CONTENTS
SAFEGUARDS ................................................................... 2-4
• Supplied Accessories ............................................................. 5
• Before Operating Your Television ............................................ 5
• Antenna Connections ......................................................... 5, 6
• Quick Reference Control Operation ........................................ 7
• EZ SETUP during First Use .................................................... 8
• Demo Mode ............................................................................ 9
Remote Control ...................................................................... 9
• Language .............................................................................. 10
• Sleep Timer .......................................................................... 10
• Video Adjust ......................................................................... 11
• Audio Select .................................................................... 12, 13
MTS (Multichannel TV Sound) ......................................... 12
EQUISOUND .................................................................... 12
SPEAKER (Internal Speaker Switch) ............................... 12
FAO (Fixed Audio Output) ................................................ 12
SRS .................................................................................. 12
AUDIO ADJUST ............................................................... 13
This operation manual includes basic operating instructions
in Spanish and French.
SPANISH is on page 48-52.
FRENCH is on page 53-57.
36F630(01-04)
COLOR TELEVISION
H OPERATION MANUAL H
®
S
P
TAR
artner, SHARP has determined that this product meets the
®
guidelines for energy efficiency.
PAGE
• Closed Caption .................................................................... 14
• Parent Control ................................................................. 15-25
V-CHIP Operation ....................................................... 15-22
VIEW TIMER .............................................................. 23-25
• Energy Save ........................................................................ 26
• Set Up ............................................................................. 27-33
EZ Setup ......................................................................... 27
Channel Setting .......................................................... 28-30
Blue Screen ............................................................... 30, 31
Personal Preference ........................................................ 32
Universal Plus Function ................................................... 33
• Auto Input ............................................................................ 34
• CH/Input ID .................................................................... 35, 36
• Screen Format ..................................................................... 37
• Using the Video and Audio Input Terminals ................... 38, 39
• Using the Audio Output Terminals ....................................... 40
• Operation of Universal Remote Control .......................... 41-45
• Before Calling for Service .................................................... 46
• Calling for Service ............................................................... 46
• Specifications ...................................................................... 47
• Limited Warranty .................................................................. 58
1
MODEL
36F630
®
E
S
U.S.
NERGY
TAR
is a
registered
A679WJ
03.3.5, 2:37 PM
Dimension: 140mm x 215mm
PAGE
1
Advertisement
Table of Contents
Related Manuals for Sharp 36F630
Summary of Contents for Sharp 36F630
-
Page 1: Table Of Contents
FRENCH is on page 53-57. 36F630(01-04) COLOR TELEVISION MODEL 36F630 H OPERATION MANUAL H artner, SHARP has determined that this product meets the ® NERGY PAGE • Closed Caption ... 14 • Parent Control ... 15-25 V-CHIP Operation ... 15-22 VIEW TIMER ... -
Page 2: Important Information/Important Safeguards
Welcome to the SHARP Family. We are pleased that you are now the owner of a SHARP Color Television – built for outstanding quality, reliability and performance. Every SHARP Color Television set is tuned and adjusted for proper color and sound, and has passed through the most stringent quality control tests at the factory. -
Page 3: Important Safeguards
12. Do not allow anything to rest on the power cord. Do not locate this television equipment where the cord will be abused by persons walking on it. 36F630(01-04) (Continued) 03.3.5, 2:37 PM Dimension: 140mm x 215mm... -
Page 4: Safeguards
