Page 1 Thank you for purchasing this SHARP product. To obtain the best performance from this product, please read this manual carefully. It will guide you in operating your SHARP product. CD-ES600 Mini Component System consisting of CD-ES600 (main unit) and CP-ES600 (speaker system).
Page 2: Special Notes
NOTE It is the intent of Sharp that this product be used in full compliance with the copyright laws of the United States and that prior permission be ob- tained from copyright owners whenever necessary.
Page 3: Important Safety Instructions
Instruction Manual for replacement or resetting of protective device. If replacement of the plug is required, be sure the service technician has used a replacement plug specified by the manufacturer that has the same overload protection as the original plug. CD-ES600 CD-ES66...
Page 4 CD-ES600 IMPORTANT SAFETY INSTRUCTIONS CD-ES66 Outdoor Antenna Grounding - If an outside antenna or cable system is connected to the product, be sure the antenna or cable system is grounded so as to provide some protection against voltage surges and built-up static charges.
Page 5: Table Of Contents
NERGY TAR® Program Information As an NERGY TAR® Partner, SHARP has determined that this product meets the NERGY TAR® guidelines for energy efficiency. NERGY TAR® is a U.S. registered mark. WHY PURCHASE NERGY TAR® LABELED PRODUCTS? Many Electrical /Electronic Products use energy both when they are on and when they are off.
Page 6: Precautions
Using this product with a higher voltage other than that which is specified is dangerous and may result in a fire or other type of acci- dent causing damage. SHARP will not be held responsible for any damage resulting from use of this unit with a voltage other than that which is specified.
Page 7: Controls And Indicators
26. Game/Video Button ....... 31 24 25 26 CD-ES600 CD-ES66...
Page 8: Rear Panel
CD-ES600 Controls and indicators (continued) CD-ES66 13 14 15 ! Display 1. Disc Number Indicators ......18 2.
Page 9 2) Button ....... . 23 21. Volume Up and Down Buttons ..... . 14 CD-ES600 CD-ES66...
Page 10: System Connections
System connections CD-ES600 CD-ES66 Make sure to unplug the AC power cord before any connections. Right speaker Speaker connection (see page 11) Antenna connection (see page 11) FM antenna AM loop antenna Left speaker AC outlet (AC 120 V, 60 Hz)
Page 11: Fm 75 Ohms Antenna Terminal
! Placing the speaker system The left and right speakers have individual shapes. For best perfor- mance, place the speakers according to the diagram below. Left speaker Screws (not supplied) Note: The speaker grilles are not removable. CD-ES600 CD-ES66 Black Incorrect Right speaker...
Page 12: Cooling Fan
CD-ES600 System connections (continued) CD-ES66 ! AC power connection After checking all the connections have been made correctly, plug the AC power cord of this unit into the AC outlet. If you plug in the unit first, the unit will enter the demonstration mode.
Page 13: Remote Control
Point the remote control directly at the remote sensor on the unit. The remote control can be used within the range shown below: Press the ON/STAND-BY button. Does the power turn on? Now, you can enjoy music. 8" - 20' (0.2 m - 6 m) CD-ES600 CD-ES66 Remote sensor...
Page 14: General Control
General control CD-ES600 CD-ES66 ! To turn the power on Press the ON/STAND-BY button to turn the power on. After use: Press the ON/STAND-BY button to enter the power stand-by mode. ! Illumination light control When the power is turned on, light illuminates around the display. To turn on/off the light, hold down the CLEAR/DIMMER button on the remote control more than 2 seconds.
Page 15: Setting The Clock
(reset)" on page 33 for details.] Perform "Setting the clock" from step 1. Note: The clock can also be set with the remote control. CD-ES600 CD-ES66 button to adjust the hour and then button once to advance the time by 1...
Page 16: Cd Playback
Listening to a CD (CDs) CD-ES600 CD-ES66 This system can also play audio CD-R and CD-RW discs, but can- not record. Some audio CD-R and CD-RW discs may not be playable due to the state of the disc or the device that was used for recording.
Page 17: Cd Pause Indicator
END" will appear on the display and CD operation will be paused. When the beginning of the first track is reached during fast re- verse, the unit will enter the playback mode. ( : Last track number) CD-ES600 CD-ES66 Operation Press in the stop mode.
Page 18: Advanced Cd Playback
CD-ES600 Advanced CD playback CD-ES66 ! To specify a disc to play You can play a disc by specifying the disc number. Press one of the 5 buttons to select the desired disc. Selected disc number Within 5 seconds, press the DIRECT PLAY button on the main unit.
Page 19: Cd Repeat Play Indicator
" In random play, the CD player will select and play tracks automat- ically. (You cannot select the order of the tracks.) Caution: After performing repeat or random play, be sure to press the ton. Otherwise, the disc(s) will play continuously. CD-ES600 CD-ES66 but-...
