INSTALLATION INSTRUCTIONS
ECA 120 VZ
Ventilation of pantries and cellars
For regular ventilation of rarely used rooms, we would recommend the ECA ... I or ECA ... KI with interval control.
The time interval can be set individually, the operating period is 10 minutes.
1 AP shutter
2 WH wall sleeve
3 ECA ... I small room fan
4 MLK Door ventilation grille
Barrier-free ventilation of bathrooms
The small room fans ECA piano H, ECA ... F and ECA ... KF switch on and off automatically depending on air humidity and/or
brightness levels. Switches do not have to be operated.
