- Page 1 LC-19SB28UT LC-22SB28UT LIQUID CRYSTAL TELEVISION TÉLÉVISEUR ACL TELEVISOR CON PANTALLA DE CRISTAL LÍQUIDO OPERATION MANUAL MODE D’EMPLOI MANUAL DE OPERACIÓN IMPORTANT : Please read this operation manual before starting operating the equipment. IMPORTANT : Veuillez lire ce mode d'emploi avant de commencer à utiliser l'appareil. IMPORTANTE : Lea este manual de operación antes de comenzar a operar el equipo.
-
Page 3: Important Information
LC-19SB28UT LC-22SB28UT LIQUID CRYSTAL TELEVISION IMPORTANT: • To aid reporting in case of loss or theft, please record the TV’s model and serial numbers in the space provided. The numbers are located at the rear of the TV. IMPORTANT INFORMATION WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE. -
Page 4: License Information
Disposal of these materials may be regulated due to environmental considerations. For disposal or recycling information, please contact your local authorities, the Electronic Industries Alliance: www.eiae.org, the lamp recycling organization: www.lamprecycle.org or Sharp at 1-800-BE-SHARP (For U.S.A. Only) DECLARATION OF CONFORMITY SHARP LIQUID CRYSTAL TELEVISION, MODEL LC-19SB28UT/LC-22SB28UT. -
Page 5: Dear Sharp Customer
DEAR SHARP CUSTOMER Thank you for your purchase of the Sharp Liquid Crystal Television. To ensure safety and many years of trouble-free operation of your product, please read the Important Safety Instructions carefully before using this product. IMPORTANT SAFETY INSTRUCTIONS Electricity is used to perform many useful functions, but it can also cause personal injuries and property damage if improperly handled. - Page 6 IMPORTANT SAFETY INSTRUCTIONS • Outdoor Antenna Grounding — If an outside antenna is connected to the television equipment, be sure the antenna system is grounded so as to provide some protection against voltage surges and built-up static charges. Article 810 of the National Electrical Code, ANSI/NFPA 70, provides information with regard to proper grounding of the mast and supporting structure, grounding of the lead-in wire to an antenna discharge...
- Page 7 • If the display panel is dusty, use an anti-static brush, which is commercially available, to clean it. • To avoid scratching the frame or screen, please use a soft, lint free cloth for cleaning. Approved cleaning cloths are available directly from Sharp in single (00Z-LCD-CLOTH) or triple (00Z-LCD-CLOTH-3) packs. Call 1-800-BE-SHARP for ordering, or VISIT www.sharpusa.com/SharpDirect.
-
Page 8: Supplied Accessories
Supplied accessories Make sure the following accessories are provided with the product. Remote control unit (×1) “AA” size battery (×2) Page 8 Page 8 NOTE • Always use the AC cord supplied with the TV. QUICK REFERENCE Attaching the stand •... - Page 9 QUICK REFERENCE QUICK INSTALLATION TIPS Attach your antenna to the back of the TV. (See page 12.) Connect the AC plug for the TV into the wall outlet. AC outlet • Place the TV close to the AC outlet, and keep the power plug within reach.
- Page 10 IF THE UNIT DOES NOT POWER ON - UNPLUG THE TELEVISION FROM THE OUTLET AND REPEAT THE INSTALLATION STEPS. IF YOU STILL ENCOUNTER NO POWER, PLEASE CONTACT US AT 1-800-BE-SHARP. 2 Insert two “AA” size batteries (supplied with the product).
-
Page 11: Table Of Contents
Contents IMPORTANT INFORMATION ... 1 License information ... 2 DEAR SHARP CUSTOMER ... 3 IMPORTANT SAFETY INSTRUCTIONS ... 3 Supplied accessories ... 6 QUICK REFERENCE ... 6 Attaching the stand ... 6 Contents ... 9 Part names ... 10 TV (Front) ... 10 TV (Left) ... -
Page 12: Part Names
Part names TV (Front) Remote control sensor POWER indicator NOTE • The buttons on the main unit have the same functions as the same buttons on the remote control. Fundamentally, this operation manual provides a description based on operation using the remote control. TV (Rear) AC INPUT NOTE... -
Page 13: Remote Control Unit
Part names Remote control unit NOTE • When using the remote control unit, point it at the TV. (See page 8.) There is a protective film covering the face of the remote control. Please remove this film before use. POWER: Switch the power on or enters standby mode. (See page 18.) 0–9: Set the channel. -
Page 14: Preparation
Preparation Using the remote control unit Use the remote control unit by pointing it towards the remote control sensor on the TV. Objects between the remote control unit and the remote control sensor may prevent proper operation. Cautions regarding remote control unit •... -
Page 15: Using External Equipment
Using external equipment Experiencing HD images An HDTV without an HD source is just an ordinary TV. To enjoy HD images on the TV, you should get HD programming from the following: • Over-the-air broadcasting via HD quality antenna • HD cable/satellite subscription •... -
Page 16: Connecting To External Equipment
Connecting to External Equipment You can connect many types of external equipment to your TV. To view external source images, select the input source from INPUT on the remote control unit or on the TV. (See page 13.) For connecting the TV to external equipment, use commercially available cables. CAUTION •... -
Page 17: Connecting A Vcr, Game Console, Camcorder Or Cable/Satellite Set-Top Box
