- Page 1 Server Technology Solutions for the Data Center Equipment Cabinet Sentry Commander - PT40 Installation and Operations Manual © 2004 Server Technology, Inc. All rights reserved.
-
Page 2: Life Support Policy
Instructions This symbol is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance. Dangerous Voltage This symbol is intended to alert the user to the presence of un-insulated dangerous voltage within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. -
Page 3: Table Of Contents
Table of Contents 1: I HAPTER NTRODUCTION Features and Benefits ...2 Technical Support ...3 Quick Start Guide...3 2: I HAPTER NSTALLATION Standard Accessories...6 Additional Required Items ...6 Equipment Overview...6 Safety Precautions ...7 Installing the Power Input Retention Bracket...7 Mounting ...7 Connecting to the Power Source ...8 Connecting Devices...8 Connecting to the Commander...8... -
Page 5: Chapter 1: Introduction
Chapter 1: Introduction EATURES AND ENEFITS Communication Access Modes ...2 Power Distribution & Remote Management ...2 Pass-Thru Port Access...2 Load and Environment Measurement ...2 Power-up Sequencing...2 Outlet Grouping...2 Security ...2 User Interfaces and LEDs...2 ECHNICAL UPPORT UICK TART UIDE... -
Page 6: Communication Access Modes
Power-up Sequencing When the PT40 Commander is powered on, each of the power outlets is powered sequentially with a two-second delay between each outlet. Power sequencing staggers the individual loads, eliminating the potential of a blown fuse or circuit breaker due to excessive in-rush current and allows circuit support for operating load capacities of 80% to 90%. -
Page 7: Technical Support
Configure new user account(s) with outlet, group and port access...16, 26 • Remove the predefined administrative user account...16, 26 Connect the Commander to the network ...8 Sentry Commander - PT40 Installation and Operations Manual Tel: 775.284.2000 Web: www.servertech.com Fax: 775.284.2065 Email: support@servertech.com... -
Page 9: Chapter 2: Installation
Chapter 2: Installation TANDARD CCESSORIES DDITIONAL EQUIRED TEMS QUIPMENT VERVIEW AFETY RECAUTIONS NSTALLING THE OWER NPUT OUNTING ONNECTING TO THE OWER ONNECTING EVICES ONNECTING TO THE OMMANDER Serial (RS232) port...8 Ethernet port...8 Modem port ...8 ETENTION RACKET OURCE... - Page 10 RJ12 AUX (For connection to optional Environmental Monitor) AC Power Inlet 100-120V PT40-H404-1-02 208-240V PT40-H404-2-02 Outlet Power Status LED Figure 2.1 Sentry PT40 Commander Views 6 • Installation RJ45 Serial (RS-232) DB9 male Modem (For connection to external modem) PASS-THRU...
-
Page 11: Safety Precautions
NOTE: A mounting bracket kit for 23” wide racks or cabinets is available. Contact your Server Technology Sales Representative for more information. Sentry Commander - PT40 Installation and Operations Manual Destiné à l'installation et l'utilisation Nur für Installation und Gebrauch an... -
Page 12: Connecting To The Power Source
Technical Specifications for more information on the Modem port. NOTE: Commander’s with the optional integrated Global Security Modem will have an RJ12 Telco port in lieu of above for connection to a standard telephone line. 8 • Installation party cables. Sentry Commander - PT40 Installation and Operations Manual... -
Page 13: Chapter 3: Operations
Chapter 3: Operations NTERFACES Outlet Naming and Grouping Usernames and Passwords HTML I NTERFACE Logging In Outlet Control Individual...12 Group...12 Environmental Monitoring Input Load ...12 Configuration System...13 Network ...13 Telnet/SSH ...14 HTTP/SSL ...14 Serial Ports...15 Outlets ...16 Groups ...16 Users...16 FTP...18 SNTP...18 SNMP...18... -
Page 14: Outlet Naming And Grouping
Usernames may contain from 1-16 characters and are not case sensitive; spaces are not allowed. Passwords may contain up to 16 characters, and are case sensitive. 10 • Operations Sentry Commander - PT40 Installation and Operations Manual... -
Page 15: Html Interface
If you enter an invalid username or password, you will be prompted again. You are given three attempts to enter a valid username and password combination. If all three fail, the session ends and a protected page will be displayed. Sentry Commander - PT40 Installation and Operations Manual User/Navigation... -
Page 16: Outlet Control
Sentry at the time the page was loaded. This page will refresh automatically every 10 seconds. 12 • Operations * Control State will be applied when communication is re-established Installation and Operations Manual Sentry Commander - PT40... -
Page 17: Configuration
NOTE: The unit must be restarted after network configuration changes. See Performing a warm boot: on page 19. Setting the IP address, subnet mask or gateway: In the appropriate field, enter the IP address, subnet mask or gateway address and press Apply. Sentry Commander - PT40 Installation and Operations Manual Operations • 13... -
Page 18: Chapter 4: Advanced Operations
Optional –Both non-secure (HTTP) and SSL encrypted connections (HTTPS) are allowed access. • Required – ONLY SSL encrypted connections (HTTPS) are allowed access. Select Optional or Required from the Secure Access drop-down menu and press Apply. 14 • Operations Sentry Commander - PT40 Installation and Operations Manual... -
Page 19: Serial Ports
The modem should be configured directly from a PC using a terminal program and the command &W be used to save the new configuration to memory and set it to default. Sentry Commander - PT40 Installation and Operations Manual... -
Page 20: Outlets
On the subsequent User Edit page, enter a password and verify the new password for the new user in the Password and Verify Password fields. For security, password characters are not displayed. Press Apply. 16 • Operations Sentry Commander - PT40 Installation and Operations Manual... - Page 21 Click on the Ports link in the Access column for the associated user. On the subsequent User Ports page, select or deselect ports to be accessed by the user and press Apply. Sentry Commander - PT40 Installation and Operations Manual...
