  • Page 1 CCTV Products & Accessories Catalogue 2008 Building Technologies...
  • Page 3: Table Of Contents

    Table of Contents © Siemens Building Technologies Group Cameras and Domes... 1-1 Cameras Overview ... 1-2 Monochrome Cameras... 1-4 Colour Cameras ... 1-6 Day-Night Cameras ... 1-14 Camera Mounts ... 1-20 Fixed Domes Overview... 1-22 Fixed Domes... 1-24 Speed Domes Overview ... 1-35 Functional Domes...
  • Page 4 Video Software ... 13-1 System Diagrams... 14-1 Hints and Tips ... 15-1 Glossary ... 16-1 TFT Monitors Overview ... 12-2 CRT Monitors Overview ... 12-3 Monochrome Monitors ... 12-4 Colour Monitors ... 12-5 LCD-Displays ... 12-7 Monitor Mounts... 12-11 IVM Software ... 13-2 SISTORE MX NVS Network Video Software ...
  • Page 5: Cameras And Domes

    Only a camera optimally adjusted to prevailing light conditions can deliver clear, crisp images. Siemens has met this challenge at the highest level and created a range of cameras and fixed domes to cover all customer needs. The cameras have...
  • Page 6: Cameras Overview

    Cameras and Domes Cameras Overview © Siemens Building Technologies Group...
  • Page 7 Cameras and Domes Cameras Overview © Siemens Building Technologies Group...
  • Page 8: Monochrome Cameras

    Selectable (ON/OFF); up to 49 win- dows 24 characters CS (C-mount adapter supplied) Direct drive or Video drive 74 x 60 x 125 mm 12 V DC / 24 V AC‚ 50 Hz 0.40 kg © Siemens Building Technologies Group...
  • Page 9 24 V AC As CCBB1345.. for technical details‚ but with the following differences: Television standard Pixels Electronic shutter Power requirements Weight © Siemens Building Technologies Group Order No. 2GF1081-8EA CCIR: 625 lines‚ 50 fields/s‚ 50 Hz (vertically)‚ 15.625 Hz (horizontally) Internal: crystal...
  • Page 10: Colour Cameras

    Off: 1/50 s Selectable (ON/OFF)‚ up to 49 windows 24 characters CS (C-mount adapter supplied) Direct drive or Video drive 74 x 60 x 125 mm 12 V DC / 24 V AC‚ 50 Hz 0.45 kg © Siemens Building Technologies Group...
  • Page 11 1/3" DSP Colour OSD Camera 330 TVL‚ PAL‚ 90 V AC D 260 V AC As CCBC1320.. for technical details‚ but with the following differences: Power requirements Weight © Siemens Building Technologies Group Order No. CCBC1320.. PAL: 625 lines‚ 50 fields‚...
  • Page 12 1/10‚000 s‚ Auto: AES 1/50 to 1/100‚000 s 70 x 58 x 117 mm 3.8 W 2GF1183-8BA 12 V DC / 24 V AC‚ 50 Hz 0.60 kg 2GF1183-8DA 90 V AC D 260 V AC‚ 50 Hz 0.70 kg © Siemens Building Technologies Group...
  • Page 13 1/3" DSP Colour DIP Switch Camera 540 TVL‚ PAL‚ 90 V AC D 260 V AC As CCBC1337.. for technical details‚ but with the following differences: Power requirements Power consumption Weight © Siemens Building Technologies Group Order No. 2GF1183-8BB NTSC: 525 lines‚ 60 fields‚ 60 Hz (vertically)‚...
  • Page 14 NTSC: 525 lines‚ 60 fields‚ 60 Hz (vertically)‚ 15‚734 Hz (horizontally) 768 (H) x 494 (V) Automatic: 1/60 s - 1/100000 s Off: 1/60 s 12 V DC / 24 V AC‚ 60 Hz 0.45 kg © Siemens Building Technologies Group...
  • Page 15 500 TVL‚ PAL/NTSC‚ 90 D 260 V AC As CCWC1345.. for technical details‚ but with the following differences: Power requirements Power consumption Weight © Siemens Building Technologies Group Order No. CCWC1345.. PAL: 2:1 interlace V: 50 Hz‚ H: 15.625 Hz NTSC: 2:1 interlace V: 59.94 Hz‚...
  • Page 16 Optical zoom x22‚ digital zoom x11 (video AF) 3.9 D 85.8 mm F1.6 (wide) D F3.7 (tele) x2 D x60 52 dB (AGC off) -10° C to +50° C 6.5 W 120 x 120 x 185 mm 1.50 kg © Siemens Building Technologies Group...
  • Page 17: Camera Features

    Camera features… Slow / fast shutter speed Too bright Too dark Perfect view with Wide Dynamic On Menu allows programming of six different modes of back light compensation …for all applications. SHUTTER 1/50 SYNC LEVEL IRIS LEVEL CONFIGURE CAM TITLE TITLE WHITE BAL ATW/MTW/SET...
  • Page 18: Day-Night Cameras

    49 windows 880 nm‚ monochrome mode 24 characters CS (C-mount adapter supplied) Direct drive or Video drive 74 x 60 x 125 mm 12 V DC / 24 V AC‚ 50 Hz 0.45 kg © Siemens Building Technologies Group...
  • Page 19 1/3" DSP Day-Night OSD Camera 540 TVL‚ PAL‚ 90 V AC D 260 V AC As CCBS1337.. for technical details‚ but with the following differences: Power requirements Weight © Siemens Building Technologies Group Order No. CCBS1337.. PAL: 625 lines‚ 50 fields/s‚...
  • Page 20 72 x 63 x 122 mm 5 W‚ 8 W (incl. IR-cut filter move- ment) 2GF1183-8FC 12 V DC / 24 V AC‚ 50 Hz 0.45 kg 2GF1183-8FB 90 V AC to 260 V AC‚ 50 Hz 0.55 kg © Siemens Building Technologies Group...
  • Page 21 480 TVL‚ PAL‚ 90 D 260 V AC‚ 50 Hz As CCBS1345.. for technical details‚ but with the following differences: Power requirements Power consumption Weight © Siemens Building Technologies Group Order No. CCBS1345.. PAL: 625 lines‚ 50 fields/s‚ 50 Hz (vertically)‚...
  • Page 22 Optical zoom x22‚ digital zoom x11 (video AF) 3.9 D 85.8 mm F1.6 (wide) D F3.7 (tele) x 2 D x 60 52 dB (AGC off) -10° C to +50° C 120 x 120 x 185 mm 1.50 kg © Siemens Building Technologies Group...
  • Page 23 “All-in-one” auto focus camera ...out of the box and ready to mount. Up to 22x optical zoom...
  • Page 24: Camera Mounts

    Grey (RAL7032) Approx. 2 kg 54 x 210-310 mm 0.21 kg 2GF1710-8AR Ceilling Grey (RAL7032) Approx. 2 kg 54 x 210 mm 0.44 kg 2GF1710-8AS Grey (RAL7032) Approx. 2 kg 54 x 210-310 mm 0.44 kg © Siemens Building Technologies Group...
  • Page 25 Easily adjusted‚ heavy-duty camera mount suitable for wall or ceiling mounting of cameras. Colour Installation Load rating Arm length Weight © Siemens Building Technologies Group Order No. 2GF1710-8BD Wall or ceiling Silver and black Epoxy powder-coat 56 x 140 mm 0.25 kg...
  • Page 26: Fixed Domes Overview

    Cameras and Domes Fixed Domes Overview 1-22 © Siemens Building Technologies Group...
  • Page 27 Cameras and Domes Fixed Domes Overview © Siemens Building Technologies Group 1-23...
  • Page 28: Fixed Domes

