Page 1 SHARP ELECTRONICS CORPORATION Sharp Plaza, Mahwah, New Jersey 07430-2135 SHARP CORPORATION Printed on post-consumer recycled paper. Imprimé sur du papier recyclé. Impreso en papel reciclado. Impresso em papel reciclado pós utilização. Printed in Japan Imprimé au Japon Impreso en Japón Impresso no Japão...
Page 2: Operation Manual
LIQUID CRYSTAL TELEVISION IMPORTANT: To aid reporting in case of loss or theft, please record the TV’s model and serial numbers in the space provided. The numbers are located at the rear of the TV. IMPORTANT INFORMATION WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE.
Page 3 IMPORTANT INFORMATION WARNING: FCC Regulations state that any unauthorized changes or modifications to this equipment not expressly approved by the manufacturer could void the user’s authority to operate this equipment. CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY INSERT. “Note to CATV system installer: This reminder is provided to call the CATV system installer’s attention to Article 820-40 of the National Electrical Code that provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the grounding system of the building, as close to the point of cable entry as practical.”...
Page 4: Dear Sharp Customer
DEAR SHARP CUSTOMER Thank you for your purchase of the Sharp LCD Color TV product. To ensure safety and many years of trouble-free operation of your product, please read the Safety Precau- tions carefully before using this product. IMPORTANT SAFETY PRECAUTIONS Electricity is used to perform many useful functions, but it can also cause personal injuries and property damage if improperly handled.
Page 5 IMPORTANT SAFETY PRECAUTIONS (Continued) I Cleaning—Unplug the power cord from the AC outlet before cleaning the product. Use a damp cloth to clean the product. Do not use liquid cleaners or aerosol cleaners. I Water and moisture—Do not use the product near water, such as bathtub, washbasin, kitchen sink and laundry tub, swimming pool and in a wet basement.
Page 6: Important Safety Precautions
IMPORTANT SAFETY PRECAUTIONS (Continued) I If an outside antenna is connected to the television equipment, be sure the antenna system is grounded so as to provide some protection against voltage surges and built-up static charges. Section 810 of the National Electrical Code provides information with respect to proper grounding of the mast and supporting structure, grounding of the lead-in wire to an antenna discharge unit, size of grounding conductors, Iocation of antenna-discharge unit, connection to grounding elec- trodes, and requirements for the grounding electrode.
Page 7: Table Of Contents
CONTENTS DEAR SHARP CUSTOMER ... 3 IMPORTANT SAFETY PRECAUTIONS ... 3-5 SUPPLIED ACCESSORIES ... 7 PREPARATION ... 8-10 Using the Remote Control ... 8 Batteries for the Remote Control ... 8 Power Connection ... 9 Antenna Connection ... 9, 10 FRONT AND REAR CONTROL OPTIONS ...
Page 8: Supplied Accessories
SUPPLIED ACCESSORIES Make sure the following accessories are provided with the product. Remote Control RRMCGA077WJSA (LC-13/15E1U) RRMCGA077WJSB (LC-13/15E1UB) RRMCGA077WJSC (LC-13/15E1UW) Antenna Cable QCNWG0003CEPA AC Adapter UADP-0212CEZZ UADP-A009WJPZ “AAA” size (UM/SUM-4) Dry Battery (×2) UBATU0038CEZZ AC Cord QACCD3097CEPA Operation Manual Cable Clamp LHLDW0109CESA UBATU0026GEZZ (LC-13/15E1U, LC-13/15E1UW)
Page 9: Preparation
PREPARATION Using the Remote Control I Use the remote control by pointing it towards the remote sensor window on the main unit. Objects between the remote control and sensor window may prevent proper operation. Cautions regarding use of remote control I Do not expose the remote control to shock.
Page 10: Power Connection
“B” position on the RF switch (not supplied) : You can view the scrambled channels via the converter/ RF switch (not supplied) • Consult your SHARP Dealer or Service Center for the type of splitter, RF switch or combiner that might be required.
Page 11 PREPARATION (Continued) Antenna Connection (Continued) ANTENNAS • The antenna requirements for good color television reception are more important than those for black & white television reception. For this reason, a good quality outdoor antenna is strongly recommended. The following is a brief explanation of the type of connections that are provided with the various antenna systems.
Page 12: Front And Rear Control Options
FRONT AND REAR CONTROL OPTIONS Main unit (front view) Upper control panel Remote sensor window POWER indicator A green indicator lights when the power is on and a red indicator lights when in the standby mode (the indicator will not light when the main power is off). •...
