MICRO COMPONENT SYSTEM
MODEL
XL-HP707
OPERATION MANUAL
Thank you for purchasing this SHARP product.
To obtain the best performance from this product, please read this
manual carefully. It will guide you in operating your SHARP product.
XL-HP707 Micro Component System consisting of XL-HP707 (main unit)
and CP-HP707 (speaker system).
Accessories
Please confirm that the following accessories are included.
Remote control
1
AM loop antenna
(RRMCG0408AWSA)
(QANTL0005AWZZ)
Note:
Only the above accessories are included.
1
FM antenna
1
(92LFANT1746A)
Advertisement
Table of Contents
Related Manuals for Sharp XL-HP707
Summary of Contents for Sharp XL-HP707
-
Page 1: Micro Component System
Thank you for purchasing this SHARP product. To obtain the best performance from this product, please read this manual carefully. It will guide you in operating your SHARP product. XL-HP707 Micro Component System consisting of XL-HP707 (main unit) and CP-HP707 (speaker system). -
Page 2: Special Notes
NOTE It is the intent of Sharp that this product be used in full compliance with the copyright laws of the United States and that prior permission be ob- tained from copyright owners whenever necessary. -
Page 3: Important Safety Instructions
Instruction Manual for replacement or resetting of protective device. If replacement of the plug is required, be sure the service technician has used a replacement plug specified by the manufacturer that has the same overload protection as the original plug. XL-HP707... - Page 4 IMPORTANT SAFETY INSTRUCTIONS XL-HP707 Outdoor Antenna Grounding - If an outside antenna or cable system is connected to the product, be sure the antenna or cable system is grounded so as to provide some protection against voltage surges and built-up static charges. Article 810 of the National Electrical Code, ANSI/...
-
Page 5: Table Of Contents
NERGY TAR® Program Information As an NERGY TAR® Partner, SHARP has determined that this product meets the NERGY TAR® guidelines for energy efficiency. NERGY TAR® is a U.S. registered mark. WHY PURCHASE NERGY TAR® LABELED PRODUCTS? Many Electrical /Electronic Products use energy both when they are on and when they are off. -
Page 6: Precautions
Using this product with a higher voltage other than that which is specified is dangerous and may result in a fire or other type of acci- dent causing damage. SHARP will not be held responsible for any damage resulting from use of this unit with a voltage other than that which is specified. -
Page 7: Controls And Indicators
26. Tuning Up Button ....... . . 21 27. Tuning Down Button ......21 XL-HP707 Reference page... -
Page 8: Speaker System
Controls and indicators (continued) XL-HP707 15 16 17 ! Display 1. Disc Number Indicators ......18 2. - Page 9 23. Tape Forward Play Button ......23 24. Tape Record Pause Button ..... . 25, 26 XL-HP707 Reference page...
-
Page 10: System Connections
System connections XL-HP707 Make sure to unplug the AC power cord before any connections. Antenna connection (see page 11) FM antenna AM loop antenna Right speaker Left speaker Speaker connection (see page 11) AC outlet (AC 120 V, 60 Hz) -
Page 11: 2. Speaker Terminals
" Do not stand or sit on the speakers. You may be injured. ! Speaker grilles are removable Make sure nothing comes into contact with the speaker diaphragms when you remove the speaker grilles. XL-HP707 Incorrect... -
Page 12: Cooling Fan
System connections (continued) XL-HP707 ! AC power connection After checking all the connections have been made correctly, plug the AC power cord of this unit into the AC outlet. If you plug in the unit first, the unit will enter the demonstration mode. -
Page 13: Remote Control
Point the remote control directly at the remote sensor on the unit. The remote control can be used within the range shown below: Press the ON/STAND-BY button. Does the power turn on? Now, you can enjoy music. Remote sensor 8" - 20' (0.2 m - 6 m) XL-HP707... -
Page 14: General Control
General control XL-HP707 ! To turn the power on Press the ON/STAND-BY button to turn the power on. After use: Press the ON/STAND-BY button to enter the power stand-by mode. ! Illumination light control When the power is turned on, the entire display and ring around the volume control light up. -
Page 15: Setting The Clock
(reset)" on page 33 for details.] 2 Perform "Setting the clock" from step 1. Note: The clock can also be set with the remote control. XL-HP707 button to adjust the hour and button once to advance the time by button to adjust the minutes and button once to advance the time by button to display the time. -
Page 16: Cd Playback
Listening to a CD (CDs) XL-HP707 This system can play audio CD, CD-R and CD-RW discs, but can- not record. Some audio CD-R and CD-RW discs may not be playable due to the state of the disc or the device that was used for recording. -
Page 17: Cd Pause Indicator
END" will appear on the display and CD operation will be paused. When the beginning of the first track is reached during fast re- verse, the unit will enter the playback mode. ( : Last track number) XL-HP707 Operation button... -
Page 18: Advanced Cd Playback
Advanced CD playback XL-HP707 ! To specify a disc to play You can play a disc by specifying the disc number. Press one of the 5 buttons to select the desired disc. Selected disc number Within 5 seconds, press the CD DIRECT PLAY button on the main unit. -
Page 19: Cd Repeat Play Indicator
" In random play, the CD player will select and play tracks auto- matically. (You cannot select the order of the tracks.) Caution: After performing repeat or random play, be sure to press the ) button. Otherwise, the disc(s) will play continuously. XL-HP707... -
Page 20: Memory Indicator
Advanced CD Playback (continued) XL-HP707 ! Programmed play You can choose up to 32 selections for playback in the order you like. While in the stop mode, press the MEMORY/SET (MEMORY) button to enter the programming save mode. Press one of the 5 buttons to select the desired disc. -
Page 21: Listening To The Radio
" " " will appear when an FM broadcast is in stereo. " If the FM reception is weak, press the TUNER (BAND) button to extinguish the "ST" indicator. The reception changes to monau- ral, and the sound becomes clearer. FM stereo mode indicator FM stereo receiving indicator XL-HP707... - Page 22 Listening to the radio (continued) XL-HP707 ! Memorizing a station You can store 40 AM and FM stations in memory and recall them at the push of a button. (Preset tuning) Perform steps 1 - 3 in "Tuning" on page 21.