22. When replacement parts are required, be sure the service technician has used replacement parts specified by the manufacturer that have the same characteristics as the original part. Unauthorized substitutions may result in fire, electric shock, or other hazards. 36F630(01-04) (Continued) ANTENNA... -
Page 5: Supplied Accessories
(not supplied). 2. A 300-ohm system is a flat “twin-lead” cable that can be attached to a 75-ohm terminal through a 300/75-ohm ADAPTOR (not supplied). 36F630(05-06) Size AA Dry Batteries B a t t e r y... -
Page 6: Antenna Connections
“B” position on the RF switch (not supplied) : You can view the scrambled channels via the converter/ RF switch (not supplied) Cable TV converter/ descrambler (not supplied) Note: • Consult your SHARP Dealer or Service Center for the type of splitter, RF switch or combiner that might be required. 36F630(05-06) B. Separate VHF/UHF Antenna ANTENNA ANTENNA... -
Page 7: Quick Reference Control Operation
• The degree of illumination will decrease with time and depending on the temperature. • The time needed to charge the phosphorescent display will vary depending on the surrounding lighting. • Sunlight and fluorescent lighting are the most effective when charging the display. 36F630(07) VIDEO/AUDIO POWER MENU –... -
Page 8: Ez Setup During First Use
• It may be difficult to PRESET when the broadcast signals are weak, the channel cycle frequency is incorrect or frequency jamming is occurring around the area. Please refer to pages 28–30 for more information on manually memorizing the channels using CHANNEL SETTING. 36F630(08-09) SEL ECT LANGUAGE... -
Page 9: Demo Mode
MAIN MENU screen by pressing MENU on the TV set. • Some features of your TV set are not accessible without the Remote Control. If you lost your Remote Control, contact a Sharp Service Center for a replacement. -
Page 10: Language
4 seconds. The SLEEP TIMER shows a similar display for each remaining minute and a 10-second display right before shutting off the TV. • If you turn the POWER OFF, the SLEEP TIMER will automatically reset. 36F630(10-11) MENU SLEEP T I MER... -
Page 11: Video Adjust
• VIDEO ADJUST setting, once set, is shared among AIR/CABLE, INPUT 1, INPUT 2, and INPUT 3 modes. • VIDEO ADJUST setting for INPUT 3 when used as COMPONENT can be set independently. 36F630(10-11) VOL l button To decrease contrast... -
Page 12: Audio Select
Press CH a/s to move the “E” mark to “AUDIO SELECT”. Press VOL k/l to access the AUDIO SELECT screen. Press CH a/s to move the “E” mark to “MTS”, “EQUISOUND”, “SPEAKER”, “FAO”, “SURROUND” or “AUDIO ADJUST”. 36F630(12-13) MENU SLEEP T I MER V I DEO ADJ UST... -
Page 13: Srs
• Selecting MTS while receiving video signals from INPUT terminals does not change the type of sound; in this case, sound is determined by the video source. • If “FAO” mode is on, “SPEAKER” mode will automatically turn off. Changing “SPEAKER” setting will not affect “FAO” mode. 36F630(12-13) AU I O EQU I SOUND SPEAKER... -
Page 14: Closed Caption
• If no TEXT broadcast is being received while viewing in the TEXT mode, the screen may become dark and blank for some programs. Should this occur, switch the Closed Caption mode to “OFF”. 36F630(14-18) MENU SLEEP T I MER... -
Page 15: Parent Control
TV-MA (Mature Audience Only) : Content Rating can be set. – : Content Rating cannot be set (not normally broadcast by TV station). 36F630(14-18) Example 2: “R” in the age-based rating is blocked, this will automatically block the higher rating “NC-17”, “X”... - Page 16 • Clearing a higher rating’s age or content setting will not clear lower settings. Make sure that all undesired boxes are blocked. [3] ADDITIONAL MODE Besides “MPAA RATINGS” and “TV PARENTAL GUIDELINES”, new ratings system’s data can be downloaded when they become available. (See page 19.) 36F630(14-18) G A E TV–Y – –...
-
Page 17: Mpaa Rating
“E” mark to “PG”, then press VOL k/l to select BLOCK. If you set “PG” to BLOCK, “PG-13”, “R”, “NC-17” and “X” are automatically blocked. Press MENU to return to the V-CHIP select screen. 36F630(14-18) MENU SLEEP T I MER V I DEO ADJ UST... - Page 18 When done, press MENU to return to V-CHIP selct screen. Press MENU to exit. Note: • If SECRET No. is not set, enter a SECRET No. as show in steps 7 and 8 of [1] MPAA RATING. 36F630(14-18) I NPUT SECRET No . – – – –...
- Page 19 If you watch a program containing “new rating system data”, the DOWNLOAD screen will be displayed. The DOWNLOAD screen will disappear once downloading is finished. Note: • DOWNLOAD will not start, if you are not watching a program containing “new rating system data”. 36F630(19-22) REMOTE KEYPAD VOLUME (k)/(l)
- Page 20 CH a/s and VOL k/l if you select “Cdn. French Ratings” in step 2. Note: • You are able to download up to 4 different rating systems. 36F630(19-22) MPAA TV GU I E D L I NES Cd n .