Page 13 FRONT AND REAR CONTROL OPTIONS (Continued) Main unit (rear view) VIDEO V ID E O AUDIO (L) /O U T A V -I N 2 AUDIO (R) A U D IO O N E N T C O M P AUDIO (L) A U D IO AUDIO (R)
Page 14: Removing The Back Cover
FRONT AND REAR CONTROL OPTIONS (Continued) Removing the Back Cover I Before connecting a connection cord into the rear terminal, remove the back cover. Push in the tab and pull out the back cover carefully. I To mount the cover, insert the 2 hooks on the bottom of the cover into the cabinet and press on the upper part of the back cover until the tab locks in place with a click.
Page 15: Ez Setup
EZ SETUP EZ SETUP during the First Power On Control section of main unit MAIN POWER MENU TV/VIDEO MAIN POWER DISPLAY SLEEP PIC. FLIP MENU MUTE BRIGHT TV/VIDEO MENU/ FLASHBACK a/b/c/d • Do not let the EZ SETUP screen display unattended for a long time. •...
Page 16: Remote Control
REMOTE CONTROL POWER (p. 17) DISPLAY* SLEEP (p. 20) BRIGHT (p. 21) MUTE (p. 17) VOL(+)/(–) (p. 17) CH ( )/( ) (p. 18) MTS* (p. 17) BASIC OPERATION This product is factory set to comply with the TV broadcasting system in the United States. For Brazil, Argentina and Uruguay, set the color system according to the country before using this product by following the table below.
Page 17: Turning On Power
BASIC OPERATION (Continued) Turning on POWER Control section of main unit MAIN POWER MENU TV/VIDEO MAIN POWER POWER indicator Switching TV/VIDEO [AV1/AV2/COMPONENT/TV] Modes DISPLAY SLEEP PIC. FLIP MENU MUTE BRIGHT TV/VIDEO FLASHBACK TV/VIDEO Press MAIN POWER, located on the upper side of the main unit, to The POWER indicator instantane- ously changes from red to green and the main unit is turned on.
Page 18: Sound Volume
BASIC OPERATION (Continued) Sound Volume POWER DISPLAY SLEEP PIC. FLIP MENU MUTE BRIGHT TV/VIDEO MUTE FLASHBACK (+)/(–) ON/OFF Standby DISPLAY SLEEP PIC. FLIP MENU MUTE BRIGHT TV/VIDEO POWER FLASHBACK Press VOL (+) to increase the sound volume. The segment of the indicator increases.
Page 19: Basic Operation
BASIC OPERATION (Continued) Changing the Channels Changing channels by using Channel Select on the remote control • This LCD TV set allows you to select up to 125 channels (1 to 125). To select a channel, enter a 2- or 3-digit number. DISPLAY SLEEP PIC.
Page 20: Selecting Menu Items
SELECTING MENU ITEMS Selecting Menu Items • This LCD TV set allows you to adjust the various settings using the menu screen. Select the desired menu item by following the steps below and then refer to the indicated page for details. DISPLAY SLEEP PIC.
Page 21: Adjustment
ADJUSTMENT Adjusting the SLEEP TIMER Settings You can set the SLEEP TIMER to automatically turn off the TV. DISPLAY SLEEP PIC. FLIP MENU SLEEP MUTE BRIGHT TV/VIDEO FLASHBACK DISPLAY SLEEP PIC. FLIP MENU MUTE BRIGHT TV/VIDEO MENU/ a/b/c/d FLASHBACK • When you set the SLEEP TIMER, the SLEEP indicator lights. •...
Page 22: Adjusting The Brightness Settings
ADJUSTMENT (Continued) Adjusting the BRIGHTNESS Settings You can set the brightness of the screen. DISPLAY SLEEP PIC. FLIP MENU MUTE BRIGHT TV/VIDEO FLASHBACK BRIGHT DISPLAY SLEEP PIC. FLIP MENU MUTE BRIGHT TV/VIDEO MENU/ FLASHBACK a/b/c/d Directly setting the BRIGHTNESS Press BRIGHT to display the BRIGHTNESS screen.
Page 23: Adjusting The Picture Flip Settings
ADJUSTMENT (Continued) Adjusting the PICTURE FLIP Settings You can set the orientation of the picture. DISPLAY SLEEP PIC. FLIP PIC. FLIP MENU MUTE BRIGHT TV/VIDEO FLASHBACK DISPLAY SLEEP PIC. FLIP MENU MUTE BRIGHT TV/VIDEO MENU/ FLASHBACK a/b/c/d Directly setting the PICTURE FLIP Press PIC.
Page 24: Adjusting The Language Settings
ADJUSTMENT (Continued) Adjusting the LANGUAGE Settings The language for the On-Screen Display can be ENGLISH, SPANISH or FRENCH. DISPLAY SLEEP PIC. FLIP MENU MUTE BRIGHT TV/VIDEO MENU/ FLASHBACK a/b/c/d Press MENU to display the MENU screen. Press a/b to move the cursor to SET UP.
