SIIG 04-0735A Quick Installation Manual

Bluetooth wireless mini keyboard
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Introduction
The Bluetooth Wireless Keyboard is an Ultra-thin
mini keyboard with ultra-comfort laptop style
keypad.
Key Features and Benefits
•
Compliant with Bluetooth version 2.0 (HID
profile)
•
Compact footprint with 85-key layout for
space saving and ease of carry
•
6 media play control function keys (Play/
Pause, Previous, Next, Volume Up, Volume
Down, Mute)
•
Scissor key switch structure gives comfort
touch with tactile feedback
•
On/Off power switch and smart power
management function to better extend
battery life
04-0735A
Bluetooth Wireless Mini
Keyboard
Quick Installation Guide
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 04-0735A and is the answer not in the manual?

Questions and answers

Related Manuals for SIIG 04-0735A

Summary of Contents for SIIG 04-0735A

  • Page 1 6 media play control function keys (Play/ Pause, Previous, Next, Volume Up, Volume Down, Mute) • Scissor key switch structure gives comfort touch with tactile feedback • On/Off power switch and smart power management function to better extend battery life 04-0735A...

  • Page 2: System Requirements

    System Requirements • Bluetooth wireless technology (V2.0 or later) enabled laptop or desktop PC • Windows 7 (32-/64-bit) / Vista (32-/64- bit) / XP (32-/64-bit) Package Contents • Bluetooth Wireless Mini Keyboard • 2 AAA batteries • Quick installation guide Layout Connect Button On/Off Switch...

  • Page 3: Installing The Batteries

    Installing the Batteries Remove the battery cover from the back of the keyboard. Insert the 2 AAA batteries. Make sure the batteries are properly installed as indicated by the image below. Replace the battery cover. Figure 3: Installing the Batteries Pairing Keyboard Turn on the Bluetooth source device's Bluetooth function.

  • Page 4: Function Key (Fn)

    User's should see new device called Bluetooth Wireless Keyboard. The connection process should provide a pass code for pairing. Enter the pass code from the keyboard and press Enter key. Wait while the keyboard is added to the system. Function Key (Fn) The function key (Fn) enables the typing of the function keys and the operation of the embedded numeric keypad.

  • Page 5: Numeric Keypad

    Numeric Keypad The numeric keypad works with the NumLock Num Lock On Hold down the Fn and press NumLock key. The blue characters of the numeric keypad will be enabled. The alpha characters are disabled. Note: To return to normal keyboard operation, hold down the Fn key and press NumLock key to turn off NumLock.

  • Page 6: Bios Setting

    Bios Setting The Bluetooth Wireless Keyboard's space-saving design requires the dual alpha/numeric function of certain keys. Since the numeric keypad feature is controlled by the Num Lockkey, an inconvenient situation will occur when using a computer that automatically enables the Num Lock key with each boot up.

  • Page 7: Technical Support And Warranty

    Go to www.siig.com, click Support, then REQUEST A PRODUCT REPLACEMENT to submit a request to SIIG RMA or fax a request to 510-657-5962. Your RMA request will be processed, if the product is determined to be defective, an RMA number will be issued.
  • Page 8 Fremont, CA 94538-3152, USA Phone: 510-657-8688 Bluetooth Wireless Mini Keyboard is a trademark of SIIG, Inc. SIIG and the SIIG logo are registered trademarks of SIIG, Inc. Microsoft and Windows are registered trademarks of Microsoft Corporation. All other names used in this publication are for identification only and may be trademarks of their respective owners.
