NTSC
LIQUID CRYSTAL DISPLAY CAMCORDER
MODEL
VL - AH130U
OPERATION MANUAL
Please read this operation manual
carefully before using the VIEWCAM.
Important
For assistance in reporting the theft or loss of
this product, record on the line below the
model number and serial number which
are located on the bottom of the unit.
Please retain this information.
Model No.:
Serial No.:
• See page 54 for use of Demo mode.
