1.1 Purpose of this manual
The purpose of this service manual is to provide service engineers who already have basic
Knowledge necessary to repair air vent dryers with electronic control systems.
1.2 Important
Repairs to electrical appliances must be carried out only by qualified service engineers
Before touching internal components, always remove the plug from the power socket
2. Technical Data
Voltage
Weight
Heater
Dimention
WxDxH
Drying system
Humidity control
Motor
Temperature control
Energy efficiency
Error alarms
3． ． ． ． Control Panel
1. Buzzer
230V 2100W
595*555*850mm
Conductimetric sensor
Single-phase asynchronous motor with capacitor
1
2 3 4
5
7. Indicator Lights
2
220V 60Hz
38 Kg
Air vented
NTC sensor
C
3
6
7
8
