Low Profile Universal TV Mount - 23" to 42"
Fixed Flat-Panel TV Wall Mount
Material: 2.0mm Cold Rolled Steel Plate
TV Size: 23" - 42"
Max load capacity: 132lbs / 60kgs
Wall distance: 1.38" / 35mm
Bubble level included
Universal Mounting Pattern
IMPORTANT: If you don't understand the installation instructions, please consult an installation
specialist
04-0660A
Installation Instructions
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for SIIG 04-0660A
Summary of Contents for SIIG 04-0660A
-
Page 1: Installation Instructions
Low Profile Universal TV Mount - 23" to 42" Fixed Flat-Panel TV Wall Mount Material: 2.0mm Cold Rolled Steel Plate TV Size: 23" - 42" Max load capacity: 132lbs / 60kgs Wall distance: 1.38" / 35mm Bubble level included Universal Mounting Pattern... - Page 2 INSTALLATION AND OPERATING INSTRUCTIONS Caution Prior to the installation of this product, the installation instructions should be read and completely understood. The installation instructions must be read to prevent personal injury and property damage. Keep these installation instructions in an easily accessible location for future reference. CAUTION: The maximum load capacity is 132lbs.
- Page 3 Tools Required: Phillips head screw driver Stud finder for drywall installation 7/16" Socket and Wrench Electric drill, 1/8" (3mm) drill bit for wood stud installation and 5/16" (8mm) masonry bit for concrete/brick installation Note: Please ensure that the bubble level (G2) is properly mounted on the wall plate prior to mounting the wall plate.
- Page 4 B) Concrete / Brick Installation The concrete anchors must be used for concrete installation. NOTE: Attach the bubble level (G2) to the wall plate, with the help of an assistant place the wall plate into position against the wall, using the bubble level to keep it level. Mark four holes to be used for securing the mount and place the wall plate aside.
- Page 5 Step 3 Final Installation & Adjustment Hook the TV rails over the top of the wall plate. Then rotate the long screw at the bottom of the display rail to tighten. Maintenance Check the mounting screws every two months for tightness.
- Page 6 Blank Page...
- Page 7 • You are responsible for the cost of shipping to SIIG. Ship the product to the following address: SIIG, Inc. 6078 Stewart Avenue Fremont, CA 94538-3152, USA RMA #: ________________ • SIIG will ship the repaired or replaced product via Ground in the U.S. and International Economy outside of the U.S. at no cost to the customer.
- Page 8 VARs. Low Profile Universal TV Mount - 23" to 42" is a trademark of SIIG, Inc. SIIG and the SIIG logo are registered trademarks of SIIG, Inc. Other names used in this publication are for identification only and may be trademarks of their respective owners.