    0.29 kg 2GF1084-8AC CCIR: 625 lines‚ 50 fields‚ 50 Hz (vertically)‚ 15.625 Hz (horizontally) 500 (H) x 582 (V) 2GF1084-8AD EIA: 525 lines‚ 60 fields‚ 60 Hz (vertically)‚ 15.734 Hz (horizontally) 510 (H) x 492 (V) © Siemens Building Technologies Group...
  • Page 29 1/3" CCD 3.7 mm Monochrome Fixed Dome 580 TVL‚ EIA‚ 12 V DC / 24 V AC As CFFB1315.. for technical details‚ but with the following differences: Television standard Pixels © Siemens Building Technologies Group Order No. CFFB1315.. 580 TV lines 0.2 Lux (F2.0 @50IRE) AGC (ON/OFF) >...
  • Page 30 0.56 Lux (F2.0 @50IRE) AGC (ON/OFF) Autom 1/50 to 1/100K s Clear (ON/OFF) 2-pin (1 m cable included) > 50 dB Auto 112 x 97.5 mm 12 V DC / 24 V AC 3.5 W 0.29 kg © Siemens Building Technologies Group...
  • Page 31 1/4" CCD 2.8-5.8 mm Monochrome Varifocal Dome 580 TVL‚ EIA‚ 12 V DC / 24 V AC As CFVB1415.. for technical details‚ but with the following differences: Television standard Pixels © Siemens Building Technologies Group Order No. 2GF1184-8AA PAL: 625 lines‚ 50 fields‚ 50 Hz (vertically)‚...
  • Page 32 0.29 kg 2GF1184-8AE PAL: 625 lines‚ 50 fields‚ 50 Hz (vertically)‚ 15.625 Hz (horizontally) 752 (H) x 582 (V) 2GF1184-8AF NTSC: 525 lines‚ 60 fields‚ 60 Hz (vertically)‚ 15.734 Hz (horizontally) 752 (H) x 582 (V) © Siemens Building Technologies Group...
  • Page 33 1/4" CCD 2.8-5.8 mm‚ Day-Night Varifocal Dome‚ 480L‚ NTSC‚ 12 V DC / 24 V AC As CFVS1415.. for technical details‚ but with the following differences: Television standard Pixels © Siemens Building Technologies Group Order No. CFVS1415.. 480 TV lines Colour: 0.34 Lux (F1.4 @50IRE) Mono: 0.15 Lux (F1.4 @50IRE)
  • Page 34 1.7 kg 2GF1085-8AC CCIR: 625 lines‚ 50 fields‚ 50 Hz (vertically)‚ 15.625 Hz (horizontally) 752 (H) x 582 (V) 2GF1085-8AD EIA: 525 lines‚ 60 fields‚ 60 Hz (vertically)‚ 15.734 Hz (horizontally) 768 (H) x 494 (V) © Siemens Building Technologies Group...
  • Page 35 1/3" CCD Colour Vandal Resistant Varifocal Dome‚ 480 TVL NTSC‚ 12 V DC / 24 V AC As CVVC1315.. for technical details‚ but with the following differences: Television standard Pixels © Siemens Building Technologies Group Order No. CVVC1315.. 480 TV lines 0.47 Lux (F1.0 @50IRE) AGC (ON/OFF) >...
  • Page 36 1.70 kg 2GF1185-8AE PAL: 625 lines‚ 50 fields‚ 50 Hz (vertically)‚ 15.625 Hz (horizontally) 752 (H) x 582 (V) 2GF1185-8AF NTSC: 525 lines‚ 60 fields‚ 60 Hz (vertically)‚ 15.734 Hz (horizontally) 768 (H) x 494 (V) © Siemens Building Technologies Group...
  • Page 37 S/N ratio Operating temperature range Dimensions (Ø x H) Power requirements Power consumption Weight © Siemens Building Technologies Group Order No. 2GF1182-8AM 795 (H) x 596 (V) 1/4" SONY Super HAD CCD Internal: crystal/external: Line Lock 1.0 lux @ F=1.6 (AGC on‚...
  • Page 38 Vandal dome features… Day-night model automatically changes from colour pictures by day, to monochrome images at night – true 24 hour surveillance! 36° 91° Greater viewing angle for colour and mono models Remote setup for both day-night and colour models …for varying applications.
  • Page 39: Speed Domes Overview

    Cameras and Domes Speed Domes Overview © Siemens Building Technologies Group 1-35...
  • Page 40: Functional Domes

    The dome accommodates a variety of protocols‚ including the Siemens protocol. The dome is available as a simple colour camera‚ light-sensitive low-light camera or flexible‚ day-night camera with 18 x and 26 x optical zoom and 480 TV lines resolution‚...
  • Page 41 1/4'' CCD High-Speed Day-Night Dome‚ 480 TVL‚ PAL‚ Indoor 24 V AC As CCDA1435.. for technical details‚ but with the following differences: Lens Minimum illumination Zoom © Siemens Building Technologies Group Order No. 2GF1193-8AA 1.0 lux (F1.4‚ 1/50s) 2GF1193-8AB 0.7 Lux (F1.4‚ 1/50s) 0.05 Lux (F1.4‚...
  • Page 42 Cameras and Domes Functional Domes 1-38 © Siemens Building Technologies Group...
  • Page 43 Night‚ Clear Bubble‚ IP67‚ Supplied with 110 D 230 V AC XTU As CCDS1415.. for technical details‚ but with the following differences: Minimum illumination Lens Weight © Siemens Building Technologies Group Order No. CCDS1415.. PAL: 625 lines‚ 50 fields‚ 50 Hz (vertically)‚...
  • Page 44 As CCDS1415.. for technical details‚ but with the following differences: Minimum illumination Lens Weight 1-40 Order No. 2GF1194-8AD 0.05 lux (colour) 0.01 lux (mono) 26 x optical‚ 12 x digital 3.5 mm to 91 mm (F1.6 to F3.8) 5.6 kg © Siemens Building Technologies Group...
  • Page 45: Dome Mounts And Accessories

    Replacement Lens 3.7 mm for CF Series Weight CFFA-IC60 Replacement Lens 6.0 mm for CF Series Weight CFFA-IC12 Replacement Lens 12 mm for CF Series Weight © Siemens Building Technologies Group Order No. 2GF1086-8AA 0.05 kg 2GF1086-8AG 0.05 kg 2GF1086-8AH 0.05 kg CFFA13..
  • Page 46 12 V DC only! Dimensions (Ø x H) Weight 1-42 Order No. 2GF1086-8AM 225 x 120 mm 1.30 kg 2GF1086-8AN 0.50 kg 2GF1086-8AP 140 x 35.3 mm 0.40 kg © Siemens Building Technologies Group...
  • Page 47 Picture format Network connections Security Protocols Installation Weight Power requirements Power consumption © Siemens Building Technologies Group Order No. 2GF1086-8AL QCIF (176 x 144) CIF (352 x 288) 4CIF (704 x 576) (interlaced) 10baseT Ethernet or 100baseTX Fast Ethernet‚ auto-sensing‚...
  • Page 48 0 D 90% 4.0 kg 2GF1192-8BB -20° C to +60° C 0 D 90% 165 x 228 mm 1.20 kg 2GF1192-8BC -20° C to +60° C 0 D 90% 177 x 232 mm 1.40 kg © Siemens Building Technologies Group...
  • Page 49 CCDA1425-WPH/-VRH. Storage temperature Relative humidity Dimensions (W x H x D) Weight © Siemens Building Technologies Group Order No. 2GF1192-8BD -20° C to +60° C 0 D 90% 180 x 240 x 60 mm 0.8 kg...
  • Page 50 -20° C to +60° C 0 D 90% 62 x 535 mm 1.0 kg 2GF1192-8BH -20° C to +60° C 0 D 90% 180 x 210 x 308 mm 1.0 kg 2GF1192-8BK 0.30 kg 2GF1192-8BL 0.30 kg © Siemens Building Technologies Group...
  • Page 51 The Solaris Dummy Dome looks just like the real thing. It is an ideal‚ low- cost solution wherever offenders are to be discouraged and where vid- eo information is not actually required. Dimension (Ø x H) Weight © Siemens Building Technologies Group Order No. 2GF1192-8BM 0.60 kg 2GF1192-8CB 220 mm x 110 mm -20 D +60 °C...
  • Page 52 This corner mount adapter can be used to fix the wall mount CCDS1415-WM on a right angled wall corner. Weight 1-48 Order No. 2GF1194-8BB 4.0 kg 2GF1194-8CD 2.0 kg 2GF1194-8CB 126 x 530 mm 2.0 kg 2GF1194-8CC 6.10 kg 2GF1194-8CE 5.0 kg © Siemens Building Technologies Group...
  • Page 53 The RTU allows the XTU to be installed at a distance of up to 300 m from the dome camera. Dimensions (W x H x D) Input voltage Weight © Siemens Building Technologies Group Order No. 2GF1194-8CF 216 x 103 mm 1.0 kg...
  • Page 54 Incl. bubble: 400 x 405 mm Polyester powder coated white 1.25 kg 2GF1194-8BJ Excl. bubble: 300 x 405 mm Incl. bubble: 400 x 405 mm Polyester powder coated unpainted 1.25 kg 2GF1194-8BL 360 mm x 12 mm 0.50 kg © Siemens Building Technologies Group...
  • Page 55 Screw the base to the wall, connect the terminals and “snap” in the housing – simple! Reliable performance with 52 zone black mirror optics filtering white light interference – combining world beating intrusion technology with high quality CCTV camera images from Siemens...
  • Page 56: Pir Cameras

