Telos VSET Quick Start Installation Manual

Desktop controller
Hide thumbs Also See for VSET:

Advertisement

Table of Contents

QUICK-START INSTALLATION GUIDE
QUICK-START INSTALLATION GUIDE
TELOS VSET DESKTOP CONTROLLER
For use with Telos VX, Hx6, and iQ6 Systems
WELCOME TO VSET DESKTOP CONTROLLER.
We have made the Telos VSet easy to set up and configure. This quick-start guide will take you through
the basic steps to configure your new VSet to start delivering top quality caller audio to your show in no
time. Before we get started, let's make sure you have what you need.

REQUIRED EQUIPMENT, CABLES, AND ACCESSORIES:

There are a few additional items required for a successful installation. Check the list below and
make sure you have what you need.
Included items:
• VSet Desktop Controller
• PoE injector & AC power cable
• Ethernet cable
Items you need to supply:
• Configured Telos VX Engine, iQ6, or Hx6 Talkshow System
• Configured Ethernet Switch (if using more than one VSet,
a computer network, or the VX Engine)
TelosAlliance.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VSET and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Telos VSET

Summary of Contents for Telos VSET

  • Page 1 We have made the Telos VSet easy to set up and configure. This quick-start guide will take you through the basic steps to configure your new VSet to start delivering top quality caller audio to your show in no time. Before we get started, let’s make sure you have what you need.
  • Page 2 If your system’s Ethernet switch provides PoE: A. Connect one end of the Ethernet cable to the VSet Ethernet port (A), connect the other end to a PoE enabled port on your configured Ethernet switch (B). Continue to Step 3.
  • Page 3 Press the “Menu” key (H) and find the “Setup” option (I). Press the numbered Line button next to “Setup”. Press the left-hand line button next to “VSet IP address”. Using the VSet numbered keypad (K), enter the IP address for your VSet. The star key “*”...
  • Page 4 “Engine IP” (P) which will then allow you to manually enter the IP address of Telos hybrid/engine you wish to connect to. Using the VSet numbered keypad (K), enter the IP address for your engine. The star key “*” is used to enter a dot “. ” , and the pound key “#” is used to backspace/delete.
  • Page 5 2. The available studios will be listed on the OLED (Q). Press the left hand line button to select your desired Studio. 3. After the studio is selected, the VSet will automatically list and select the active show. If you are operating a Telos VX, multiple shows may be available and will be listed. Select your desired show by pressing the left-hand line key next to the show name.
  • Page 6 QUICK-START INSTALLATION GUIDE THIS PAGE INTENTIONALLY LEFT BLANK...
  • Page 7 QUICK-START INSTALLATION GUIDE THIS PAGE INTENTIONALLY LEFT BLANK...
  • Page 8 Radio: +1 (216) 622-0247 TV: +1 (717) 735-3611 Radio: support@telosalliance.com TV: support@linearacoustic.com 1241 Superior Ave. • Cleveland, Ohio, 44114, USA • +1.216.241.7225 • TelosAlliance.com © 2018 TLS Corp. The Telos Alliance®. All Rights Reserved. C18/1/17045 1490-00206-002 --- QUICK START GUIDE: VSDC...
