Sena X1 Pro Quick Start Manual

Smart cycling helmet
Hide thumbs Also See for X1 Pro:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Manual
SMART CYCLING HELMET
QUICK START GUIDE
1.0.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the X1 Pro and is the answer not in the manual?

Questions and answers

Related Manuals for Sena X1 Pro

Summary of Contents for Sena X1 Pro

  • Page 1 SMART CYCLING HELMET QUICK START GUIDE 1.0.0...
  • Page 2 RIDE CONNECTED Blast your favorite tunes, talk over the intercom with your buddies, hear directions from your GPS and more, all through your Sena X1 Pro Smart Cycling Helmet. With built-in Bluetooth ® capabilities, Quad HD camera, HD speakers and a microphone using Advanced Noise Control™, technology has never felt so minimal...

  • Page 3: Getting Started

    Visit Sena. com/device-manager-download/ to see how to update your product. 3. Users can follow Sena on Facebook, YouTube, Twitter and Instagram to receive the most up to date information on products, helpful tips and all other announcements regarding Sena products.

  • Page 4: How To Use This Guide

    QUICK START GUIDE How to Use This Guide The legend and callouts are here to help you read the illustrations. New technology can be confusing, but we’ve created a simple way to perform actions using illustrations. HOLD Function Button(s) to Tap or Hold Buttons Left Side...

  • Page 5: Right Side

    QUICK START GUIDE Right Side Camera Button Multi-Function Button Icon Legend Press and Hold button button the HOLD for the specifi ed amount specifi ed number of time of times Audible prompt from “Hello” the Bluetooth Module...
  • Page 6 QUICK START GUIDE Helmet Structure Left Side MicroSD Bluetooth Card Slot Buttons Action Camera DC Power Charging & Firmware Upgrade Port Speakers...
  • Page 7 QUICK START GUIDE Right Side Camera Control Buttons Microphone...

  • Page 8: Basic Operation

    QUICK START GUIDE Basic Operation Left Side (-) Button (+) Button Decrease Volume Increase Volume Track Back Track Forward FM Radio On/Off Scan Radio Stations Speed Dial Blue/Red/Green Fault Reset LED Lights Button Center Button Answer/End Phone Call Reject an Incoming Phone Call Start/End Intercom Conversation Play/Pause Music Enter Intercom Pairing Mode...

  • Page 9: Front Side

    QUICK START GUIDE Right Side Multi-Function Button WiFi Power On/Off Multi-Function Button Enter Camera WiFi Power On/Off Confi guration Settings Enter Camera Confi guration Settings Camera Button Camera Power On/Off Camera Button Start/Stop Recording Camera Power On/Off Start/Stop Recording Front Side Camera LED Lights Camera LED Lights...
  • Page 10 QUICK START GUIDE How To Fit the Helmet 1. Position the helmet on your head with the front covering your forehead. 2. Position the strap adjuster centered, just below your ears. 3. Position the helmet low on your forehead with the buckle under the chin and back against the throat.
  • Page 11 QUICK START GUIDE 4. Adjust the chinstrap tension at the buckle so the chinstrap is tight and comfortable by pulling the chinstrap end through the buckle to either tighten or loosen as needed. Use the “O-Ring” to secure the excess strap. Chinstrap O-Ring Note: Check the chinstrap’s position and tension...
  • Page 12 QUICK START GUIDE 5. Turn the retention system knob clockwise to tighten or counterclockwise to loosen. Retention System Knob 6. To change the height of the retention system, firmly pull or push the retention system upward or downward to a different position.

  • Page 13: Basic Operations

    QUICK START GUIDE Basic Operations Powering On Powering Off HOLD POWER POWER Volume Down Volume Up VOLUME VOLUME DOWN Checking the Battery Level There are two ways to check the battery levels, visually using the LED lights, and audibly. Instructions are for when powering the Bluetooth Module on.

  • Page 14: Bluetooth Pairing

    QUICK START GUIDE Bluetooth Pairing (Phone, MP3, GPS) Mobile Phone Pairing Steps continued... HOLD “Phone pairing” Alternating blue CONFIG. MENU and red fl ashing lights indicate device is now “Confi guration menu” discoverable. STATUS NAVIGATE FORWARD NUMBER Mobile Phone Answer a Call Make Call with Voice Dialer HOLD...