- Page 21 No. is chosen, “SECRET No. IS INCORRECT” will be displayed. Input the SECRET No. again in this case. Note: • If you turn the Power ON from OFF, the V-CHIP BLOCK will be activated again. 36F630(19-22) MPAA TV GU I E D L I NES DOWNL OAD : OF F →...
- Page 22 Press and hold both VOL k and CH a on the TV set simultaneously until the message “INPUT SECRET No.” disappears. Press the MENU button twice to exit. 36F630(19-22) I NPUT SECRET No . – – – – I NPUT SECRET No .
-
Page 23: View Timer
ON the “VIEW TIMER”. (If STATUS is OFF, VIEW TIMER will not operate.) Press MENU. “INPUT SECRET No.” will be displayed. Note: • If SECRET No. is already set, skip to step 10. 36F630(23-26) V I EW T I MER V I EWI NG T I ME – –H –... - Page 24 KEYPAD. When you choose the correct SECRET No., the VIEW TIMER is canceled. If the wrong SECRET No. is chosen, “SECRET No. IS INCORRECT” is displayed. Input the SECRET No. again in this case. 36F630(23-26) I NPUT SECRET No . 1 2 3 4 MENU →...
-
Page 25: Parent Control
4 seconds. For the last 5 minutes, the remaining time will be displayed every minute. • “0 REMAIN” will be displayed for 10 seconds just before the VIEWING TIME expires. 36F630(23-26) I NPUT SECRET No . – – – –... -
Page 26: Energy Save
Press CH a/s to move the “E” mark to “ENERGY SAVE”. Press VOL k/l to access the ENERGY SAVE select screen. Press VOL k/l to select “ON”. Press MENU to exit. 36F630(23-26) MENU SLEEP T I MER V I DEO ADJ UST... -
Page 27: Set Up
If you want to stop the EZ SETUP process once it has started, press VOL l. Search will be canceled. To cancel EZ SETUP Press VOL l. Once EZ SETUP is complete, the lowest channel number memorized will be displayed. 36F630(27-29) VOLUME (k)/(l) CHANNEL UP (a)/ DOWN (s) -
Page 28: Channel Setting
Press MENU to exit. Note: • Receivable channels of your TV set are: AIR channels: VHF: 2 through 13. UHF: 14 through 69. 36F630(27-29) MENU SLEEP T I MER V I DEO ADJ UST AUD I O SEL ECT CLOSED CAPT I ON... - Page 29 CH a/s to move the “E” mark to “CH MEMORY”. Press VOL k/l to access CH MEMORY. Use CH a/s or REMOTE KEYPAD to select each desired channel to add or erase. 36F630(27-29) CH SETT I NG MENU → EZ SETUP...
-
Page 30: Blue Screen
Press CH a/s to move the “E” mark to “SET UP”. Press VOL k/l to access the SET UP screen. Press VOL k/l to access the BLUE SCREEN select screen. Press VOL k/l to select “ON”. 36F630(30-37) MEMORY A I R ERASE... -
Page 31: Blue Screen
To continue watching TV under these conditions, switch the BLUE SCREEN “OFF”. • While INPUT1, 2 or 3 (COMPONENT) is selected, the BLUE SCREEN will not be shown even if BLUE SCREEN is turned on. 36F630(30-37) MENU Power turns off Blue screen... -
Page 32: Personal Preference
Repeat steps 5 and 6 to register the next CHANNEL Number or INPUT mode. Press MENU to exit. To select the PERSONAL PREFERENCE channel. If the channels are memorized as shown on the right, press the Remote’s “A” button to select the channels below. 36F630(30-37) PERSONAL PREFERENCE MENU SLEEP T I MER... -
Page 33: Universal Plus Function
DVD is connected to. If connected through RF (antenna terminal), select either CH3 or CH4 to match the setting of the VCR or DVD. Press MENU to exit. 36F630(30-37) MENU SLEEP T I MER V I DEO ADJ UST AUD I O SEL ECT... -
Page 34: Auto Input
Press VOL k/l to access the AUTO INPUT select screen. Press VOL k/l to select “AUTO”. You may turn off “AUTO INPUT” when it is not in use. Press VOL k/l to select “OFF”. Press MENU to exit. 36F630(30-37) VOLUME (k)/(l) CHANNEL UP (a)/... -
Page 35: Ch/Input Id
Press CH a/s to move the “E” mark to “SET UP”. Press VOL k/l to access the SET UP screen then, press CH a/s to move the “E” mark to “CH/INPUT ID” . Press VOL k/l to access the CH/INPUT ID screen. 36F630(30-37) REMOTE KEYPAD VOLUME... - Page 36 • The maximum number of ID labels available to register channel names is 20 for AIR channels and 40 for CABLE channels. • If you wish to register a new ID when all the available ID labels are assigned, delete a registered ID to make room. 36F630(30-37) ENTER : _ _ _ _ RESET MENU : RETURN →...
