RP901 User Manual Chapter 1 - Overview 1.1 Package Please make sure the following contents are in the RP901 gift box. If something is missing or damaged, please contact your unitech representative. The standard package contents: RP901 Wireless UHF RFID Reader ...
RP901 User Manual 1.3 Specifications The RP901 can support the EPC protocols Generation 2 of RFID tags. Both EPC Code and TID data of GS1 standard are readable. System & Performance Frequency 8652MHz~928MHz (US/EU/JP/TW/CN) RFID Protocol EPC Generation-2, ISO 180000-6C...
1.4 Getting Started 1.4.1 Power Up Press the Trigger Button for 2 seconds without releasing. RP901 will emit one long beep and light the LED red. When the sound then stops and the light goes off, the reader successfully powers up.
Page 21
RP901 User Manual 1.4.3 Connecting to a PC/ Notebook Step 1: Press and hold the Trigger Button for 2 seconds to power up RP901, after that the blue indicator LED will flash continuously. (If the blue LED does not flash, it ®...
Page 23
Press and hold the Trigger Button for 2 seconds to boot the unit, after which the blue LED indicator will flash continuously. (If the blue LED indicator does ® not flash, it means RP901 is not currently in Bluetooth Mode. Please refer to 3.7 Communication Interface.
Page 24
RP901 User Manual Step 4: Upon establishing connection the RP901 will emit two short beeps and turn off its blue LED indicator. Also, the UHF RFID Reader in the Apple iOS device’s ® Bluetooth devices list will list as “Connected”.
Page 25
RP901 User Manual Step 6: If a virtual keyboard is required, please press the Function Button once. At this moment the RP901 will emit one short beep, and the Apple iOS device’s virtual keyboard will pop out. ...
Page 27
RP901 User Manual Step 4: Upon establishing connection the RP901 will emit two short beeps and turn off its blue LED indicator. Also, the UHF RFID Reader in the Android device’s ® Bluetooth devices list will list as “Connected”. ...
Page 29
RP901 User Manual 1.4.6 Reading RFID Tags RP901’s RFID antenna is located at its front. When reading, hold the unit, aim at the RFID tag, and press the Trigger button. If reading is successful (Good Read), the RP901 will emit one beep and the green LED indicator will simultaneously lit for one second.
Page 30
RP901 might be requested for a pincode, which is unable to be input from RP901 (as it does not have a numeric keypad). To fix this, redo Step 1 & 2, restart your Host device and try establishing new connection with RP901 again.
Page 31
When the Communication Interface is set to Memory (refer to Communication Interface), data obtained from RFID Tag read operations will be stored in RP901’s memory. The following steps will store or delete the data within. A. Retrieving the Data in Memory...
Page 35
RP901 User Manual B. Deleting the Data in Memory To delete the data on RP901’s Memory, please directly delete the file TAGDATA.TXT in the removable storage device “MiniScan”. In about 5 seconds the RP901 will emit 2 short beeps, indicating a successful delete.
** It can be that an obstacle between RP901 and host device has interfered with the data transmission , or RP901 is too far away from the host device. To fix this, please get back in effective transmission range.
The following steps will switch the RP901 to Configuration Mode and connect it to the Host PC’s RFID Utility. Step 1: Use a micro USB cable and connect the RP901 to the Host PC. Step 2: Press and hold RP901’s Function button first without releasing, then press and hold the Trigger button.
Step 4: Open the RFID Utility from the Host PC and complete the connection. The above steps will switch the RP901 to Configuration Mode and connect it to the Host PC’s RFID Utility. The User may begin setting parameters on the RP901.
Page 42
<A> The Auto Mode follows the same rules of operation as the Trigger Mode, except that scan operation start automatically, without pressing the Trigger button. <B> Scan Operation is repeated and do not terminate unless the RP901 enters Sleep Mode. <C> In Sleep Mode, Pressing the Trigger button will automatically reactivate Auto Mode.
Page 43
RP901 User Manual 3.1.2 Read Mode RP901 supports Single-Tag Read mode or Multi-Tag Read mode. Different Memory Bank can be read according to Read mode selected. Session and Target can be set for determining how often a tag will respond to a query from the reader.
Page 44
RP901. Default Setting: S0 ■ Target There are two Targets: Single Target and Dual Target. RP901 will read flag A if Single Target is selected, and will read A first then read B if Dual Target is selected.
