Please read this entire manual before installation. Save these instructions.
SAFETY NOTICE
CAUTION: HOT WHILE IN OPERATION. KEEP CHILDREN,
CLOTHING AND FURNITURE AWAY. CONTACT MAY
CAUSE SKIN BURNS.
IF THIS HEATER IS NOT PROPERLY INSTALLED,
A HOUSE FIRE MAY RESULT.
CONTACT LOCAL BU ILDING OFFICIALS ABOUT RE-
STRICTIONS AND INSTALLATION INSPECTION REQUIRE-
MENTS IN YOUR AREA.
FAILURE TO COMPLY WITH OWNERS' MANUAL IN-
STRUCTIONS WILL VOID YOUR WARRA NTY!
NOTE: This heater should not be installed in a
bedroom or bathroom.
INSTALLER: PLEASE LEAVE THIS MANUAL WITH THE OWNER!!
Sierra Products, Inc.
5061 Brooks St., Ste B
Montclair, CA 91763
(909) 399-3355
EF4001B AutoLite Pellet Stove Insert
Installation & Operating Instructions
PLEASE READ THIS ENTIRE MANUAL BEFORE INSTALLATION
AND USE OF THIS PELLET FUEL-BURNING ROOM HEATER.
FAILURE TO FOLLOW T HESE IN STRUCTION S COU LD RESULT IN
PROPERTY DAMAGE, BODILY INJURY OR EVEN DEATH.
GENERAL INFORMATION
Installation and repair should be done by a qualified
service person. The heater should be inspected before use
and at least annually by a professiona l service person. More
frequent cleaning m ay be re quired due to fuel quality,
excessive lint from carpetin g, bedding m ate rial, etc . It is
impera tive that control com partm ents , burn pot and c irculat-
ing air passageways of the heater be kept clean.
The EASYFIRE Pellet Insert has been designed and
approved for burning w oo d pellet fu el on ly. Bu rning solid
fuel in other forms is not permitted and will void all warran-
ties.
This unit has been approved for use with a Ø 3" Type L
Pellet Vent System or Stainless Chimney Liner (Ø 4" on
runs 10 fee t and above).
NEVER use gasoline, gasoline-type lantern fuels,
kerosene, charcoal lighter fluid, or similar liquids to start or
"freshen up" a fire. Keep all such liquids well away from the
heater while it is in use.
Ashes must be disposed of in a metal container with a
tight fitting lid and placed on a noncombustible floor or
ground, we ll away from all fu els, pending fina l disposal.
NOTE : During the first few burns the high tem perature
paint and sealant used in manufacture will emit some odor
and smoke. Open doors and windows to the outside for
proper ventilation during the first burn cycle and curing of
the paint.
This heate r, when insta lled, m ust be electrically gro unded in
accordance with local codes or, in the absence of local
codes, with the National Electrical Code, ANSI/NFPA 70-
2006.
Listed by OMNI-Test
Laboratories, Inc.
Report No. 256-S-01-4
Advertisement
Table of Contents
Related Manuals for Sierra Products EF-4001B AutoLite
Summary of Contents for Sierra Products EF-4001B AutoLite
-
Page 1: General Information
STRUCTIONS WILL VOID YOUR WARRA NTY! NOTE: This heater should not be installed in a bedroom or bathroom. INSTALLER: PLEASE LEAVE THIS MANUAL WITH THE OWNER!! Sierra Products, Inc. 5061 Brooks St., Ste B Montclair, CA 91763 (909) 399-3355 EF4001B AutoLite Pellet Stove Insert Installation &... -
Page 2: Installation Instructions
The heater may be installed as a free-stan ding unit m oun t- ed on a noncombustible protective floor pad or he arth, o r it may be m oun ted into an existing U. L. approved wood stove chimney using a Hearth Extension (p/n 11099). Non-combu- stib le floor protection is required and must be used when placing the heater on any com bustib le m ate rial. - Page 3 Figure 3 3. If the hearth and fireplace floor are not at the same elevation, leveling legs may be installed on the rear of the unit (Figure 4) for distances of up to 1". For larger distances shimm ing may be used using a non-com bustib le m ate rial.
-
Page 4: Door Handle Assembly
DOOR HANDLE ASSEMBLY The door handle and latch must be assembled and adjusted prior to the operation of the stove. 1. Position hand le ass em bly through d oor a nd s ecu re with collar by sliding over shaft and tightening with allen wrench provided. -
Page 5: Canadian Requirements
If your house power is out the AutoLite system will not be able to start the stove whe n the therm osta t calls for hea t. However if the stove is operating when the power goes out the stove will not shut down operating on the backup battery. -
Page 6: General Warnings
FUEL SELECTION Proper fue l selection is im portant for overall operation. Your stove operates best with 1/4" diam eter wood pe llets that are no longer than 3/4" long. The pellets should be specifically manufactured for use pellet heaters. Use of fuel non- conforming fue l will cause the sto ve to operate erratica lly. -
Page 7: Maintenance Procedure
Me dium is bes t for sta rt up) a nd turn the therm osta t up to “Ca ll for heat”. The stove fan will beg in to op erate along with the ignitor cycle. A fter ab out a m inute th e pellets w ill begin to fall in the burn pot. -
Page 8: Troubleshooting Guide
run the fan in the CLEAN OUT position with the door open for approximately one minute or until ash is no longer being picked up by the fan. Remem ber, you must always check the clean out cap on the tee after utilizing the CLEAN OUT feature. - Page 9 HI TEMP/FLUE AND TRIM INDICATORS: W hen the H i-Tem p/Flue indicator light com es o n (red lite beneath control button) it means that the flue is obstructed or you have a re verse draft and gases cannot ex it properly. Maintenance is required and a thorough cleaning and pipe check m ust be performed.
- Page 10 Note: Caution must be taken when installing burn pot or operating door not to damage ceramic glass. Do not attempt to operate he ater if glas s be comes d am aged in any w ay! 2. Control Functions: Control functions on the Eas yfire are as follows: OFF, FAN, LOW , MEDIUM, HIGH, CLEAN.
- Page 11 Front ash access panel Figure 15 d. The clean-out port cover should be removed and the vent pipe checked every four to six weeks or whenever you utilize the clean-out mode on the control dial. e. Fly-ash can also accumulate in the vent pipe and term ination cap .
- Page 12 deactivate the timer you will have to start over by turning the knob to off and then back to FAN or LOW. The EASYFIRE will automatically switch to 12 volt backup provided you have the 12 volt option installed. 2. Pro blem: The heater was lit and burning properly, then suddenly it stopped feeding pellets.
- Page 13 ITEM No. PART NUMBER 110429 100119 100125 300536 300106 120114 110080 110510 200549 110456 110451 120117 300512 120120 120118 110058 10407 DESCRIPTION DOOR FRONT GLASS (Ceramic glass 11"x11 3/4"x5mm) GLASS FIBER GASKET DOOR FIBER ROPE GASKET FEED AUGER SYSTEM V3 COMBUSTION BLOWER ASSEMBLY CONTROL BOARD V2.1 MAIN FUSE - 1 AMP...