    CCIR‚ 12 V DC The discrete‚ high-quality monochrome camera with a working PIR in a standard Siemens detector housing is suitable for installations requir- ing CCTV surveillance and reliable motion detection. The detection range of the PIR has the same surveillance range as the camera - ideal for remote transmission systems.
  • Page 57 1/3" CCD Colour Camera 380 TVL with PIR-Detector‚ PAL‚ 12 V DC The discrete‚ high-quality colour camera with a working PIR in a stand- ard Siemens detector housing is suitable for installations requiring CCTV surveillance and reliable motion detection. The detection range of the PIR has the same surveillance range as the camera - ideal for remote transmission systems.
  • Page 58: Ip Camera Overview

    Cameras and Domes IP Camera Overview 1-54 © Siemens Building Technologies Group...
  • Page 59: Ip Cameras

    Tripod thread Dimensions (W x H x D) Operating temperature range Weight Power requirements Power consumption © Siemens Building Technologies Group Order No. 2GF1186-8AB PAL: 625 lines‚ 50 fields‚ 50 Hz (ver- tically)‚ 15.625 Hz (horizontally) 1/3-inch interline CCD 752 (H) x 582 (V)
  • Page 60 ARP‚ BOOTP/DHCP‚ TCP/IP‚ HTTP‚ ICMP‚ SNMP‚ FTP and DNS IP address configurable via ARP‚ BOOTP/DHCP‚ connection to twist- ed-pair RJ45 Ethernet. 0.62 kg 12 V DC or 24 V AC‚ 50 Hz © Siemens Building Technologies Group...
  • Page 61 CCIx1345.. 1/3" Super High Resolution MJPEG / MPEG-4 IP Streaming Cameras The CCIx1345 range is a true CCTV IP Security Camera range that com- bines the requirements of classic analogue CCTV cameras with the high performance‚ flexibility and IT-security of a modern Video-over-IP device.
  • Page 62 Mono: 0.1 lux at F=1.2 (AGC on‚ 50 IRE video) 0.01 lux at F=1.2 (AGC on‚ 50 IRE video‚ IR-Illumination) Selectable: OFF‚ ON Selectable: OFF‚ ON (AE mode) In night mode: 850-1000 nm Normal operation 7.0 W © Siemens Building Technologies Group...
  • Page 63: Accessories Cameras And Domes

    3 power clips for control lines and video test connector (BNC)‚ fitted in a weatherproof plastic housing. Power supply not included. Connections Protection rating Weight © Siemens Building Technologies Group Order No. 2GF1800-8BE 230 V AC‚ 50 Hz 12 V DC‚ 640 mA Input: European plug‚...
  • Page 64 Power requirements Protection rating Weight 1-60 Order No. 2GF1086-8AJ BPZ:80-194 230 V AC 12 V DC‚ 500 mA 0.52 kg BPZ:80-223 100 D 240 V AC‚ 50/60 Hz‚ 300 mA Indoor use only 1.30 kg © Siemens Building Technologies Group...
  • Page 65: Lenses

    The front of any CCTV system is a lens, often overlooked but a very important part of any system… Provide the right view in a variety of security surveillance situations with these professional lenses that are easy to adjust. Focal-length and focus adjustments have screw-locks to ensure views remain as initially set.
  • Page 66: Fixed Focal Length Lenses

    2.8 mm F1.4 95.6º 0.2 m Adjustable 1/3" CS-mount 0.0545 kg 2GF1661-8AM 4.0 mm F1.2 70.6º 0.25 m Adjustable 1/3" CS-mount 0.0504 kg 2GF1661-8AN 6.0 mm F1.2 48.1° 0.3 m Adjustable 1/3" CS-mount 0.0417 kg © Siemens Building Technologies Group...
  • Page 67 Weight CLFD1314/2.8 2.8 mm F1.4‚ 1/3" CS Focal length Maximum relative aperture Horizontal angle of view Minimum object distance Format Weight © Siemens Building Technologies Group Order No. 2GF1661-8AP 8.0 mm F1.2 36.5º 0.3 m Adjustable 1/3" CS-mount 0.0411 kg 2GF1661-8AQ 16.0 mm...
  • Page 68 0.0644 kg 2GF1663-8AQ 6.0 mm F1.2 48.1° 0.3 m 1/3" CS-mount 0.0498 kg 2GF1663-8AR 8.0 mm F1.2 36.5º 0.3 m 1/3" CS-mount 0.0495 kg 2GF1663-8AS 16.0 mm F1.6 17.6° 0.7 m Adjustable 1/3" CS-mount 0.0475 kg © Siemens Building Technologies Group...
  • Page 69: Varifocal Length Lenses

    7 D 70 mm F1.8 1/3" CS Format Focal length Focus type Maximum relative aperture Horizontal angle of view Minimum object distance Weight © Siemens Building Technologies Group Order No. CLVM13.. 2GF1664-8AG 1/3" CS-mount 3.5 D 8 mm Adjustable F1.4 35 D 73.8°...
  • Page 70 0.0805 kg 2GF1667-8AU 5 D 50 mm Adjustable F1.4 D C 5.6 D 53.6° 0.3 m 0.20 kg 2GF1667-8AL 1/3" CS-mount 7 D 70 mm Adjustable 4.2 D 40.1° 0.3 D 1.0 m 0.2015 kg © Siemens Building Technologies Group...
  • Page 71 3 D 8 mm F1.0 1/3" VF‚ AS‚ IR Format Focal length Horizontal angle of view Maximum relative aperture Minimum object distance Weight © Siemens Building Technologies Group Order No. CLVD1318.. 2GF1651-8AB 1/2" CS-mount Adjustable 4 D 12 mm 31.2 D 93.6°...
  • Page 72 Order No. 2GF1667-8AR 1/3" CS-mount 2.8 D 11 mm 26.2 D 97.4° F1.4 D 360 0.3 m 0.087 kg 2GF1667-8AS 1/3" CS-mount 10 D 40 mm 7.0 D 27.5° F1.4 D 360 0.5 m 0.077 kg © Siemens Building Technologies Group...
  • Page 73: Zoom Lenses

    Auto-Iris‚ Direct Drive 6 D 72 mm F 1.2 1/3" CS Format Focus type Focal length Horizontal angle of view Minimum object distance Weight © Siemens Building Technologies Group Order No. 2GF1666-8AD 1/3" CS-mount 6 D 72 mm Adjustable 43.7°...
  • Page 74 Access control rights allow you in, then the CCTV cameras trigger to start recording as you walk through, the PIR zones are also deactivated in just the area you have access – all displayed and controlled via one screen. www.siemens.com/interoperability...
  • Page 75: Housings And Mounts

    Housings and Mounts For all seasons, a range of camera housings… A complete range of IP66 camera housings together with a full range of accessories, brackets and spare parts tailored to the customer’s need. All of these items adhere to high quality and reliability standards to support a safe and easy installation. High performance aluminium camera housings complete with sunshield.
  • Page 76: Outdoor Housings

    A stylish-looking‚ general purpose aluminium camera housing com- plete with anti-reflective ABS polymer sunshield‚ plexi-glass face-plate with polycarbonate front and rear. Ideal for any Siemens camera fitted with any Siemens monofocal or varifocal lens. Three cable entries pro- vide for power‚ video‚ control cable (RS485 for camera etc.) or system cable.
  • Page 77 Cable entry Finish Colour Protection rating Dimensions (W x H x D) Weight © Siemens Building Technologies Group Order No. 2GF1705-8EA 110 D 265 V AC‚ 7 W 16° C ± 3° C 20° C ± 3° C 2 x PG9‚ 1 x PG16 Centre section: extruded and die- cast aluminium‚...
  • Page 78 125 x 100 x 400 mm Aluminium extrusion (housing body & sunshield)‚ glass filled polyester thermoset (front & rear caps) 14 °C 20 °C 7 Watt nominal‚ 25 Watts max. PTC resistor heating element. IP66 6.0 kg © Siemens Building Technologies Group...
  • Page 79 Usable volume (W x H x D) Finish Heater turn-on Heater turn-off Heater rating Protection rating Weight © Siemens Building Technologies Group Order No. BPZ:80-143 24 V AC‚ 50/60 Hz Housing body: Polyester powder- coat RAL7032 leatherette full gloss. Sunshield: Polyester powdercoat hipca white smooth full gloss.
  • Page 80 Bracket: 133 x 194 x 169 mm 85 x 80 x 225 mm Pressure die-cast aluminium with extruded aluminium body and sun- shield. 14 °C 20 °C 7 W nominal‚ 25 W max. PTC resistor heating element. IP67 3.54 kg © Siemens Building Technologies Group...
  • Page 81 Usable volume (W x H x D) Finish Heater turn-on Heater turn-off Heater rating Protection rating Weight © Siemens Building Technologies Group Order No. BPZ:80-153 230 V AC‚ 50/60 Hz Housing Body: Polyester Powder- coat RAL7032 Leatherette Full Gloss. Sunshield: Polyester Powder- coat Hipca White Full Gloss.
  • Page 82: Housing Mounts