-
Page 22: Ftp
Enter an IP address in the appropriate Trap Destination field and press Apply. Enabling or disabling tower traps: Click on the Tower Traps link. On the subsequent Tower Traps page, select or deselect the desired traps and press Apply. 18 • Operations Sentry Commander - PT40 Installation and Operations Manual... -
Page 23: C L I
See Appendix A: for more information on resetting a Sentry to factory defaults from the HTML interface. Uploading new firmware: See Appendix B: for more information on uploading new firmware from the HTML interface. Sentry Commander - PT40 Installation and Operations Manual Operations • 19... -
Page 24: Command Line Interface
Grants a user access to one or all outlets Add Porttouser Grants a user access to one or all serial/Pass-Thru ports Create Group Adds a group name Create User Adds a user account 20 • Operations Sentry Commander - PT40 Installation and Operations Manual... - Page 25 Displays the Sentry firmware version To display the names of commands that you may execute: At the command prompt, press Enter. A list of valid commands for the current user appears. Sentry Commander - PT40 Installation and Operations Manual Operations • 21...
-
Page 26: Operations Commands
Type reboot, followed by a group name, and press Enter, or Type reboot all and press Enter. Example The following command reboots all the outlets in the group named ServerGroup_1: Sentry: reboot ServerGroup_1<Enter> 22 • Operations environment and Sentry Sentry Commander - PT40 Installation and Operations Manual... - Page 27 At the Sentry: prompt, type list outlets and press Enter. Example The follow command displays all accessible outlets for the current user: Sentry: list outlets<Enter> Outlet Outlet Name DataServer_1 WebServer_1 Sentry Commander - PT40 Installation and Operations Manual Outlet Control State State Outlet Control State...
- Page 28 Type istat and press Enter, or Type iload and press Enter. Examples The following command displays the infeed status: Sentry: istat Input Input Feed ID Feed Name HQ_1_Infeed_A 24 • Operations Input Input Status Load 10.5 Amps Sentry Commander - PT40 Installation and Operations Manual...
-
Page 29: Starting A New Session
The Quit or Logout commands ends a session. A session ends automatically when no activity is detected for five minutes, or upon loss of connection. To end a session: At the Sentry: prompt, type quit and press Enter, or Type logout and press Enter. Sentry Commander - PT40 Installation and Operations Manual Operations • 25... -
Page 30: Administration Commands
Sentry: set user password johndoe<Enter> Password: <Enter> Verify Password: <Enter> The following command blanks the password for the user JaneDoe: Sentry: set user password<Enter> Username: janedoe<Enter> Password: <Enter> Verify Password: <Enter> 26 • Operations Sentry Commander - PT40 Installation and Operations Manual... - Page 31 At the Sentry: prompt, type list users and press Enter. Example The following command displays all users with their access privilege level: Sentry: list users<Enter> User Name JOHNDOE JANEDOE JOSEYDOE JOEDOE Sentry Commander - PT40 Installation and Operations Manual Privilege Environmental Level Monitoring Admin Allowed User Allowed...
- Page 32 At the Sentry: prompt, type add porttouser, optionally followed by a Port name and a username. Press Enter. Examples The following commands grants to user JaneDoe access to the Pass-Thru port Router1: Sentry:add PortToUser Router1 janedoe<Enter> 28 • Operations Sentry Commander - PT40 Installation and Operations Manual...