  • Page 15: Music Controls

    HOLD “[Camera On]” “[Recording]” Camera Off Stop Recording HOLD HOLD “[Camera Off]” “[Recording stopped]” Note: • You cannot record videos without a microSD card. • Your SD card needs to be formatted using the X1 Pro before using the camera.

  • Page 16: Intercom Pairing

    QUICK START GUIDE Intercom Pairing Up to three people can communicate via intercom with the X1 Pro Smart Cycling Helmet simply by pairing their headsets. Intercom Pairing Pairing with Intercom B HOLD “Intercom pairing” Flashing blue LED confi rms intercoms are paired.

  • Page 17: Two-Way Intercom

    QUICK START GUIDE Two-Way Intercom Last-Come, First-Served Start/End with Intercom Friend 1 Intercom Friend 1 Start/End with Intercom Friend 2 Intercom Intercom Friend 1 Friend 2 Start/End with Intercom Friend 3 Intercom Intercom Intercom Friend 1 Friend 2 Friend 3 Group Intercom Start Group Intercom End Group Intercom...
  • Page 18 QUICK START GUIDE Radio FM Radio On Seek and Save Stations HOLD SEEK FORWARD “[Beep, Beep]” FM Radio Off SEEK BACKWARD HOLD HOLD ENTER PRESET “[Beep, Beep]” MODE “Preset (#)” Scan and Save Stations HOLD CHOOSE START PRESET # SCANNING HOLD SAVE TO SAVE...
  • Page 19 QUICK START GUIDE Navigating Preset Stations HOLD NAVIGATE FORWARD Note: You can also use the Sena Device Manager or the Sena Smartphone App to save the preset stations. Headset Configuration Menu Accessing the Navigating Between Confi guration Menu Menu Options HOLD CONFIG.

  • Page 20: Camera Configuration Menu

    QUICK START GUIDE Camera Configuration Menu Accessing the Camera Navigating Between Confi guration Menu Menu Options HOLD CAMERA NAVIGATE CONFIG. FORWARD MENU “Camera Setup” “[Menu prompt]” Enable / Disable or Execute Menu Options NAVIGATE BACKWARD “[Menu prompt]” ENABLE/ DISABLE EXECUTE...

  • Page 21: Sena Device Manager

    Bluetooth Communication Module’s settings, as well as access the User’s and Quick Start Guides. To do so, pair your mobile phone with your X1 Pro Smart Cycling Helmet by following the instructions in the “Bluetooth Pairing (Phone, MP3, GPS)” section in this quick start guide. Run the Sena Smartphone App and configure the settings directly from your smartphone.
  • Page 22 WiFi feature on your X1 Pro Smart Cycling Helmet. To do so, connect your mobile phone with the X1 Pro Smart Cycling Helmet by following the instructions provided on the Sena Camera App.

  • Page 23: Troubleshooting

    QUICK START GUIDE Troubleshooting Factory Reset Fault Reset HOLD “Confi guration menu” Note: Fault Reset will not restore the Bluetooth module to factory default NAVIGATE settings. BACKWARD “Factory reset” EXECUTE...
  • Page 24 QUICK START GUIDE TYPE OPERATION BUTTON COMMANDS HOLD Power on/off Volume up/ Basic Volume down Operations Answer phone call HOLD End/reject phone call HOLD Mobile Voice dial Phone HOLD Speed dial HOLD Play/Pause music HOLD Track forward Music HOLD Track back QUICK REFERENCE...

  • Page 25: Quick Reference

    QUICK REFERENCE TYPE OPERATION BUTTON COMMANDS HOLD Camera On HOLD Camera Off Camera HOLD Start/Stop Recording HOLD Intercom pairing Start/end each intercom HOLD End all intercoms Intercom Start group intercom HOLD End group intercom...
  • Page 26 QUICK REFERENCE TYPE OPERATION BUTTON COMMANDS HOLD FM radio on/off HOLD Select preset Seek stations forward Seek stations backward FM Radio Scan up FM band/stop HOLD scanning Save preset while scanning...