    227 x 75.4 x 86 mm Silver (RAL9006) Epoxy powder-coat 25 kg 2GF1705-8LG 120 x 130 x 215 mm Silver (RAL9006) Epoxy powder-coat 25 kg 1.1 kg 2GF1705-8LH 110 x 175 mm Silver (RAL9006) Epoxy powder-coat 25 kg 1.1 kg © Siemens Building Technologies Group...
  • Page 83 For installation of a protective housing on a horizontal or inclined sur- face‚ on a wall bracket or pole bracket. Dimensions (W x H x D) Colour Finish Load rating Weight © Siemens Building Technologies Group Order No. 2GF1705-8LJ 185 mm 121 x 121 x 185 mm Silver (RAL9006) Epoxy powder-coat 25 kg 1.0 kg...
  • Page 84 Off-white (RAL9002) Epoxy powder-coat 25 kg 0.63 kg GBQ:A5383520001 110 x 175 mm Off-white (RAL9002) Epoxy powder-coat 50 kg 1.28 kg BPZ:80-105 50 x 85 x 280 mm Max. Load 15 kg Die-cast aluminium 0.70 kg © Siemens Building Technologies Group...
  • Page 85 HS02B/L camera housing. The casting replaces the standard casting and is bought as an after market add-on. The bracket is suitable for indoor and outdoor use. Colour Finish Weight © Siemens Building Technologies Group Order No. BPZ:80-100 Polyester powdercoat RAL7032 leatherette full gloss 75 kg 10 SWG mild steel 1.70 kg...
  • Page 86: Spares Housings And Mounts

    Housings and Mounts Spares Housings and Mounts Type WI01AB WI01AB Spare Wiper Spare wiper arm and blade for HS01 and FH07 housings. Protection rating Weight 3-12 Order No. BPZ:80-242 IP66 0.1 kg © Siemens Building Technologies Group...
  • Page 87: Accessories Housings And Mounts

    12 V DC power to the camera. Dimensions (W x H x D) Input rating Output rating Heating connection Weight © Siemens Building Technologies Group Order No. 2GF1705-8GH 230 V AC ± 5% 9.6 VA 50 Hz 230 V AC ±...
  • Page 88 24 V AC‚ 400 mA 0.20 kg 2GF1705-8LC 0.03 kg 2GF1705-8GJ 0.11 kg 2GF1705-8GK 0.11 kg GBQ:A5572360001 20° C ± 3° C 14° C ± 3° C 110 D 230 V AC‚ 40 W 0.10 kg © Siemens Building Technologies Group...
  • Page 89 HS01 Super Connoisseur Wiper units. Power requirements Power consumption Protection rating Weight © Siemens Building Technologies Group Order No. GBQ:A5572490001 20° C ± 3° C 14° C ± 3° C 12 / 24 V DC‚ V AC‚ 20 W 0.10 kg...
  • Page 90 Speed domes… …for the best 360˚ view.
  • Page 91: Pan/Tilt And Telemetry Equipment

    Pan-tilt and Telemetry Equipment Telemetry equipment designed for buildings A complete range of telemetry receivers connecting to pan-tilt head devices, operat- ing at fixed or variable speeds and offering different maximum loads. The range is designed for both internal and external use. Models allow simple connection and control via matrix switching systems and keyboards, including setting and calling preset positions, and variable speed control.
  • Page 92: Pan/Tilt Telemetry Controller

    D) COM2 - RS485/TTY modified (9- pin Sub-D) 2-pin power supply con- nector Aluminium‚ painted RAL7016 with plastic side panels IP40 255 x 50 x 170 mm 12 to 13.2 V DC 2.4 W 0.90 kg © Siemens Building Technologies Group...
  • Page 93 The Visilynx keyboard gives operators the ability to select cameras and camera pre-set positions by meaningful names rather than meaningless numbers. Power requirements Weight © Siemens Building Technologies Group Order No. 2GF2400-8EC Variable speed joystick (3 axis)‚ 31 keys on keyboard 2 Line LCD display with backlight‚...
  • Page 94: Pan/Tilt Heads

    380 x 230 x 184 mm Over the top mount: 221 x 252 x 184 mm 7-pin plug (power supply) 48°/s 24°/s 16 kg (Over the Top) or 16 kg (Side mount) IP66 7.0 kg © Siemens Building Technologies Group...
  • Page 95 Pan speed Tilt speed Load rating Potentiometer on both axis Presets Protection rating Weight © Siemens Building Technologies Group Order No. BPZ:80-352 24 V AC Painted Polyester Powdercoat RAL7032 Leatherette Full Gloss Side mount: 380 x 230 x 184 mm...
  • Page 96 24 V AC 2 x 6.8 W 2GF1708-8EA 360° 32°/s ± 90° 16°/s 12 kg 13 pin / 24 pin 5 kOhm 50 positions C31 / RAL7032 (light grey) 6.50 kg IP66 24 V AC 90 W © Siemens Building Technologies Group...
  • Page 97: Pan/Tilt Telemetry Receivers/Drivers

    Telemetry formats Auxiliary contact rating Baud rate Data outputs (camera control) Presets Weight © Siemens Building Technologies Group Order No. S24245-B5015-A1 230 V AC / 115 V AC‚ 50/60 Hz 280 x 190 x 130 mm CKA3210‚ CKA4820‚ SIMATRIX IP66 TTY 20 mA‚...
  • Page 98 2 x 20 mm 3 x 13 mm At 25° C 30‚000 h 102 x 30 x 100 mm IP66 Controllers / matrix switchers with Molynx protocol -20° C to +40° C PCB: 0.80 kg Box: 1.50 kg © Siemens Building Technologies Group...
  • Page 99 MTBF Dimensions (W x H x D) Control functions Compatible with Operating temperature range Weight © Siemens Building Technologies Group Order No. BPZ:80-201 230 D 240 V AC‚ 50/60 Hz 20 W 230 V AC 102 x 30 x 100 mm C Type (Coax) or D Type (RS485‚...
  • Page 100 Controllers / matrix switchers with Molynx protocol -20° C to +40° C C Type (Coax) or D Type (RS485‚ Molynx protocol) At 25° C 30‚000 h 164 x 135 x 254 mm PCB: 0.50 kg BOX: 1.75 kg © Siemens Building Technologies Group...
  • Page 101 Control functions Compatible with Operating temperature range Telemetry formats MTBF Dimensions (W x H x D) Weight © Siemens Building Technologies Group Order No. BPZ:80-205 230 D 240 V AC‚ 50/60 Hz 20 W 24 V DC 9600 bps Controllers / matrix switchers with Molynx protocol -20°...
  • Page 102 230 V AC 9600 bps Controllers / matrix switchers with Molynx protocol -20° C to +40° C C Type (Coax) or D Type (RS485‚ Molynx protocol) At 25° C 30‚000 h 120 x 30 x 195 mm © Siemens Building Technologies Group...
  • Page 103: Pan/Tilt Mounts

    A heavy-duty bracket for fixing heavy housings and/or pan & tilts to a wall or other surface. Dimensions (W x H x D) Colour Load rating Finish Weight © Siemens Building Technologies Group Order No. 2GF1710-8AC Galvanized steel‚ painted Off-white (RAL9002) 60 kg 226 mm 250 x 290/430 x 530 mm 2.40 kg...
  • Page 104 40 kg Folded Stainless Steel with Stainless Steel Fasteners 2.0 kg BPZ:80-104 127 x 304.8 mm max. 100 kg Mild Steel 3.0 kg BPZ:80-102 127 x 152.4 mm max. 100 kg Mild Steel 2.0 kg © Siemens Building Technologies Group...
  • Page 105: Accessories Pan/Tilt And Telemetry Equipment

    (AC version). Weight P12C-DC6 Spare DC Connector for Pan-Tilt P25 A spare connector for pan-tilts with 7 female pins (DC power supply connector). Weight © Siemens Building Technologies Group Order No. BPZ:80-213 0.20 kg BPZ:80-212 0.20 kg BPZ:80-211 0.024 kg...
  • Page 106: Spare Parts Pan/Tilt And Telemetry Equipment

