Welcome to the AirBooster™ 350 RF amplifier
The AirBooster 350 is an intelligent RF amplifier for boosting some Sierra
Wireless Class III (600mW)
an "intelligent" booster in that it does not simply apply a fixed gain to a
varying input RF level as a linear amplifier would. Instead, the AirBooster
amplifier takes a constant RF level from the CDPD device and applies as
much gain as the CDPD system requires at that moment.
A GPS Option is also available, adding a GPS receiver inside the package.
This is available as a field upgrade kit or pre-installed at the factory.
Documentation related to GPS is covered in a
Your AirBooster 350 Components
All AirBooster 350 packages will include the following components:
™
AirBooster 350 RF amplifier.
Power Cable.
Sierra Wireless Product CD-ROM with this Documentation including a
3 Year Warranty.
4 Screws with Washers.
Mounting Template.
Quick Start Guide.
Units with the factory installed GPS option will also include:
DB-9 Serial Cable.
Additional accessories are available from
RF Connector Cables (an assortment of lengths and connector options
are available).
GPS Options (Factory Installed or Field Upgrade Kit).
GPS antennas (Magnetic or Hard Mount options).
For details on these and other Sierra Wireless accessories
visit our web site.
Supported Products
At the time of this writing, the AirBooster 350 RF amplifier is supported by
the following Sierra Wireless products:
®
AirCard 350 CDPD Adapter
SB300 OEM Module
Additional Sierra Wireless products may be added to this list. Consult
web site for a complete and current list.

User Guide

CDPD devices to Class I (3W). The amplifier is
separate
Sierra Wireless. These include:
2110195 Rev 1.0
December 1999
section.
contact sales or
our