-
Page 33: Group Administration
To remove a group name: At the Sentry: prompt, type remove group, optionally followed by a username. Press Enter. Example The following command removes group name ServerGroup_1: Sentry: remove group ServerGroup_1<Enter> Sentry Commander - PT40 Installation and Operations Manual Operations • 29... -
Page 34: Outlet Administration
At the Sentry: prompt, type set outlet wakeup, followed by on or off and the outlet name. Press Enter. Example The following command sets the wakeup state for outlet .a1 to off: Sentry: set outlet wakeup off .a1<Enter> 30 • Operations Sentry Commander - PT40 Installation and Operations Manual... -
Page 35: Serial/Pass-Thru Port Administration
At the Sentry: prompt, type set port speed, follow by the data-rate and press Enter. Example The following command sets the serial/Pass-Thru ports data-rate to 38400 BPS: Sentry: set port speed 38400<Enter> Sentry Commander - PT40 Installation and Operations Manual Wakeup State... - Page 36 The following command set the Init 2 string to ‘AT E0 Q1 S0=3 S2=64 S12=50 &C1 &D2’: Sentry: set modem init2 AT E0 Q1 S0=3 S2=64 S12=50 &C1 &D2<Enter> 32 • Operations Sentry Commander - PT40 Installation and Operations Manual...
-
Page 37: System Administration
Sentry: set location<Enter> In this case, the control screen’s Location field will be blank, and no welcome banner will be displayed after a successful login. Sentry Commander - PT40 Installation and Operations Manual AT E0 Q1 S0=1 S2=64 S12=50 &C1 &D2 Check Operations •... - Page 38 24 alphanumeric and other typeable characters (ASCII 33 to 126 decimal - spaces are not allowed). Press Enter. Example The following command adds the descriptive name HQ_1_Infeed_A to the infeed on the Sentry: Sentry: set infeed name .aa HQ_1_Infeed_A<Enter> 34 • Operations Sentry Commander - PT40 Installation and Operations Manual...
-
Page 39: Tcp/Ip Administration
Sentry: set ipaddress 12.34.56.78<Enter> Setting the subnet mask The Set Subnet command sets the subnet mask for the network the PT40 will be attached to. To set the subnet mask: At the Sentry: prompt, type set subnet, followed by the subnet mask and press Enter. - Page 40 12.34.56.1 Telnet: Enabled SSH: Enabled HTTP: Enabled SSL: Enabled SNMP: Enabled Network Status Link: Speed: 100 Mbps Duplex: Full Negotiation: Auto 36 • Operations Port: Port: 65535 Port: Security: BASIC Access: Required Sentry Commander - PT40 Installation and Operations Manual...
-
Page 41: Http Administration
At the Sentry: prompt, type set telnet port, followed by the port number and press Enter. Example The following changes the Telnet port number to 7001: Sentry: set telnet port 7001<Enter> Sentry Commander - PT40 Installation and Operations Manual Operations • 37... -
Page 42: Ftp Administration
At the Sentry: prompt, type set ftp filepath, followed by the filepath and press Enter. Example The following command sets the FTP filepath to ftp://sentry: Sentry: set ftp filepath ftp://sentry<Enter> 38 • Operations Sentry Commander - PT40 Installation and Operations Manual... -
Page 43: Sntp Administration
At the Sentry: prompt, type show sntp and press Enter. Example The following command displays the SNTP configuration information: Sentry: show sntp <Enter> SNTP Date/Time (GMT): 2003-02-21 SNTP Primary IP Address: SNTP Secondary IP Address: Sentry Commander - PT40 Installation and Operations Manual guest OpenSesame ftp://sentry snb_s50a.bin 21:32:48 204.152.184.72... -
Page 45: Chapter 4: Advanced Operations
Chapter 4: Advanced Operations Enabling and Setting up SSL Support SSL Technical Specifications Enabling and Setting up SSH Support SSH Technical Specifications SNMP MIB, OID and Support Enabling and Setting up SNMP Support SNMP Traps Configuring Traps... -
Page 46: Enabling And Setting Up Ssl Support
Transport Layer Security (TLS) version 1 (RFC 2246) SSL/TLS-enabled HTTPS server (RFC 2818) Self-Signed X.509 Certificate version 3 (RFC 2459) Asymmetric Cryptography: 1024-bit RSA Key Exchange Symmetric Cryptography Ciphers: TLS_RSA_WITH_AES_256_CBC_SHA TLS_RSA_WITH_AES_128_CBC_SHA 42 • Advanced Operations TLS_RSA_WITH_3DES_EDE_CBC_SHA TLS_RSA_WITH_DES_CBC_SHA Sentry Commander - PT40 Installation and Operations Manual... -
Page 47: Enabling And Setting Up Ssh Support
Diffie-Hellman DSA/DSS 512-1024 (random) bits per NIST specification Symmetric Cryptography: AES256-CBC RIJNDAEL256-CBC AES192-CBC RIJNDAEL192-CBC AES128-CBC RIJNDAEL128-CBC Message Integrity: HMAC-SHA1-160 HMAC-SHA1-96 HMAC-MD5-128 HMAC-MD5-96 Authentication: Username/Password Session Channel Break Extension (for RS232 Break) Sentry Commander - PT40 Installation and Operations Manual 3DES-192-CBC BLOWFISH-128-CBC ARCFOUR-128 Advanced Operations • 43... -
Page 48: Enabling And Setting Up Snmp Support
The following sets the trap destination 1 to 64.42.31.208: Sentry: set snmp trapdest1 64.42.31.208<Enter> To reset the trap destination: At the Sentry: prompt, type set snmp, trapdest1 or trapdest2, 0.0.0.0 and press Enter. 44 • Advanced Operations Sentry Commander - PT40 Installation and Operations Manual... - Page 49 SNMP Configuration SNMP: SET Community String: GET Community String: TRAP Community String: Error Trap Repeat Time (seconds): Trap Destination 1: Trap Destination 2: Sentry Commander - PT40 Installation and Operations Manual Enabled private public trap 64.42.31.208 (undefined) Advanced Operations • 45...