-
Page 23: Tape Playback
" TAPE button on the remote control: The unit turns on and side A playback starts (regardless of the last function). " button on the main unit: The unit turns on and playback of the last function starts (CD/TAPE/TUNER/VIDEO). XL-HP707... -
Page 24: Recording On A Cassette Tape
" When recording important selections, make a preliminary test to Operation ensure that the desired material is properly recorded. " SHARP is not liable for damage or loss of your recording arising Press in the stop from malfunction of this unit. -
Page 25: Tape Record Indicator
CD and the cassette will stop automatically. " CD playback will start approximately 7 seconds after the tape starts. To stop recording: Press the (TAPE ) button. The CD and tape will stop. XL-HP707... -
Page 26: Recording On A Cassette Tape
Recording on a cassette tape (continued) XL-HP707 Recording from several CDs continuously: 1 Perform steps 1 - 6 in "Recording from a CD (CDs)" on page 25. 2 Within 5 seconds, press the ( ) button to record on side A, or the ( ) button for side B. -
Page 27: Timer And Sleep Operation
Press the CLOCK/TIMER button. Within 10 seconds, press the "ONCE" or "DAILY", and press the MEMORY/SET button. Stop Set the clock to the correct time if "ONCE" or "DAILY" does not appear. XL-HP707 button to select Continued to the next page... -
Page 28: Daily Timer Indicator
Timer and sleep operation (continued) XL-HP707 Within 10 seconds, press the lect "ONCE SET" or "DAILY SET", and press the MEMORY/ SET button. Press the button to select "PLAY" or "REC", and press the MEMORY/SET button. White The illustrations show the daily timer setting. - Page 29 "ONCE ON" or "DAILY ON", and press the MEMORY/SET button. 4 Press the ON/STAND-BY button to enter the power stand-by mode. Note: The timer can also be set with the remote control. XL-HP707 button to select button to select button to select button to select...
-
Page 30: Sleep Indicator
Timer and sleep operation (continued) XL-HP707 ! Sleep operation The radio, compact disc and cassette tape can all be turned off automatically. Play back the desired sound source. Press the CLOCK/TIMER button. Within 10 seconds, press the button to select "SLEEP", and press the MEMO-... -
Page 31: Enhancing Your System
" Be sure your headphones have a 1/8" (3.5 mm) diameter plug and are between 16 ohms and 50 ohms impedance. The recom- mended impedance is 32 ohms. " Plugging in the headphones disconnects the speakers automati- cally. Adjust the volume using the VOLUME control. XL-HP707 ( ) button. -
Page 32: Troubleshooting Chart
Troubleshooting chart Many potential problems can be resolved by the owner without call- ing a service technician. If something is wrong with this product, check the following before calling your authorized SHARP dealer or service center. ! General Symptom Possible cause "... - Page 33 2 While pressing down the button and the X-BASS/DEMO but- ton, press the PRESET button until "CLEAR AL" appears. Caution: This operation will erase all data stored in memory including clock, timer settings, tuner preset, and CD program. XL-HP707...
-
Page 34: Maintenance
XL-HP707 ! Condensation Sudden temperature changes, storage or operation in an extremely humid environment may cause condensation inside the cabinet (CD pickup, tape heads, etc.) or on the transmitter on the remote control. Condensation can cause the unit to malfunction. If this happens, leave the power on with no disc (or cassette) in the unit until normal playback is possible (about 1 hour). -
Page 35: Specifications
Specifications As part of our policy of continuous improvement, SHARP reserves the right to make design and specification changes for product improvement without prior notice. The performance specification fig- ures indicated are nominal values of production units. There may be some deviations from these values in individual units. -
Page 36: Consumer Limited Warranty
Product, and shall constitute full satisfaction of all claims, whether based on contract, negligence, strict liability or otherwise. In no event shall Sharp be liable, or in any way responsible, for any damages or defects in the Product which were caused by repairs or attempted repairs performed by anyone other than an authorized servicer.