Connecting to External Equipment ■ When using Component cable (INPUT 2): • Blu-ray disc player • DVD player • HD cable/satellite set-top box Rear of the TV AUDIO-L (White) NOTE • See page 14 for connecting a Blu-ray disc player, DVD player or an HD cable/satellite set-top box to the HDMI terminal. Connecting a VCR, Game Console, Camcorder or Cable/Satellite Set-top Box ■... -
Page 18: Connecting An Audio Amplifier
Connecting to External Equipment Connecting an Audio Amplifier ■ When using coaxial cable: It is possible to output audio through the DIGITAL AUDIO COAXIAL terminal. Rear of the TV Connecting a PC ■ When using HDMI cable (INPUT 3): Rear of the TV NOTE •... -
Page 19: Displaying An Image From A Pc
Connecting to External Equipment ■ When using analog RGB cable (INPUT 4): Rear of the TV NOTE • When using an analog RGB cable, input the audio signal to the AUDIO PC/HDMI terminal of INPUT 4. Displaying an image from a PC To view an image from a PC, perform the following procedure. -
Page 20: Watching Tv
Watching TV Preparation Perform the following steps before you press POWER on the remote control unit. Insert the batteries into the remote control unit. (See page 8.) Connect the antenna cable to the TV. (See page 12.) Plug in the AC cord to the AC outlet. (See page 7.) Turning on the power Press POWER on the TV, or POWER on the remote control. -
Page 21: Auto Ch Memory
Watching TV Auto Ch Memory Auto Ch Memory makes the TV look for all channels viewable in the set area. Press MENU and the MENU screen displays. Press ▲/▼ to select “Channel”, then press ▶ or ENTER. Press ▲/▼ to select “Auto Ch Memory”, then press ▶ or ENTER. -
Page 22: Selecting The Digital Audio Language
Watching TV Selecting the digital audio language When two or more audio languages are included in a digital signal, you can select one of the audio languages. In digital TV mode, press AUDIO and the “Audio Language” menu screen displays. Press ▲/▼... -
Page 23: Favorite Channel Setting
Watching TV Favorite channel setting This function allows you to program 4 favorite channels in 4 different categories. By setting the favorite channels in advance, you can select your favorite channels easily. Programming favorite channel Select the channel you want to register as a favorite channel. -
Page 24: Closed Captions And Digital Closed Captions
Watching TV Closed captions and digital closed captions NOTE • Closed Caption might not appear according to the condition of the signal from the broadcasting station. Your TV is equipped with an internal Closed Caption decoder. It allows you to view conversations, narration and sound effects as subtitles on your TV. -
Page 25: Caption Setup
Watching TV Caption setup This function allows you to adjust the closed caption screen appearance to suit your preference. Press MENU and the MENU screen displays. Press ▲/▼ to select “Setup”, then press ▶ or ENTER. Press ▲/▼ to select “Closed Caption”, then press ▶... -
Page 26: Parental Control (V-Chip)
Watching TV Parental control (V-CHIP) V-CHIP might not function according to the condition of the signal from the broadcasting station. V-CHIP is an electronic filtering device built into your TV. This tool gives parents a great degree of control over broadcasts accessed by their children. -
Page 27: Canadian Rating Systems
Watching TV Canadian rating systems • The TV rating systems in Canada are based on the Canadian Radio-Television and Telecommunications Commission (CRTC) policy on violence in television programming. • While violence is the most important content element to be rated, the structure developed takes into consideration other program content like language, nudity, sexuality and mature themes. -
Page 28: Other Convenience Functions
Other convenience functions Menu operation buttons Use the following buttons on the remote control to operate the menu. MENU: Press to open the menu screen. ▲/▼/◀/▶: Press to select a desired item on the screen or adjust a selected item. ENTER: Press to go to the next step or complete the setting. - Page 29 Other convenience functions Icon Selected item Picture Picture Setting Brightness / Contrast / Sharpness / Color / Tint Color Temperature Backlight On / Off AV Mode Sports Standard Movie Memory View Mode Film Mode On / Off PC Setting* Hor Position / Ver Position (see pages 16, 17) Clock Phase...
-
Page 30: Appendix
Appendix Troubleshooting Problem • No power • Unit cannot be operated. • Remote control unit does not operate. • Picture is cut off/with sidebar screen. • Strange color, light color, or color misalignment • Power is suddenly turned off. • No picture •... -
Page 31: Specifications
• Typical time for power output decrease of about one-half assuming continuous use in a room with normal lighting, normal brightness and temperature at 77°F/25°C. • As part of policy of continuous improvement, SHARP reserves the right to make design and specification changes for product improvement without prior notice. The performance specification figures indicated are nominal values of production units. -
Page 32: Calling For Service
WHICH VARY FROM STATE TO STATE. The warranties given herein shall be the sole and exclusive warranties granted by Sharp and shall be the sole and exclusive remedy available to the purchaser and only for the time periods set forth herein. No other representations or promises made by anyone are permitted.
