- Page 1 FLAGSHIP Luxury Scooter Model: TE-889XLSN User Manual 7/3/2006...
-
Page 2: Table Of Contents
Table of Contents INTRODUCTION……….……………………………………………………………………3 FEATURE GUIDE………….………………………………………………………………..3 SAFETY ADVICE……….…………………………………………………………………...4 EMI WARNING……………….……………………………………………………………...5 WARNINGS……………….………………………………………………………………….6 ADJUSTMENTS……………………………………………………………………………..7 SCOOTER TILLER CONTROLS…………………………………………………………..9 DRIVE/FREEWHEEL OPERATION……...………………………………………………10 STARTING TO DRIVE YOUR SCOOTER………...…………………………………….11 EXTRA GUIDELINES IN THE CONTROL OF YOUR SCOOTER………...………….12 TRANSPORT/STORAGE…………………..……………………………………………..13 BATTERIES AND BATTERY CHARGING…………...………………………………….14 MAINTENANCE…………………………..………………………………………………..15 TROUBLESHOOTING GUIDE………...………………………………………………….15 TECHNICAL SPECIFICATIONS…………..……………………………………………..16 QUARTERLY INSPECTION…………...………………………………………………….17 WARRANTY……………..………………………………………………………………….18 DISCLAIMER………..……………………………………………………………………...18... -
Page 3: Introduction
INTRODUCTION Congratulations on your purchase of the Shoprider® Flagship ™ scooter. The Flagship ™ scooter is the ultimate combination of style, comfort and ease of use. The freedom that the Flagship ™ scooter offers, allows you the liberty of mobility, rain or shine. Direct drive transaxles, automatic electromagnetic brake and easy hand controls give a safe and efficient ride. -
Page 4: Safety Advice
• Make sure the tiller is properly adjusted to the user or damage and injury could result. • DO NOT transport in a vehicle WHILE seated on the scooter. Shoprider® will not be responsible for any injury or damage that might result. -
Page 5: Emi Warning
EMI WARNING Shoprider® Flagship ™ may be susceptible to electromagnetic interference (EMI), which is a kind of interfering electromagnetic energy (EM) emitted from sources such as radio stations, TV stations, amateur radio (HAM) transmitters, two-way radio, and cellular phones. The interference (from radio wave sources) can cause the scooter to release its brakes, move by itself, or move in unintended directions. -
Page 6: Warnings
EMI. NOTE! There is no easy way to evaluate the overall immunity of the scooter. 5. Report all incidents of unintended movement or braking to your Shoprider® provider, and note whether there are sources of EMI nearby. -
Page 7: Adjustments
ADJUSTMENTS Tiller Angle Adjustment (Fig 2) On the left hand side at the base of the tiller is a red lever. Push the lever to release the pin and select the desired tiller angle. Refit the pin into one of the three location holes to lock tiller in place. -
Page 8: Scooter Tiller Controls
SCOOTER TILLER CONTROLS (FIG 3) Speed Controls The speed control allows you to set a speed between 1 (minimum) and 10 (maximum). There is also a high/low switch giving you a total of 20 speed settings.. Battery Level Indicator The number of red bars shows the amount of charge left in your batteries. -
Page 9: Drive/Freewheel Operation
WARNING! For safety, always put the scooter into gear (lever down) after pushing or rolling scooter. Failure to do so may result in injury. Shoprider® is not responsible for damage or injury incurred due to improper or misuse of the scooter. -
Page 10: Starting To Drive Your Scooter
STARTING TO DRIVE YOUR SCOOTER First Time Use Prior to using your Shoprider® Flagship ™ scooter for the first time, you must charge the batteries fully (refer to Battery Charging Procedures). Charging may take up to 12 hours. Charging the batteries completely prior to first time use will benefit battery efficiency and extend battery life. -
Page 11: Extra Guidelines In The Control Of Your Scooter
EXTRA GUIDELINES IN THE CONTROL OF YOUR SCOOTER Ramps The stability of your scooter is governed by several factors such as the seating position, the angle of the slope and your height and weight. When approaching an incline, do so directly and not at an angle and where ever possible avoid making turns. -
Page 12: Batteries And Battery Charging
Failure to do so may cause damage. Charging The Shoprider® Flagship ™ scooter has a built in 3-pin charger port located on the right side of the tiller next to the key switch. To charge the batteries connect the 3-pin male plug lead into the 3-pin female battery-charging socket on the tiller. -
Page 13: Maintenance
• Inspection for loose wheel bolts, tiller base bolts, seat tightening bolt, and other nuts and bolts is recommended on a regular basis. • Most lubricated components on the Shoprider® Flagship ™ scooter are designed to be maintenance free and are sealed. Therefore lubrication is not required for these components. -
Page 14: Technical Specifications
UNIT SPECIFICATIONS Overall Dimensions: L Number, Size of Tires Suggested User Weight (on the level road) Total Weight (w/ batteries, basket, seat) Each Battery Module Weight (12v-75amp x2) Battery Module Capacity Charger-24v Output Power of Motor Maximum Speed Maximum Climbing Angle (based on user weight of 90kg/200lb) /Safe Climbing Angle Range (per charge w/ STD 75Ah Battery) -
Page 15: Quarterly Inspection
NOTE! Regular (Monthly) inspection is strongly recommended by the manufacturer to ensure ultimate performance of the vehicle. Service Record: Purchaser:____________________________________________________ Model #: TE-889XLSN Flagship™ ____________________________ Provider Unit Was Purchased From: _______________________________ M / D / Y M / D / Y... -
Page 16: Warranty
It is not intended to be used by individuals with physical limitations that could prevent the user from operating this unit safely. Shoprider® disclaims all responsibility for any personal injury or property damage, which may occur as a result of improper or unsafe use of its products.