    A spare connector for pan-tilts with 7 female pins (AC power supply connector). Weight P00C-4F Spare Preset Connector for Pan-Tilt P25 A spare connector for pan-tilts with 4 female pins (preset). Weight 4-16 Order No. BPZ:80-169 0.30 kg BPZ:80-167 0.40 kg © Siemens Building Technologies Group...
  • Page 107 The range covers various distances to be illuminated, depending upon the target distance to be monitored. Ideal for use with monochrome and day-night cameras as all Siemens day-night models are compatible with infrared illumination.
  • Page 108: Illumination

    Brushed stainless steel 6.40 kg 230 V AC 75 W 2GF1903-8AU 2 x 170 LEDs in parallel 50° Approx. 40 m IP65 Stainless steel‚ acrylic glass Brushed stainless steel 6.40 kg 230 V AC 75 W © Siemens Building Technologies Group...
  • Page 109: Accessories Illumination

    SIRED-PMB/S Pole Bracket for SIRED S25/S50 Pole mount bracket for SIRED S25 and S50. Consisting of V2A steel with adjustable base. Pole diameter Weight © Siemens Building Technologies Group Order No. 2GF1903-8AV 0.10 kg 2GF1903-8AG Approx. 1 - 1000 Lux Switch-on: 5 s‚...
  • Page 111 Pan & tilt heads and camera housings for potentially explosive environments ™ The Phoenix range of explosion-proof equipment is typically used for surveillance in petrochemical, industrial, aerospace, or offshore industries, and generally on sites where there is a risk of explosion due to volatile gases or vapours. Special ordering process: The equipment is delivered including a camera of your choice completely ready for use, certified to meet the rigorous and exacting European ATEX Directive 94/9/EC.
  • Page 112: Explosion-Proof Housings And Mounts

    The housing can be factory fitted with a wiper and integral 10 or 17fn AC Telemetry Receiver. Siemens will deliver this housing only as a factory pre-built version with Siemens or customer-supplied camera and lens. Therefore one of the Phoenix-FIT options must be ordered.
  • Page 113 As FH07C.. for technical details‚ but with the following differences: Power requirements Usable volume (W x H x D) Dimensions (W x H x D) Weight © Siemens Building Technologies Group Order No. S24245-C4020-A11 110 V AC 114 x 94 x 290 mm 209 x 186 x 545 mm 10.0 kg...
  • Page 114 The housing can be factory-fitted with a wiper and integral 10 or 17fn AC Telemetry Receiver. Siemens can deliver this housing as a factory pre-built version with Siemens or customer-supplied camera and lens. Therefore one of the Phoenix-FIT options must be ordered.
  • Page 115 As FH07B.. for technical details‚ but with the following differences: Power requirements Usable volume (W x H x D) Dimensions (W x H x D) Weight © Siemens Building Technologies Group Order No. S24245-C4020-A8 110 V AC 114 x 94 x 290 mm 209 x 186 x 545 mm 10.0 kg...
  • Page 116: Explosion-Proof Pan/Tilt Units

    IIB gas environments (includes ethylene and propane). The pan & tilts are fitted with potentiometers‚ and 230‚ 110 and 24 V AC ver- sions are available. Please note‚ that Siemens cannot supply ATEX IIB Equipment certifi- cates unless the Phoenix-CERT option is ordered with each PTZ. Approval...
  • Page 117 & sun shield. The housing can have a wiper and integral 10 or 17fn AC Telemetry Receiver factory fitted. Siemens will deliver this housing and PTZ head only as a factory pre- built version with Siemens or customer-supplied camera and lens.
  • Page 118 Phoenix 110 V AC ATEX IIC Explosion-Proof Preset Camera Head As FPHC.. for technical details‚ but with the following differences: Power requirements Power consumption Order No. S24245-C4070-A3 24 V AC 52 VA S24245-C4070-A2 110 V AC 54 VA © Siemens Building Technologies Group...
  • Page 119: Receivers

    ATEX IIB and IIC housings. Power requirements Power consumption Operating temperature range Telemetry formats Presets © Siemens Building Technologies Group Order No. BPZ:80-128 230 D 240 V AC‚ 50/60 Hz 20 W -20 to +40 °C...
  • Page 120: Accessories Mounts

    Phoenix-CERT-Siemens Factory Fit Siemens Camera & Lens including ATEX Equipment Certification This option should be ordered if Siemens products will be used in the Phoenix housings. This option shall be ordered for each housing. Phoenix-CERT-3rd Party Factory Fit 3rd Party Camera & Lens including ATEX Equipment...
  • Page 121 Compound filled barrier gland for unarmored cable for FH07C Hous- ings. Approval WI01AB WI01AB Spare Wiper Spare wiper arm and blade for HS01 and FH07 housings. Protection rating Weight © Siemens Building Technologies Group Order No. S24245-C4090-A6 BPZ:80-315 ATEX II GC (Eed IIC) BPZ:80-242 IP66 0.1 kg...
  • Page 122 Using interoperable access control, intrusion detection and video surveillance systems Access control rights allow you in, automatically disabling the alarm system and simultaneously recording everything via the video surveillance system – all displayed and controlled via one screen. www.siemens.com/interoperability...
  • Page 123: Video Transmission

    Video Transmission When distance is a problem, transmitting the video is the only solution… With different possibilities of transmitting video, Siemens offers twisted pair or via Ethernet. Twisted pair transmission is suitable for short range distances up to 1500 m –...
  • Page 124: Twisted Pair/Coax

    0.5 W 2GF5605-8BB 2 Vpp‚ 130 Ohm‚ symmetric‚ screw terminal 1 Vpp‚ 75 Ohm‚ asymmetric‚ screw terminal Max. 600 m (indoor only) 80 x 20 x 70 mm 0.20 kg 12 V DC 0.75 W © Siemens Building Technologies Group...
  • Page 125 Video inputs Video outputs Dimensions (W x H x D) Weight Power requirements Power consumption © Siemens Building Technologies Group Order No. 2GF5604-8BA < 1200 m with wire diameter 0.8 mm‚ PE-insulated with pre-empha- sis switched on‚ with receiver mod- ule TP-RXMOD02 >...
  • Page 126: Accessories Video Transmission

    Dimensions (H x W x D) Weight Order No. 2GF5505-8AH 0.40 kg 2GF5505-8AG 0.37 kg GBQ:A5573460001 2 x BNC‚ in and out 75 Ohm Plastic 0.227 kg BPZ:80-236 41 x 32 x 90 mm 0.20 kg © Siemens Building Technologies Group...
  • Page 127: Video Motion Detection

    Video Motion Detection Reliable outdoor video motion detection system… SISTORE CX EDS (Enhanced Detection Solution) is a radically new high performance digital video analysis system. It is an intelligent embedded codec performing video streaming, recording and it operates as a professional outdoor video motion detec- tion system, with object tracking –...
  • Page 128: Video Motion Detection

    Intelligent Video Detection System SISTORE CX EDS is a video motion detection system featuring the latest Siemens technology for perimeter protection. Motion detection and object tracking are based on the latest statistical image analysis meth- ods‚ optimized for use in critical outdoor areas. If SISTORE CX devices are used‚...
  • Page 129 Quads, Video Distribution, Video Multiplexers Video handling made easy with a range of quads, video multiplexers and video distribution A range of video distribution equipment that allows either a combination, duplica- tion or switching of different video sources, including video amplification. The range of sequential video switchers enable simple switching of different video sources to a single video monitor.
  • Page 130: Quads' Split Screens And Video Distribution

    4 x BNC‚ 75 Ohm 1 per camera 1 x Form-C (C‚ NO‚ NC)‚ 24 V DC‚ 1 A 285 x 44 x 235 mm 1.70 kg 12 D 24 V AC / DC (230 V AC adapter supplied) © Siemens Building Technologies Group...
  • Page 131: Amplifiers

    19" rack. Power requirements Dimensions (W x H x D) Bandwidth Weight © Siemens Building Technologies Group Order No. BPZ:80-232 110 D 240 V AC at 40 VA‚ 50/60 Hz 126 x 134 x 483 mm (inc. BNC's) 10 MHz 3.38 kg...
  • Page 132 The alarm can be easily located via the intrusion detection system, then verified with surveillance cameras while simultaneously recording, yet restricting access control rights within the building – all displayed and controlled via one screen. www.siemens.com/interoperability...
  • Page 133: Matrix Switching Systems

    Video matrix switching made easy... SIMATRIX is a universal video matrix, that is fully scaleable to fit individual application requirements. User functionalities are wide ranging, from the pure matrix switching function, up to special event control in conjunction with external contacts, notifi- cation messaging for the processing of danger, alarm and intrusion information (i.e.
  • Page 134: Matrix Switchers