Page 25: Adjusting The Video Adjust Settings
ADJUSTMENT (Continued) Adjusting the VIDEO ADJUST Settings DISPLAY SLEEP PIC. FLIP MENU MUTE BRIGHT TV/VIDEO MENU/ FLASHBACK a/b/c/d Press MENU to display the MENU screen. Press a/b to move the cursor to VIDEO ADJUST. Press c/d to enter. Press a/b to move the cursor to the desired item.
Page 26 When the picture or sound is not stable, set a specific COLOR SYSTEM (not AUTO). The picture and sound may be improved. Press d Increase contrast Toward green Higher color intensity More brightness Sharp picture Press d Increase contrast Toward green Higher color intensity More brightness Sharp picture...
Page 27: Adjusting The Preset Settings
ADJUSTMENT (Continued) Adjusting the PRESET Settings DISPLAY SLEEP PIC. FLIP MENU MUTE BRIGHT TV/VIDEO MENU/ FLASHBACK a/b/c/d Selected item Factory setting BRIGHTNESS [BRIGHT] AUTO POWER OFF [OFF] (only TV mode) PICTURE FLIP [NORMAL] Normal image AV2 IN/OUT [IN] Press MENU to display the MENU screen.
Page 28: Set Up
ADJUSTMENT (Continued) SET UP I CHANNEL SETTING It is necessary to set the receiving mode to AIR or CABLE channels to receive locally broadcast TV programs. DISPLAY SLEEP PIC. FLIP MENU MUTE BRIGHT TV/VIDEO MENU/ FLASHBACK a/b/c/d • Receivable channels of your TV set are: AIR channels: VHF: 2 through 13.
Page 29 ADJUSTMENT (Continued) SET UP (Continued) I Saving broadcast TV channels in the memory DISPLAY SLEEP PIC. FLIP MENU MUTE BRIGHT TV/VIDEO MENU/ FLASHBACK a/b/c/d I Adding weak or additional channels or erasing unwanted channels from TV memory DISPLAY SLEEP PIC. FLIP MENU MUTE BRIGHT...
Page 30: Adjusting The Blue Screen Settings
ADJUSTMENT (Continued) Adjusting the BLUE SCREEN Settings I BLUE SCREEN Automatically turns the screen blue if a broadcast signal is not received. DISPLAY SLEEP PIC. FLIP MENU MUTE BRIGHT TV/VIDEO MENU/ FLASHBACK a/b/c/d • When received signals are weak or interfered with by some other signals, the BLUE SCREEN function may be activated.
Page 31: Adjusting The Closed Caption Settings
ADJUSTMENT (Continued) Adjusting the CLOSED CAPTION Settings I SETTING CLOSED CAPTION • This TV set is equipped with an internal Closed Caption decoder. “Closed Caption” is a system which allows conversations, narration, and sound effects in TV programs and home videos to be viewed as captions on the TV screen (see the illustration). •...
Page 32 ADJUSTMENT (Continued) Adjusting the CLOSED CAPTION Settings (Continued) I SETTING CLOSED CAPTION DISPLAY SLEEP PIC. FLIP MENU MUTE BRIGHT TV/VIDEO MENU/ FLASHBACK a/b/c/d Setting the CLOSED CAPTION on the MENU screen Press MENU to display the MENU screen. Press a/b to move the cursor to CLOSED CAPTION.
Page 33: Adjusting The V-Chip Settings
ADJUSTMENT (Continued) Adjusting the V-CHIP Settings I V-CHIP • This function allows TV programs to be restricted and TV usage to be controlled based on FCC data. It prevents children from watching violent or sexual scenes that may be harmful. •...
Page 34 ADJUSTMENT (Continued) Adjusting the V-CHIP Settings (Continued) [2] TV PARENTAL GUIDELINES RATING TV-Y (All children) TV-Y7 (Direct to Older Children) ⇑ TV-G (General Audience) TV-PG (Parental Guidance base Suggested) ⇓ TV-14 (Parents Strongly Cautioned) TV-MA (Mature Audience Only) : The content rating can be set, but this rating is not normally broadcast by TV stations. ✕...
Page 35: I Setting V-Chip
ADJUSTMENT (Continued) Adjusting the V-CHIP Settings (Continued) I SETTING V-CHIP [1] MPAA RATING DISPLAY SLEEP PIC. FLIP MENU MUTE BRIGHT TV/VIDEO MENU/ a/b/c/d FLASHBACK Channel Select • If you set G to BLOCK, all ratings are automatically blocked. • If you set X to BLOCK, G, PG, PG-13, R and NC-17 are not blocked. Press MENU to display the MENU screen.