-
Page 50: Snmp Traps
Location of the Sentry, and identifier and name of the affected outlet. For descriptions of the outlet status types, please refer to the prior table. 46 • Advanced Operations Sentry Commander - PT40 Installation and Operations Manual... -
Page 51: Configuring Traps
Status trap automatically enables the Infeed and Tower Status traps for that outlet. Conversely, if a Tower Status trap is disabled, all associated Infeed Status & Load and Outlet Status traps will be disabled. Sentry Commander - PT40 Installation and Operations Manual... - Page 52 The following command enables the Change trap for the third outlet on the first infeed of the second tower, using the outlet’s absolute name: Sentry: set trap outlet change .ba3 on<Enter> 48 • Advanced Operations Sentry Commander - PT40 Installation and Operations Manual...
- Page 53 Feed ID Feed Name HQ_1_Infeed_A Outlet trap configuration: Outlet Outlet Name .AA1 DataServer_1 .AA2 WebServer_1 .AA3 FileServer_1 .AA4 Sentry Commander - PT40 Installation and Operations Manual Status Trap Status Load High Trap Trap Thresh 255 A Change Status Trap Trap...
-
Page 55: Chapter 5: Appendices
Chapter 5: Appendices A: R PPENDIX ESETTING TO To reset to factory defaults from the HTML interface ...52 To reset to factory defaults from the command line...52 To reset to factory defaults using the reset button...52 B: U PPENDIX PLOADING IRMWARE To initiate an FTP upload session from the HTML interface...52 To initiate an FTP upload session from the command line ...52... -
Page 56: To Reset To Factory Defaults From The Html Interface
FTP Host. See FTP Administration in Chapter 3: for more information. To initiate an FTP firmware upload session: At the Sentry: prompt, type restart ftpload and press Enter. 52 • Appendices Resetting to Factory Defaults Sentry Commander - PT40 Installation and Operations Manual... -
Page 57: Appendix C: Technical Specifications
R e la t iv e H u m id it y O p e ra t in g S t o ra g e A p p ro v a ls Sentry Commander - PT40 Installation and Operations Manual Inlet* Outlets O u t p u t C u rre n t R a t in g s L’... -
Page 58: Data Connections
54 • Appendices Technical Specifications Input/Output Output Output Output 7 54321 Input Input Input Input/Output Output Input Input Output Input Output Output Input/Output Input Input Output Output Input Output Input Installation and Operations Manual Sentry Commander - PT40... -
Page 59: Led Indicators
Sentry is equipped with a status LED for each power receptacle. A lit/on LED indicates that power is being supplied at the port and a darkened/off LED indicates that there is no power at the port. Sentry Commander - PT40 Installation and Operations Manual on the Server Technology website - Tech Library, Technical Notes. -
Page 60: Warranty And Limitation Of Liability
Excellent Technical Support Services • Special Update and Upgrade Programs • Warranty Protection • Extended Warranty Service • New Product Information Register your products online today! www.servertech.com 56 • Appendices Warranty, Product Registration and Support Sentry Commander - PT40 Installation and Operations Manual... -
Page 61: Technical Support
For non-warranty repairs, return of the equipment will be expedited with the inclusion of a Purchase Order or credit card number for incurred charges Sentry Commander - PT40 Installation and Operations Manual Tel: 775.284.2000 Web: www.servertech.com... - Page 64 Server Technology, Inc. Server Technology, Inc. toll free +1.800.835.1515 1040 Sandhill Drive tel +1.775.284.2000 Reno, NV 89521 fax +1.775.284.2065 www.servertech.com sales@servertech.com Sentry, Commander, Environmental Monitoring Control Unit, Pass-Thru and Sentry Secure Agent are trademarks of Server Technology, Inc. 301-0402-1 Rev. C (042304) © 2004 Server Technology, Inc. All rights reserved.