Page 20: Memory Indicator
CD-ES600 Advanced CD Playback (continued) CD-ES66 ! Programmed play You can choose up to 32 selections for playback in the order you like. While in the stop mode, press the MEMORY/SET (MEMORY) button to enter the programming save mode. Press one of the 5 buttons to select the desired disc.
Page 21: Listening To The Radio
" " " will appear when an FM broadcast is in stereo. " If the FM reception is weak, press the TUNER (BAND) button to extinguish the "ST" indicator. The reception changes to monau- ral, and the sound becomes clearer. FM stereo mode indicator FM stereo receiving indicator CD-ES600 CD-ES66...
Page 22: Listening To The Radio
CD-ES600 Listening to the radio (continued) CD-ES66 ! Memorizing a station You can store 40 AM and FM stations in memory and recall them at the push of a button. (Preset tuning) Perform steps 1 - 3 in "Tuning" on page 21.
Page 23: Tape Playback
2) button (main unit and remote control): The unit turns on and the "TAPE" function is activated. " button (main unit and remote control): The unit turns on and playback of the last function starts (CD/TAPE/TUNER/ GAME). CD-ES600 CD-ES66 TAPE 2 Tape play indicator...
Page 24: Recording On A Cassette Tape
" When recording important selections, make a preliminary test to Operation ensure that the desired material is properly recorded. " SHARP is not liable for damage or loss of your recording arising Press in the stop from malfunction of this unit.
Page 25: Tape 2 Record Indicator
CD and the cassette will stop automatically. " CD playback will start approximately 7 seconds after the tape starts. To stop recording: Press the button. The CD and tape will stop. CD-ES600 CD-ES66...
Page 26: Recording On A Cassette Tape
CD-ES600 Recording on a cassette tape (continued) CD-ES66 Recording from several CDs continuously: 1 Perform steps 1 - 5 in "Recording from a CD (CDs)" on page 25. 2 Within 5 seconds, press the To perform programmed recording: 1 Program discs and tracks. (See page 20.) 2 Press the button.
Page 27: Timer And Sleep Operation
Within 10 seconds, press the "ONCE" or "DAILY", and press the MEMORY/SET button. Once timer Stop Set the unit to the correct time if "ONCE" or "DAILY" does not appear. sette compartment. button to select Continued to the next page CD-ES600 CD-ES66...
Page 28: Daily Timer Indicator
CD-ES600 Timer and sleep operation (continued) CD-ES66 Within 10 seconds, press the lect "ONCE SET" or "DAILY SET", and press the MEMORY/ SET button. Press the "REC", and press the MEMORY/SET button. White The illustrations show the daily timer setting.
Page 29 "ONCE ON" or "DAILY ON", and press the MEMORY/SET button. 4 Press the ON/STAND-BY button to enter the power stand-by mode. Note: The timer can also be set with the remote control. CD-ES600 CD-ES66 button to select button to select button to select...
Page 30: Sleep Indicator
CD-ES600 Timer and sleep operation (continued) CD-ES66 ! Sleep operation The radio, compact disc and cassette tape can all be turned off automatically. Play back the desired sound source. Press the CLOCK/TIMER button. Within 10 seconds, press the button to select "SLEEP", and press the MEMO-...
Page 31: Enhancing Your System
(CD/TAPE/TUNER/GAME). ! To record on a tape from Game, VCR etc. Insert a cassette in the TAPE 2 cassette compartment. Press the GAME/VIDEO button. Press the button. Press the button. Play the game system, VCR, etc. Yellow CD-ES600 CD-ES66...
Page 32: Troubleshooting Chart
Troubleshooting chart Many potential problems can be resolved by the owner without call- ing a service technician. If something is wrong with this product, check the following before calling your authorized SHARP dealer or service center. ! General Symptom Possible cause "...
Page 33 While pressing down the button and the X-BASS/DEMO but- ton, press the PRESET button until "CLEAR AL" appears. Caution: This operation will erase all data stored in memory including clock, timer settings, tuner preset, and CD program. CD-ES600 CD-ES66...
Page 34: Maintenance
CD-ES600 CD-ES66 ! Condensation Sudden temperature changes, storage or operation in an extremely humid environment may cause condensation inside the cabinet (CD pickup, tape heads, etc.) or on the transmitter on the remote control. Condensation can cause the unit to malfunction. If this happens, leave the power on with no disc (or cassette) in the unit until normal playback is possible (about 1 hour).
Page 35: Specifications
Specifications As part of our policy of continuous improvement, SHARP reserves the right to make design and specification changes for product improvement without prior notice. The performance specification fig- ures indicated are nominal values of production units. There may be some deviations from these values in individual units.
Page 36: Consumer Limited Warranty
Product, and shall constitute full satisfaction of all claims, whether based on contract, negligence, strict liability or otherwise. In no event shall Sharp be liable, or in any way responsible, for any damages or defects in the Product which were caused by repairs or attempted repairs performed by anyone other than an authorized servicer.
