- Page 1 V210/V240-R19-H Rack Mount Kit Installation Guide SHP900006-000 4/11/05 Rev 2.0 Page 1 of 4 Proprietary Information of SharkRack, Inc. 23842 Cabot Blvd., Hayward, CA 94545 87(SHARKRACK) 877-427-5722 www.sharkrack.com...
- Page 2 V210/V240-R19-H Rack Mount Kit Installation Guide Step 1. Separate the Slide Assemblies by detaching the Inner Slide Member from the Outer Slide Member. Remove the Inner Slide Member from the Slide Assembly by first fully extending the Inner Slide Member. Next depress the slide stop, which allows for the Inner Slide Member to be detached.
- Page 3 V210/V240-R19-H Rack Mount Kit Installation Guide Step 4. Install the Outer Slide Member in the rack enclosure. Attach the Front Mounting Bracket to the Front Rack Rail using (2) 10-32 x 1/2” pan head screws. Attach the Rear Mounting Bracket to the Rear Rack Rail using (3) 10-32 x 1/2”...
- Page 4 LIABILITY, EXCEED THE TOTAL AMOUNTS ACTUALLY PAID TO SELLER BY CUSTOMER UNDER THE ORDER THAT GIVES RISE TO ANY LIABILITY HEREUNDER. During the warranty period, purchaser must promptly call SharkRack (877-427-5722) to log any such defects in materials and workmanship.
