compliance with EN 60950
in compiance with EN 55022, EN61000-3-2/3
in compliance with EN 55024, EN61000-4-2/3/4/5/6/8/11, ENV50204
PC based control software
Remote Control Handset p/n 790010000
Headquarters:
SIM2 MULTIMEDIA S.p.A.
Viale Lino Zanussi 11
33170 Pordenone - Italy
Tel. +39.0434.383253
Fax. +39.0434.383261
www.sim2.com
USA:
SIM2 SELECO USA Inc.
10108 USA Today Way
33025 Miramar FL - USA
Tel. +1.954.442 2999
Fax. +1.954.442 2998
email: sales@sim2usa.com
www.sim2usa.com
Germany:
Gewerbepark, 17
35606 Solms - Germany
Tel. +49-800-8007462
Fax. +49-800-9007462
email: info.de@sim2.it
www.sim2.com
UK:
SIM2 UK Ltd.
Steinway House
Worth Farm
Little Horsted
Nr. Uckfield
East Sussex TN22 5TT
Tel:+44-1825-750850
Fax:+44-1825-750851
www.sim2.co.uk
SIM2 Multimedia is certified
45" Display Monitor