Page 46
Up to 8 digits of hexadecimal value can be entered if Access Password is required. Configuration Method: Set Access Password, once confirmed then click to send the new parameter to the RP901. Default Setting: None ■ Starting Pointer and Data Length...
RP901 User Manual 3.4 RF Parameters 3.4.1 RF Output Power This function will set the RF output power of RP901. Lower output power will result in shorter reading distance as well as more power saving. Configuration Method: Select one RF output power...
Each parameter of data output can be set: simply choose one of either Disable or Enable then click to send the new parameter values to the RP901. There are two output formats available, one Full Description another Simple Cascade. In Simple Cascade format, the caption is neglected even it is enabled.
Page 54
Select the Simple Cascade format or Full Description format. Configuration Method: Choose one of the two formats then click send the new parameter values to the RP901. Default Setting: Simple Cascade Format 3.5.2 Data Content Whether to output UHF tag data in hexadecimal format or character format.
RP901 User Manual 3.6 Other Parameters Setup RP901 has other parameters not related to RFID, such as Date Format, Time Format, Communication Interface, Sleep Mode etc. 3.6.1 Date Format Date format of memory data’s date mark. Set how date format is arranged: D means Date, M means Month, Y means Year.
Page 65
Choose one of the two then click transfer the parameter value to the RP901. Default Setting: HH:MM:SS 3.6.3 Communication Interface Set the communication interface between the RP901 and the Host PC, meaning the communication interface for RP901’s data output. Five choices are available. Configuration Method: Choose one of the five then click transfer parameter values to the RP901.
Page 66
SPP (BT Virtual COM) as communication interface. During BT-SPP connection, RP901 can be programmed via command strings sent from the Host. RP901 also can be triggered to start/stop scanning tags via BT-SPP connection without using the physical trigger button. The details are described in the RP901 BT-SPP Command Manual, please download the manual from: http://w3.tw.ute.com/pub/cs/manual/rp901/RP901_BT_SPP_Commands_...
These include Key Layout, Key Numeric, Key Caps lock, Inter-block, and Inter-character. 3.9.1 Keyboard Layout Set the language used for RP901’s data output to the Host- PC. 24 choices are available. Configuration Method: Choose one of 24, then click transfer the parameter setting to the RP901.
Page 70
Configuration Method: Choose one (value range 0 ~ 500 ms), then click to transfer the parameter setting to the RP901. Default Setting: 0 ms 3.9.5 Inter-character Interval Time Set the Interval Time between one character and the next within each packet of data.
RP901 User Manual 3.10 Data Terminator Set the terminator symbol used when uploading RP901’s data to the Host-PC. It can be 1 or 2 Bytes depending on the Communication Interface. Configuration Method: Choose or type in a symbol using the special keyboard shown in photo.
3.11 Sleep Mode /Timer Set the activation status for Sleep Mode and the Timer value used for entering Sleep Mode. The RP901 will enter Sleep Mode to conserve power if there is no successful Tag scanned after a period of time.
Host PC within a Wait Time, it will automatically exit Configuration Mode and return to Normal Operation Mode. Or, while within Wait Time, if the RP901’s Function button is pressed, followed by the Trigger button, and both buttons are held for about 5 seconds, it will also exit Configuration Mode.
* Only when connected to an RP901 may Retrieve and Update be used. Reset: Restore all parameters to their Default settings. When the RP901 is connected to the Host-PC, User can restore all parameter inside the RP901 to their factory Default settings (Reset Reader’s Parameter to Default).
5.1 Entering Firmware Update Mode Under normal circumstances, the RP901 boots into the Normal Operation Mode. The following steps will move the RP901 to Firmware Update Mode and connect it to the Host PC’s RFID Utility to facilitate firmware upgrade through USB Virtual COM communication.
Page 82
Still holding down the Function button and Trigger button, check the Device Manager on the Host PC to see if a USB Virtual COM has appeared. Now release the Function button and the Trigger button. The RP901 will automatically change its Communication Interface to USB Virtual COM.
Page 84
CAUTION ! While the RP901 is updating its firmware , please avoid unnecessary errors and do not unplug the cable. Incomplete firmware update may cause damage to RP901. Step 6: When update is complete, click “OK”to finish the update program. The RP901 will reboot and return to Normal Operation Mode automatically.