    It allows variable speed control of PTZ and dome devices when used with a CKA4820 and CAC0103 dome converter. Fixed speed control using the Siemens TTY protocol is a standard feature. The project-spe- cific characteristics of the system can be set for each process or sequence using the parameterisation software.
  • Page 135 SIMATRIX 648 Extension Module for 2 Terminal / Keyboard Interfaces To expand the SIMATRIX 648 for connection of two further CKA or SUT48 keyboards (max. 4). Weight © Siemens Building Technologies Group Order No. 2GF2208-8EA PAL/CCIR 16 x BNC‚ 1Vpp‚ 75 Ohm‚ max 64 with SIM648-IM 4 x BNC‚...
  • Page 136 441 x 266 x 217 mm‚ 19''‚ 6 U 6.50 kg 115 D 230 V AC‚ 50-60 Hz Max. 55 W 2GF2211-8CA 16 video in‚ 75 Ohm termination switchable 0.24 kg © Siemens Building Technologies Group...
  • Page 137 (maximum 1 extension chassis). Camera inputs Design Monitor output Alarm inputs Interfaces Television standard Power requirements Weight © Siemens Building Technologies Group Order No. 2GF2211-8DA 0.03 kg 2GF2211-8DB 2GF2211-8EA 128 x SysLink for communication with SIMNEO-168 19-inch rack mountable; 1U 115 D 230 V AC‚...
  • Page 138 80 ms (typical.)‚ 200 ms (max.) (fol- lowing command input on video matrix) Full IBM character set Internal synchronization 115 D 230 V AC‚ Tolerance: +10 % to -15 %‚ 50-60 Hz switchable Max. 55 W‚ depending on size © Siemens Building Technologies Group...
  • Page 139 Monitor output Interfaces Alarm connector Alarm inputs Design Dimensions (W x H x D) Weight © Siemens Building Technologies Group Order No. 2GF2211-8JA 32 x SysLink for communication with SIMNEO-EXT and SIMNEO-A128 2 x 37-pin Sub-D-Female connector 32 x‚ max 256 with SIMNEO-A128 19-inch rack mountable;...
  • Page 140 16 x SysLink for communication with SIMNEO-EXT and SIMNEO-A128 2 x 37-pin Sub-D-Female connector 32 x‚ max 256 with SIMNEO-A128 19-inch rack mountable; 6 U 441 x 266 x 217 mm‚ 19''‚ 6 U 7.73 kg © Siemens Building Technologies Group...
  • Page 141 Monitor output Interfaces Alarm connector Alarm inputs Design Dimensions (W x H x D) Weight © Siemens Building Technologies Group Order No. 2GF2211-8KE 128 x 16 x 8 x TTY-(20mA) for CKAs‚ 16 x SCU- (20mA)-Interface for CDC 2 x 37-pin Sub-D-Female connector 32 x‚...
  • Page 142 SysLink for communication with SIMNEO-EXT and SIMNEO-A128 2 x 37-pin Sub-D-Female connector 64 x‚ max 256 with SIMNEO-A128 2 x 19-inch rack mountable; 12 U 441 x 532 x 217 mm‚ 19''‚ 12 U 15.14 kg © Siemens Building Technologies Group...
  • Page 143 Monitor output Design Parameterisation PC Field size Keyboard interface Dimensions (W x H x D) Weight © Siemens Building Technologies Group Order No. 2GF2211-8LF 208 x 32 x SysLink for communication with SIMNEO-EXT and SIMNEO-A128 2 x 37-pin Sub-D-Female connector 64 x‚...
  • Page 144: Accessories Matrix Switching Systems

    RG179 Coaxial cable with a prefitted SMB socket and a BNC plug‚ 2 m Length Weight 10-12 Order No. 2GF2208-8AG 0.1 kg 2GF2207-8AE 0.1 kg 2GF2207-8AF 0.34 kg 2GF2207-8AG 10 m 2.2 kg 2GF5608-8AP 0.05 kg © Siemens Building Technologies Group...
  • Page 145 This interface kit enables the interface to the SIPORT access control sys- tem via RS232 com port 3 of SIMATRIX 648. It includes special firmware delivered on an EPROM and Software license. Weight © Siemens Building Technologies Group Order No. 2GF5505-8BA 2400...19K2 selectable...
  • Page 146 Coax Controller Unit This converter is a combined coaxial telemetry transmitter‚ telemetry protocol converter and 16 by 4 video switcher. It allows Siemens Solaris™ speed domes and telemetry receivers to be controlled over the coax using up to 2 simultaneous telemetry control sources‚ as detailed in the system overview below.
  • Page 147 Colour text insertion on the monitor output. Self-test fault diagnostics. Inputs Outputs Dimensions (W x H x D) Weight © Siemens Building Technologies Group Order No. BPZ:80-230 Length 1 m 0.24 kg BPZ:80-222 Length 1 m 0.18 kg...
  • Page 148: Recording Systems

    Recording systems SISTORE AX… SISTORE AX Watch Allows live remote viewing of cameras from single or multiple sites, including full PTZ control. … for up to 16 cameras.
  • Page 149: Recording Systems

    SISTORE – innovation and technology for recording in all applications, from standalone to networked The range of SISTORE digital video systems provide digital surveillance and image ™ recording that can be used in a multitude of applications. This can be from small shops, to shopping centres, offices or large scale industrial facilities –...
  • Page 150: Digital Video Recorders

    Recording Systems Digital Video Recorders 11-2 © Siemens Building Technologies Group...
  • Page 151 With the accompanying Remote Access Soft- ware (RAS) multiple units can be controlled via Ethernet‚ DSL or dial-up connection. The DVR is capable of audio recording and playback. Con- nect a Siemens speed dome for full telemetry control. Recording speed Video inputs...
  • Page 152 1 x VGA: 800x600 @ 60 Hz 430 x 88 x 405 mm (16.9" x 3.5" x 15.9") 10.20 kg 80 W (100 W when 3 hard disk drives are installed) 100 D 240 V AC‚ 2 A‚ 50/60 Hz © Siemens Building Technologies Group...
  • Page 153 Display format Monitor output Dimensions (W x H x D) Weight Power consumption Power requirements © Siemens Building Technologies Group Order No. 2GF4816-8EB Up to 200 ips (PAL) Up to 240 ips (NTSC) 9 x PAL / NTSC (auto-detect)‚ BNC‚ 75 Ohm‚ loop-thru 9 x / 9 x NO or NC contacts 3 x USB‚...
  • Page 154 4 x SPOT 430 x 88 x 405 mm (16.9" x 3.5" x 15.9") mm 10.20 kg 85 W (120 W when 3 hard disk drives are installed) 100 D 230 V AC‚ 2 A‚ 50/60 Hz © Siemens Building Technologies Group...
  • Page 155 Recording Systems Digital Video Recorders © Siemens Building Technologies Group 11-7...
  • Page 156 Digital: 32 IP-camera inputs via network interface 32 digital (IP cameras connected via network)‚ 4 analogue (additional activation of 3 x 4 analogue inputs possible) 1 x VGA‚ 2 x BNC 16 / 8 250 GB (expandable) © Siemens Building Technologies Group...
  • Page 157 Recording speed Digital inputs/outputs Video inputs Camera inputs Monitor output Alarm inputs/outputs Hard disk capacity © Siemens Building Technologies Group Order No. S24245-F5085-A3 200 ips (100 ips analogue and 100 ips digital) 8 / 0 Analog: 8 x FBAS (composite)‚...
  • Page 158 Recording systems SISTORE MX… SISTORE MX viewer Display up to 64 images, clear system status indications, includes full PTZ control. … for 4, 8, 16, 24 and 32 cameras and 32 IP cameras.
  • Page 159 Recording speed Video inputs Alarm inputs/outputs Camera inputs Digital inputs/outputs Hard disk capacity Monitor output Weight © Siemens Building Technologies Group Order No. SISTORE MX.. MJPEG High: 704 x 288 Standard: 352 x 288 IP megapixel: 1280 x 1024 Hardware-/Software Watchdog Via USB (CD‚...
  • Page 160 4 x USB 2.0 high speed/high current‚ 2 x Ethernet port (RJ45)‚ 1 x LAN +5 to +40 °C max. 4 A (at 24 V) 24 V DC (20.4 to 28.8 V) 262 x 133 x 47 mm max. 2.0 kg © Siemens Building Technologies Group...
  • Page 161: Accessories Recording Systems

    For use with SISTORE MX and in RemoteView for transmission over two ISDN B channels. Compatible with Weight SISTORE MX Mouse SISTORE MX Mouse SISTORE MX USB Keyboard SISTORE MX USB Keyboard © Siemens Building Technologies Group Order No. S24245-P5097-A1 S24245-P5097-A4 S24245-P5097-A2 S24245-P5097-A3 2GF4816-8BA 250 GB 1.5 kg...
  • Page 162 115 V / approx. 6.0 A or 240 V / approx. 3.0 A‚ 47 D 63 Hz Without handle: 88 x 446 x 490 mm With handle: 88 x 482 x 505 mm SISTORE AX‚ MX and CX 2GF4811-8CG 2GF4811-8CH 2GF4811-8CJ © Siemens Building Technologies Group...
  • Page 163 SISTORE CX… …intelligent digital video codec with virtual matrix facility.
  • Page 164: Network Video