-
Page 37: Screen Format
Example: While in 4:3 mode, if the picture appears stretched vertically as in screen A below, switch to 16:9 mode. The picture will return to normal as shown in screen B. Screen A (4:3) 36F630(30-37) VOLUME (k)/(l) CHANNEL UP (a)/... -
Page 38: Using The Video And Audio Input Terminals
VIDEO EQUIPMENT CAMCORDER TV GAME Yellow : To video input terminal White : To audio input (L) terminal : To audio input (R) terminal 36F630(38-40) (Front connection terminals of TV) Pull open the front door IN 2 To VIDEO OUTPUT... - Page 39 VIDEO terminal (IN 1), unplug equipment connected to the S-VIDEO terminal. • It is the intent of SHARP that this product be used in full compliance with the copyright law of the United States and that prior permission be obtained from copyright owners whenever necessary.
-
Page 40: Using The Audio Output Terminals
• When FAO is set to “OFF”, we recommend you to keep the TV’s audio output level high for optimal sound quality. (see page 12.) To the TV Pin plug x 2 36F630(38-40) Stereo Amplifier Speaker System Plug adapter To the equipment... -
Page 41: Operation Of Universal Remote Control
PAUSE Press to temporarily stop the tape or disc during playback or recording (VCR only). Press again to release PAUSE. 36F630(41-43) • “Identifying” VCRs, cable TV conveters and DVDs Your Remote Control has been set at the factory to operate your TV and many remote controlled VCRs, cable TV converters and DVDs. - Page 42 , enter your VCR’s two-digit remote control code number using the REMOTE KEYPAD (refer to the list on page 43). • The remote control is now ready to send commands to your VCR. 36F630(41-43) CATV/DVD-TV/VCR DISPLAY CHANNEL UP (a)/ DOWN (s)
- Page 43 If a channel change does not occur on the VCR within 2 minutes, read the identifying instructions again and repeat the steps. Should a channel change still not occur, the Remote will not operate with the desired VCR. 36F630(41-43) REMOTE CONTROL VCR BRAND CODE NUMBER Akai...
- Page 44 (3) Within 10 seconds after releasing INPUT and , enter your DVDs two-digit remote control code number using REMOTE KEYPAD (refer to the list). • The remote control is now ready to send commands to your DVD. 36F630(44-45) CATV/DVD- TV/VCR INPUT CHANNEL UP (a)/...
-
Page 45: Operation Of Universal Remote Control
Release the DISPLAY and CH as soon as the channel numbers start to scan up. The converter’s remote control code number has been identified, and the Remote is ready to operate the converter. 36F630(44-45) REMOTE CONTROL CATV CONVERTER BRAND Anvision 07, 08... -
Page 46: Before Calling For Service
Should this occur, switch the Closed Caption mode to “OFF”. Calling for Service For location of the nearest Sharp Authorized Servicer, or to obtain product literature accessories, supplies, or customer assistance, please call 1-800-BE-SHARP. 36F630(46) -
Page 47: Specifications
Specifications MODEL 36F630 Receiving System NTSC Stereo Broadcast MTS/SAP Reception Channels 2-13 ch 14-69 ch CATV 1-125 ch Channel Tuning 181-channel Reception PLL tuning system Antenna Input Impedance VHF/UHF 75 ohm Unbalanced Screen Size 36˝ Diagonally Measured Terminals Audio/Video input x 3 (Front x 1, Rear x 2) - Page 48 Con el fin de garantizar al cliente la recepción puntual de cualquier notificación de seguridad sobre inspección, modificación o cancelación que se le pueda solicitar a SHARP bajo el Acta de seguridad de productos de consumidor de 1972. LEA CUIDADOSAMENTE LA CLÁUSULA “GARANTÍA LIMITADA” DE LA ÚLTIMA PÁGINA.