Page 36 ADJUSTMENT (Continued) Parent Control (V-CHIP Operation Continued) Adjusting the V-CHIP Settings (Continued) [2] TV GUIDELINES G Setting TV GUIDELINES DISPLAY SLEEP PIC. FLIP MENU MUTE BRIGHT TV/VIDEO MENU/ FLASHBACK a/b/c/d G Setting BLOCK CONTENT DISPLAY SLEEP PIC. FLIP MENU MUTE BRIGHT TV/VIDEO MENU/...
Page 37 ADJUSTMENT (Continued) Adjusting the V-CHIP Settings (Continued) [3] ACTIVATING V-CHIP BLOCK G Setting STATUS You can activate V-CHIP BLOCK after setting [1] MPAA RATING and/ or [2] TV GUIDELINES. DISPLAY SLEEP PIC. FLIP MENU MUTE BRIGHT TV/VIDEO MENU/ a/b/c/d FLASHBACK Channel Select [4] CANCELING THE V-CHIP BLOCK SCREEN WHILE V-CHIP BLOCK IS ACTIVATED...
Page 38: Adjustment
ADJUSTMENT (Continued) Adjusting the V-CHIP Settings (Continued) [5] CHANGING THE V-CHIP BLOCK SETTINGS DISPLAY SLEEP PIC. FLIP MENU MUTE BRIGHT TV/VIDEO FLASHBACK Channel Select [6] CHANGING OR CLEARING THE SECRET NUMBER If you forget the secret number, clear the secret number as follows. Upper control panel of the main unit MENU...
Page 39: Connecting With External Devices
CONNECTING WITH EXTERNAL DEVICES You can enjoy picture and sound by connecting a VCR or a home video game system to the terminals located on the rear of the TV set. When connecting an external device, turn off the power of the main unit first to prevent any possible damage.
Page 40 CONNECTING WITH EXTERNAL DEVICES (Continued) Connecting a VCR, DVD player or a video camera (AV-IN1/2/COMPONENT) V ID E O /O U T A V -I N 2 A U D IO O N E N T C O M P A U D IO V ID E O A V -I N...
Page 41: How To Fix The Cables
CONNECTING WITH EXTERNAL DEVICES (Continued) Outputting video and audio (video output) You can output video and audio data from the TV set through the AV output terminals (AV-OUT). • When using as an OUTPUT terminal, select PRESET in the MENU and set AV2 IN/OUT to OUT. (See page 26.) •...
Page 42: Troubleshooting
TROUBLESHOOTING I Before calling for repair service, check the following items for possible remedies to the encountered symptoms. TV set Problem Picture Sound There is no picture or sound. There is no Picture picture. There is no picture from AV-IN1. There is no sound.
Page 43 TROUBLESHOOTING (Continued) Antenna Problem The picture is not sharp. The picture moves. The picture is doubled or tripled. The picture is spotted. There are stripes on the screen or colors fade. I Cautions regarding use in high and low temperature environments •...
Page 44: Specifications
Weight Accessories As a part of policy of continuous improvement, SHARP reserves the right to make design and specification changes for product improvement without prior notice. The performance specification figures indicated are nominal values of production units. There may be some deviations from these values in individual units.
Page 45: Dimensional Drawings
DIMENSIONAL DRAWINGS LC-13E1U (158) (150) (257) (187) (97) (59) (147) MENU TV/VIDEO MAIN POWER (337) POWER SLEEP 3.9/100 (100) VIDEO AV-IN 1 AUDIO VIDEO S-VIDEO AV-IN 2/OUT AUDIO HEAD PHONE ANT. COMPONENT AUDIO POWER INPUT DC12V Unit: inch/(mm)
Page 46: Dimensional Drawings
DIMENSIONAL DRAWINGS (Continued) LC-15E1U (167) (159) (267) (212) (97) (59) (156) MENU TV/VIDEO MAIN POWER (379) POWER SLEEP 3.9/100 (100) VIDEO AV-IN 1 AUDIO VIDEO S-VIDEO AV-IN 2/OUT AUDIO HEAD PHONE COMPONENT ANT. AUDIO POWER INPUT DC12V Unit: inch/(mm)
Page 47: Calling For Service
Product, and shall constitute full satisfaction of all claims, whether based on contract, negligence, strict liability or otherwise. In no event shall Sharp be liable, or in any way responsible, for any damages or defects in the Product which were caused by repairs or attempted repairs performed by anyone other than an authorized servicer.
Page 48 (b) Any Sharp product tampered with, modified, adjusted or repaired by any party other than Sharp, Sharp’s Authorized Service Centres or Sharp’s Authorized Servicing Dealers. (c) Damage caused or repairs required as a result of the use with items not specified or approved by Sharp, including but not limited to head cleaning tapes and chemical cleaning agents.
