Cooler Location; Filling With Water - Honeywell CL603AE User Manual

Portable evaporative air cooler


Table of Contents


Make sure to position the air cooler correctly before you set up and start using the product. Please
refer to the COOLER LOCATION section of the separate Safety & Maintenance Guide.


It is ideal to use the Continuous Water Supply Connection to run the unit for long periods of time
without refilling the tank. This also helps prevent pump failure in case the cooler is running with
inadequate water in the tank.
CAUTION: Unplug the unit from the electrical socket before emptying or refilling the water tank.
Open the Water Fill Door located on the side of the unit.
Continuous Water Supply Connection:
For a continuous water supply, you will need a garden hose that is connected to a mains water supply.
Locate the male connector at one end of the garden hose. Insert the
garden hose connector into the water inlet valve of the cooler. Screw
and tighten the water inlet valve onto the threaded part of the garden
hose connector, making sure the hose connector is secured to
ensure there will be no leaks. If there is a leakage, the hose and the
water inlet valve may not be connected properly. Try to disconnect,
replace and tighten the water inlet valve again.
When the connection is secured, turn ON the water supply and the
water will flow into the water tank of the cooler.
The cooler is now set so the water refills automatically when the
water tank is empty, or when the water reaches below a minimum
When the water tank is full of water, the water inlet valve will
auto-matically stop the water supply from overflowing the water
WARNING: The maximum water inlet pressure is 0.5 MPa.
Fill Door
Water inlet valve
Garden Hose