-
Page 49: Desecho Del Producto
No modifique el enchufe porque anulará esta característica de seguridad. No permita que se apoye nada sobre el cable de alimentación. No ponga este televisor donde el cable pueda ser deformado por personas que caminen sobre él. 36F630(49) (Continuación) 03.3.5, 3:09 PM... - Page 50 Cuando sea necesario cambiar piezas, cerciórese de que el técnico de servicio utiliza las piezas de CAMBIO especificadas por el fabricante, aquellas que tengan las mismas características que las piezas originales. Las piezas de recambio no autorizadas pueden causar incendios, descargas eléctricas u otros peligros. 36F630(50) (Continuación) 03.3.5, 3:09 PM Dimension: 140mm x 215mm...
- Page 51 • El grado de iluminación irá decayendo con el tiempo y dependiendo de la temperatura. • El tiempo necesario para cargar el visor fosforescente variará de acuerdo con la iluminación circundante. • La luz del sol y la luz fluorescente son las más eficaces para la carga del visor. 36F630(51-52) (ESPAÑOL) TERMINALES DE ENTRADA POWER MENU –...
-
Page 52: Antes De Llamar Al Servicio De Reparaciones
Si ocurriera ésto, ponga el modo CLOSED CAPTION en OFF. Solicitud de servicio técnico Para la localización del Servicio Técnico Autorizado de Sharp más próximo o para conseguir material de información, repuestos o asistencia técnica, llame a 1-800-BE-SHARP. 36F630(51-52) - Page 53 Grâce à elle, vous recevrez rapidement un avis de sécurité lors du contrôle, de la modification ou du rappel de votre produit que SHARP peut être amené à fournir conformément à la loi de 1972 sur la sécurité du produit de consommation.
-
Page 54: Précautions Importantes
Ne modifiez pas la fiche et ne désactivez pas cette fonction de sécurité. Ne posez rien sur le cordon d’alimentation. Ne placez pas la télévision dans un emplacement où le cordon d’alimentation est susceptible d’être endommagé par le passage répété de personnes. 36F630(53-55) (Suite) 03.3.5, 3:10 PM... - Page 55 Lorsqu’un remplacement de pièces se révèle nécessaire, veillez à ce que le technicien utilise des pièces de rechange spécifiées par le fabricant et qu’elles aient les mêmes caractéristiques que la pièce d’origine. Des remplacements non autorisés peuvent occasionner un incendie, une électrocution ou d’autres risques. 36F630(53-55) (suite) DESCENTE D’ANTENNE...
-
Page 56: Panneau Avant
• Le degré d’illumination diminuera avec le temps, en fonction de la température. • Le temps requis pour charger les touches phosphorescentes dépendra de l’éclairage environnant. • Les rayons directs du soleil et les luminaires fluorescents constituent les meilleures sources de chargement des touches phosphorescentes. 36F630(56-57) (FRANÇAIS) PRISES D’ENTRÉE POWER MENU –... - Page 57 Sous-titrage hors service. Appel au service après-vente Pour connaître l’emplacement du centre de service après-vente agréé Sharp le plus proche ou pour obtenir de la documentation sur les produits, des accessoires, des consommables ou une aide au consommateur, appelez le 1-800-BE-SHARP.
-
Page 58: Limited Warranty
Sharp to the purchaser with respect to the Product, and shall constitute full satisfaction of all claims, whether based on contract, negligence, strict liability or otherwise. In no event shall Sharp be liable or in any way responsible, for any damages or defects in the Product which were caused by repairs or attempted repairs performed by anyone other than an authorized servicer. - Page 59 Note 36F630(58-60) 03.3.5, 3:11 PM Dimension: 140 X 215 mm...
- Page 60 SHARP ELECTRONICS CORPORATION Sharp Plaza, Mahwah, New Jersey 07430-2135 Printed in Mexico TINS-A679WJZZ 03P05-MMG(J) 36F630(58-60) 03.3.5, 3:11 PM Dimension: 140 X 215 mm...
