- Page 1 Anticimex Smart Connect system Manual Version 1 - 01.02.2018 Substitutes: Wise-I Mini guide Version 6 - May 2016...
-
Page 2: Compliance Statement
(2) this device must accept any interference received, including interference that may cause undesired operation. Information to user The Smart Connect, Smart Eye and Smart Catch are only in compliance if no changes or modifications is made to the device. The Smart Connect, Smart Eye and Smart Catch are in compliance with the requirement for RF exposure in US with 20 cm separation distance between the user and/or bystander of the device. - Page 3 Note: This equipment has been tested and found to comply with the limits for Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
-
Page 4: Table Of Contents
2.2.1 General 2.2.2 Smart Catch 6 2.2.3. Smart Eye 2.3 Check the Smart Connect devices signal strength 6 2.4 Unlink Smart Connect devices from the Smart Connect 6 03 Handling and maintenance 3.1 Battery change 7 3.2 Emptying the trap 3.3 Clean the sensors on Smart Catch... -
Page 5: Run Mode And Service Mode
1.1 Service mode: a. The first time a Smart Connect is started up it will automatically be in Service mode. b. Service mode is used when Smart Connect devices need to be linked to the system, removed from the system or when the signal quality should be tested. c. When the system is in Service mode the Smart Connect devices use more battery, because they report to the Smart Connect every 5 minutes. -
Page 6: Link Smart Connect Devices To The Smart Connect
The device is linked now. 2.3 Check the Smart Connect devices signal strength a. When the installation is in Service Mode, use the arrow keys on the Smart Connect until you find ”LQI mode”. Press b. The Smart Connect counts down until the Smart Connect devices are awakened and will be in LQI-mode. -
Page 7: Handling And Maintenance
Repeat if more Smart Connect devices should be unlinked. d. When you are finished unlinking press The Smart Connect synchronizes with WisePlan and removes the selected devices. When the Smart Connect is ready the display shows Service mode. 03 Handling and maintenance 3.1 Battery change The batteries must be changed once a year regardless of whether WisePlan show low batteries. -
Page 8: Explanation Of Led Lights
Smart Catch lure box and/or lower flashes when pressing shield is missing. Good signal – the Smart Connect flashes constantly. device can be installed. LQI-mode Not enough signal – the Smart Connect No light. device cannot be installed here. Smart Connect device must be flashes. updated. Update flashes in staggered pace. -
Page 9: Troubleshooting
Smart Connect, and linked again. See descriptions of link and unlink on page 6. If the Smart Connect has lost all contact with the device. The device can be unlinked from the installation. The Smart Connect will not be able to contact the device that does not respond, but after having tried for 2 minutes the device will be automatically unlinked. -
Page 10: Glossary
The operating mode of a Smart Connect system. Service mode Disable traps and sensors, but allows link, unlink and LQI. Smart Device is a common name for the Smart Catch and Smart Eye. Connect device Unlink-mode Used when one or more Smart Connect devices have to be removed from the installation. - Page 11 Anticimex Innovation Center +45 48 79 93 78 AIC@anticimex.com...