    Recording Systems Network Video 11-16 © Siemens Building Technologies Group...
  • Page 165 Hard disk capacity Digital inputs Digital outputs Interfaces Recording speed Power consumption Power requirements Weight © Siemens Building Technologies Group Order No. SISTORE CX.. 1 x RJ45 - Ethernet (10baseT‚ 100baseT) 1 x RS485 1 x RS232 CX1: 1 input / 1 output...
  • Page 166 (2CIF) 25 ips encoding and 25 ips decod- ing simultaneously (4CIF) 50 ips decoding (2CIF‚ 4CIF) 100 W 12 V DC‚ 4 A (100 D 240 V AC adap- tor supplied) 5.0 kg © Siemens Building Technologies Group...
  • Page 167 Hard disk capacity Digital inputs Digital outputs Recording speed Power consumption Power requirements Weight © Siemens Building Technologies Group Order No. S24245-F5056-A4 MPEG-4 SP/ASP 2 x 250 GB 100 ips encoding (CIF‚ 2CIF) 50 ips encoding (4CIF) 50 ips encoding and 25 ips decod-...
  • Page 168 100 ips encoding (4CIF) 100 ips encoding and 25 ips decod- ing simultaneously (2CIF) 50 ips encoding and 25 ips decod- ing simultaneously (4CIF) 100 ips decoding (2CIF‚ 4CIF) 100 W 100 D 230 V AC 8.0 kg © Siemens Building Technologies Group...
  • Page 169 Hard disk capacity Digital inputs Digital outputs Recording speed Power consumption Power requirements Weight © Siemens Building Technologies Group Order No. S24245-F5096-A4 MPEG-4 SP/ASP 2 x 500 GB 200 ips encoding (CIF‚ 2CIF) 100 ips encoding (4CIF) 100 ips encoding and 25 ips decod-...
  • Page 170 As emergency lighting is automatically switched on, ventilation will be controlled, with the alarm being transmitted to first responders offering visual verification, all while restricting access to elevators and doors in the alarm area and guiding people away to safety via the voice evacuation system. www.siemens.com/interoperability...
  • Page 171: Monitors' Displays And Mounts

    – ideally suited for use wherever good picture quality and reliability are of prime importance. The traditional CRT range provides the perfect answer for all standard monitor screen size requirements in general applications where a good quality picture and high levels of performance are wanted at a reasonable price.
  • Page 172: Tft Monitors Overview

    Monitors‚ Displays and Mounts TFT Monitors Overview 12-2 © Siemens Building Technologies Group...
  • Page 173: Crt Monitors Overview

    Monitors‚ Displays and Mounts CRT Monitors Overview © Siemens Building Technologies Group 12-3...
  • Page 174: Monochrome Monitors

    356 x 333 x 381 mm 100 D 240 V AC 10.5 kg 2GF3034-8AA 2 x Video IN (BNC)‚ looped through > 1000 TV lines 405 x 371 x 406 mm 100 D 240 V AC 14.4 kg © Siemens Building Technologies Group...
  • Page 175: Colour Monitors

    Audio inputs Video (in/out) Dimensions (W x H x D) Power requirements Weight © Siemens Building Technologies Group Order No. 2GF3132-8AA > 350 TV lines‚ 450 TV lines with Y/C 1 x Audio (RCA)‚ looped through 1 x Video IN (BNC)‚ looped through‚...
  • Page 176 > 400 TV lines‚ 450 TV lines with Y/C 2 x Audio (RCA)‚ looped through 2 x Video IN (BNC)‚ looped through‚ 1 x S-VHS IN (Y/C)‚ looped through 480 x 466 x 439 mm 100 D 240 V AC 25.5 kg © Siemens Building Technologies Group...
  • Page 177 For every viewing need… …a complete range of TFT monitors.
  • Page 178: Lcd-Displays

    374 x 318 x 62.5 mm 2 built-in speakers‚ L+R 2 x audio in (RCA) Colour‚ hue‚ brightness‚ contrast‚ sharpness‚ volume‚ language‚ scan (O/U)‚ picture-in-picture function (PIP) A24205-A336-B502 8.5 kg 100 D 240 V‚ 50/60 Hz © Siemens Building Technologies Group...
  • Page 179 Dimensions (W x H x D) Audio Audio inputs Data sheet Weight Power requirements © Siemens Building Technologies Group Order No. 2GF3126-8AA 1 x video in (BNC)‚ 1 x S-video‚ 1 x DVI-I 372 x 325 x 54 mm 2 built-in speakers‚ L+R 1 x audio in (RCA) Colour‚...
  • Page 180 1 x Video in (BNC)‚ 1 x S-Video‚ 1 x DVI-I 420 x 431.5 x 54.5 mm 2 speakers 1 x audio in colour‚ hue‚ brightness‚ contrast‚ sharpness‚ volume‚ language‚ scan (O/U) A6V10059448 5.0 kg 100 D 240 V AC‚ 50/60 Hz © Siemens Building Technologies Group...
  • Page 181: Monitor Mounts

    Monitors‚ Displays and Mounts Monitor Mounts Type VMT900 Monitor Hanger for 12z15" CRT Monitors Attractive‚ easily adjusted‚ single tie-rod monitor hanger designed to safely grip monitors at the point of balance just behind the front facia. Strong‚ rubber-faced extruded aluminium corner-pieces securely hold the monitor without damaging the monitor case.
  • Page 182: Monitor Mounts

    Load rating Weight VMT911 Wall Mount Bracket for 17z21" CRT Monitors Attractive‚ easily adjusted‚ dual tie-rod monitor hanger designed to safely grip monitors at the point of balance just behind the front facia. Strong‚ rubber-faced extruded aluminium corner-pieces securely hold the monitor without damaging the monitor case.
  • Page 183 IVM allows easy operation and complete control of your CCTV system, no matter how large or small IVM (Interactive Video Management software) allows the user to carry out the entire video system management, from the generation of site plans or system configuration, to display, selection and control of individual video components or external systems.
  • Page 184: Video Software

    The I/O server is a software additional component of IVM for control of the I/O contacts of the SIMATIC S7. 13-2 Order No. 2GF9400-8FM 2GF9400-8FN 2GF9400-8FA 2GF9400-8FL 2GF9400-8FB 2GF9400-8FD 2GF9400-8FE 2GF9400-8FF 2GF9400-8GC 2GF9400-8KA 2GF9400-8KB 2GF9400-8KC © Siemens Building Technologies Group...
  • Page 185: Sistore Mx Nvs Network Video Software

    SISTORE MX NVS 16 SISTORE MX NVS 16 As SISTORE MX NVS.. for technical details‚ but with the following differ- ences: Digital Video Recording Software for 16 IP-Cameras © Siemens Building Technologies Group Order No. SISTORE MX NVS.. S24245-P5099-A1 S24245-P5099-A2...
  • Page 186: Sistore Mx Nvs Network Video Software

    SISTORE MX NVR USB Input/Output Module for SISTORE MX NVR USB input/output module for SISTORE MX NVR - 16 channels with opto- coupler function‚ 16 channels with relay function. COOS000001 FS Video Software Suite (VSS) 13-4 Order No. S24245-P5099-A4 2GF4811-8CG 2GF4811-8CH 2GF4811-8CJ 2GF9490-8AC © Siemens Building Technologies Group...
  • Page 187: System Diagrams

    System Diagrams © Siemens Building Technologies Group 14-1...
  • Page 188 System Diagrams 14-2 © Siemens Building Technologies Group...
  • Page 189 System Diagrams © Siemens Building Technologies Group 14-3...
  • Page 190 System Diagrams 14-4 © Siemens Building Technologies Group...
  • Page 191: Hints And Tips

    The second number is the protection against liquids: 7 = Protected from the effects of immersion between 15 cm and 1 m © Siemens Building Technologies Group Focusing a zoom lens 1. Place the appropriate ND filter over the lens, this will force the iris open.
  • Page 192 260 V AC CCBC1337.. 1/3" DSP Colour DIP Switch Camera 540 TVL CCBC1345-LN 1/3" DSP Colour DIP Switch Camera 480 TVL‚ NTSC‚ 12 V DC / 24 V AC © Siemens Building Technologies Group Order No. Page 2GF4816-8JA 2GF4816-8FB 2GF4816-8AF...
  • Page 193 2GF1192-8BQ 2GF1192-8BF 2GF1192-8BA 2GF1192-8BM 2GF1193-8AC 2GF1193-8AD 2GF1193-8AB CCDA1435.. 2GF1194-8BD 2GF1194-8BG 2GF1194-8CF 2GF1194-8BE 2GF1194-8BB 2GF1194-8CE 2GF1194-8BA 2GF1194-8AC 2GF1194-8AD 2GF1194-8CB © Siemens Building Technologies Group 1-10 1-10 1-10 1-14 1-15 1-15 1-15 1-17 1-17 1-17 1-20 1-20 1-46 1-46 1-44 1-46 1-45...
  • Page 194 1/3" CCD 3.7 mm Colour Fixed Dome 330 TVL CFFC1315-LN 1/3" CCD 3.7 mm Colour Fixed Dome 480 TVL‚ NTSC CFFC1315-LP 1/3" CCD 3.7 mm Colour Fixed Dome 480 TVL‚ PAL © Siemens Building Technologies Group Order No. Page 2GF1194-8BJ 2GF1194-8CG...
  • Page 195 2GF1705-8NA 2GF2400-8EA 2GF2400-8EC 2GF1642-8AT CLFD13.. 2GF1663-8AP 2GF1663-8AQ 2GF1663-8AR 2GF1663-8AN 2GF1663-8AS 2GF1640-8AH CLFM13.. 2GF1661-8AM 2GF1661-8AN 2GF1661-8AP 2GF1661-8AL 2GF1661-8AQ 2GF1666-8AD 2GF1651-8AA 2GF1651-8AB © Siemens Building Technologies Group 1-26 1-42 1-27 1-27 1-27 1-28 1-28 1-28 1-29 1-29 1-29 3-14 3-14 3-13 3-13...
  • Page 196 22x Optical Zoom‚ in Vandal-Resistant Housing CVAS1415 High Resolution‚ Auto-focus Day-Night Dome Camera with 22x Optical Zoom‚ in Vandal-Resistant Housing CVVA-CD Clear Lower Dome CVxx Vandal Dome Series © Siemens Building Technologies Group Order No. Page CLVD13.. 2GF1667-8AM 2GF1667-8AJ...
  • Page 197 11-19 S24245-P5101-A2 S24245-F5096-A2 11-20 S24245-F5096-A4 11-21 S24245-F5096-A3 11-20 S24245-P5101-A3 2GF1705-8KA 2GF1705-8JA BPZ:80-128 BPZ:80-129 S24245-C4020-A7 S24245-C4020-A9 S24245-C4020-A8 S24245-C4020-A1 S24245-C4020-A3 S24245-C4020-A2 FH07B.. S24245-C4020-A10 © Siemens Building Technologies Group 1-42 1-42 1-30 1-30 1-30 1-31 1-31 1-31 1-32 1-32 1-32 1-20 1-20 1-20...
  • Page 198 P25T-P Pan & Tilt head‚ 230 V AC P25T-P/L P25T-P/L Pan & Tilt head‚ 24 V AC P25T/D P25T/D Pan & Tilt head‚ 24 V DC PCBV331 VISILYNX Alarm Input Panel © Siemens Building Technologies Group Order No. Page S24245-C4020-A12 S24245-C4020-A11 S24245-C4020-A4 S24245-C4020-A6...
  • Page 199 Factory Fit Camera & Lens including ATEX Equipment Certification Phoenix-CERT.. Phoenix-FIT-3rd Party Fitting Fee‚ issued for each additional 3rd Party Component to be installed Phoenix-FIT-Siemens Fitting Fee‚ issued for each additional Siemens Component to be installed Phoenix-FIT.. Fitting Fee‚ issued for each additional Component to be installed Phoenix-FIT.. PSU12-CHM/CHH...
  • Page 200 SISTORE MXHDE 500 SISTORE MX Hard Disk Extension Kit 500 GB SISTORE RAID8 2000 SISTORE RAID8 2000 SISTORE RAID8 3000 SISTORE RAID8 3000 SISTORE USB-ISDN-Modul SISTORE MX ISDN Module © Siemens Building Technologies Group Order No. Page 2GF2211-8KA 2GF2211-8LF 10-11 2GF2211-8KG...
  • Page 201 Hanger Ceiling Bracket for VMT900 VMT903 Monitor Extension Tube for VMT902 VMT910 Monitor Hanger for 20z21" CRT Monitors VMT911 Wall Mount Bracket for 17z21" CRT Monitors VQD100-RT Monochrome Quad Real-Time 12 V DC VQD300-RT Colour Quad Real-Time 12 V DC VT/75...
  • Page 202 Type Index Type Description WMB-PT40 Wall Mount Bracket for PT40 and CDD2410 WMB-S-M-B Bracket for ECH-B / ECH-M © Siemens Building Technologies Group Order No. Page 2GF1710-8AC 2GF1705-8LB 4-13...
  • Page 203: Glossary

    Is a feature of a pan tilt or pan only head which allows the head to continuously move (pan) left and right between two fixed points. These fixed points can be set by adjusting the limit switches in the head. © Siemens Building Technologies Group...
  • Page 204 The term baud is used to express the data exchange rate, typically the baud settings of two devices must match if the devices are to communicate with one another. © Siemens Building Technologies Group Beam Angle Is the angular beam width of a conical beam of light and is measured in degrees.
  • Page 205 Is a new unit which replaces the candle and is a measurement of luminous intensity. Cathode Ray Tube (CRT) Is a tube in the monitor containing a heated cathode which emits a beam of electrons focused on a phosphor coated surface. The sur- face glows depending upon the intensity of the beam.
  • Page 206 Switchers may have fixed or programmable dwell times. © Siemens Building Technologies Group EASS Electronic Surveillance System It is used in retail shops to electronically tag the article merchandise to prevent shop thefts.
  • Page 207 This tube allows the camera to be used in low light areas. Image Intensifier Is a device which intensifies light by using light sensitive phosphor screens. It is used to improve camera performance under low light conditions. © Siemens Building Technologies Group...
  • Page 208 Is a control device in the form of a stick in a PTZ controller used to con- trol the pan, tilt and zoom movement of a pan tilt head or dome. © Siemens Building Technologies Group Junction box Empty box (mostly weatherproof) to be mounted close to the elec- tronic device.
  • Page 209 Occurs when the horizontal sync pulses are distorted or lost and the monitor is unable to latch on to them causing the horizontal lines to be displaced in a random manner. This is seen as a tearing of the pic- ture on the monitor. © Siemens Building Technologies Group...
  • Page 210 Read Out Time Is the time taken to read the charge from the pixels in a CCD chip. © Siemens Building Technologies Group Real Time Video Is a picture with more than 24 frames per sec and therefore looks continuous.
  • Page 211 Triaxial Cable Is a type of coaxial cable which has two layers of shield to provide bet- ter protection against EMI. © Siemens Building Technologies Group...
  • Page 212 Video Home System is a type of popular recording format used in video cassette recorders. © Siemens Building Technologies Group Video Amplifier Is used to boost the strength of a video signal. Video Cassette Recorder Is a device which can record (or playback) video and audio signals on a magnetic tape housed in a cassette.
  • Page 213 Notes 16-11 © Siemens Building Technologies Group...
  • Page 214 Planning Guide – CCTV portfolio overview Monochrome camera Colour camera Day-night camera Auto focus camera Vandal resistant auto focus fixed dome Transceiver encoding Varifocal and monofocal fixed dome Coaxial cable Vandal resistant varifocal fixed dome Twisted pair (two-wire) transmission Speed dome Fibre optic transmission Weatherproof housing PSTN / ISDN dial-up line...
  • Page 215 V ideo output Video input Video input Video input Video input Video input Video input Video input IP input Video input Video (transmitted) SISTORE CX EDS Up to 8 surveillance channels SIMATRIX 164 16 video inputs 4 video outputs IVM interface 16 alarm inputs RS232 SIMATRIX 648...
  • Page 216 Interactive Video Management system IVM is a scalable, open, interactive system for the control and operation of security applications: – Controls analogue (SIMATRIX) matrix switchers – Display of configured site plans with cameras, monitors, alarm lists, log books etc. V ideo input Video input Video input IP input...
  • Page 217 Welcome to the world of innovative thinking Innovation For the last 160 years, Siemens has been investing a great deal in both manpower and research and development. This has ensured a constant stream of new in- sights, technologies and inventions that...
  • Page 218 The required features should therefore be specified in each individual case at the time of closing the contract. Subject to change • Order no. A6V10069175 • © Siemens Switzerland Ltd www.siemens.com/cctv...

This manual is also suitable for:

Tft
