  • Page 1 EK 300 IEM Instruction manual Instruction manual Notice d’emploi Istruzioni per l’uso Instrucciones de uso Gebruiksaanwijzing Manual de instruções...

  • Page 2: Table Of Contents

    The frequency bank system ... 3 Delivery includes ... 4 Product overview ... 5 Overview of the EK 300 IEM G3 diversity receiver ... 5 Overview of the displays ... 6 Putting the diversity receiver into operation ... 7 Inserting the batteries/accupack ... 7 Charging the accupack ...

  • Page 3: Important Safety Instructions

    Unauthorized substitutions may result in fire, electric shock, or other hazards. Intended use Intended use of the EK 300 IEM G3 diversity receiver includes: • having read these instructions especially the chapter “Important safety instructions”, •...

  • Page 4: The Ek 300 Iem G3 Diversity Receiver

    The EK 300 IEM G3 diversity receiver This diversity receiver is part of the evolution wireless series generation 3 (ew G3). With this series, Sennheiser offers high-quality state-of-the-art RF transmission systems with a high level of operational reliability and ease of use. Transmitters and receivers are designed for monitoring appli- cations and permit wireless transmission with studio-quality sound.

  • Page 5: Delivery Includes

    For an overview of the frequency presets, please refer to the supplied frequency information sheet. Updated versions of the frequency informa- tion sheet can be downloaded from the EK 300 IEM G3 product page on our website at www.sennheiser.com. The frequency banks “U1” to “U6” allow you to freely select and store receiving frequencies.

  • Page 6: Product Overview

    Product overview Overview of the EK 300 IEM G3 diversity receiver On/off/volume control 3.5 mm stereo jack socket (PHONES), lockable (the ground contact is used by antenna II) Antenna I Operation and battery status indicator, red LED lit = flashing =...

  • Page 7: Overview Of The Displays

    Product overview Overview of the displays After switch-on, the diversity receiver displays the “Frequency/Name” standard display. For further illustrations and examples of the different standard displays, refer to page 10. The display backlighting is automatically reduced after approx. 20 seconds. Display RF level “RF”...

  • Page 8: Putting The Diversity Receiver Into Operation

    Inserting the batteries/accupack For powering the diversity receiver, you can either use two 1.5 V AA size batteries or the rechargeable Sennheiser BA 2015 accupack (see “Accesso- ries” on page 24). Open the battery compartment by pushing the two catches direction of the arrows and open the cover Insert the two batteries or the accupack as shown above.

  • Page 9: Attaching The Diversity Receiver To Clothing

    Putting the diversity receiver into operation Attaching the diversity receiver to clothing You can use the belt clip (e.g. belt, waistband). The belt clip is detachable so that you can also attach the diversity receiver with the antenna pointing downwards. To do so, withdraw the belt clip from its fixing points and attach it the other way round.

  • Page 10: Using The Diversity Receiver

    Using the diversity receiver To establish a transmission link, proceed as follows: 1. Switch the diversity receiver on (see next section) 2. Switch a transmitter on (see the instruction manual of the trans- mitter). The transmission link is established and the receiver’s RF level display “RF”...

  • Page 11: Deactivating The Lock Mode Temporarily

    Using the diversity receiver Deactivating the lock mode temporarily You can activate or deactivate the automatic lock mode via the Lock” menu item (see page 16). If the lock mode is activated, you have to temporarily deactivate it in order to be able to operate the receiver: Press the “Locked”...

  • Page 12: Using The Operating Menu

    Using the operating menu A special feature of the Sennheiser ew G3 series is the consistent, intuitive menu structure of transmitters and receivers. As a result, adjustments to the settings can be made quickly – even in stressful situations, for example on stage or during a live show or presentation.

  • Page 13: Working With The Operating Menu

    Using the operating menu Display Function of the menu item “Easy Setup“ Reset List Releases all locked frequency presets Current List Selects an unused frequency preset Scan New List Scans for unused receiving frequencies (frequency preset scan) Exit Exits menu Extended menu “Advanced Menu”...
  • Page 14 Press the Press the rocker button to set the channel. Press the Canceling an entry Press the The current standard display appears on the display panel. To subsequently return to the last edited menu item: Press the item appears. Exiting a menu item To return to the next higher menu level: Change to the “Exit”...

  • Page 15: Adjusting Settings Via The Operating Menu

    Adjusting settings via the operating menu Adjusting settings via the operating menu The main menu “Menu” Adjusting the squelch threshold – “Squelch” Menu Squelch Call up “Squelch” Adjustment range: 5 to 25 dBμV, adjustable in 2-dB steps, can be switched The squelch eliminates annoying noise when the transmitter is switched off or when there is no longer sufficient transmitter power received by the receiver.
  • Page 16 Scanning for, releasing and selecting frequency presets – “Easy Setup” Menu item Function of the menu item Reset List Releases all locked frequency presets Current List Selects an unused frequency preset Scan New List Automatically scans for unused receiving frequencies (frequency preset scan) If receiving frequencies are used, they will be locked;...
  • Page 17 Adjusting settings via the operating menu Adjusting the balance – “Balance” Menu Balance Call up “Balance” You can adjust the balance in 31 steps. In Focus mode (see next section) and when one of the standard displays is shown, you can also use the rocker button to adjust the balance.

  • Page 18: The Extended Menu "Advanced Menu

    The extended menu To get into the extended menu From the main menu, select “Advanced”. Setting the receiving frequencies and the frequency banks “U1” to “U6 – “Tune” When you have selected one of the system banks and then select the “Tune”...
  • Page 19 Adjusting settings via the operating menu Press the rocker button to set the frequency bank. Press the The channel is highlighted. Press the rocker button to set the channel. Press the The frequency (MHz section) is highlighted. Set the desired frequency (MHz and kHz section) as described in the previous chapter.
  • Page 20 Adjusting the contrast of the display panel – “LCD Contrast” Advanced Menu Name LCD Contrast Call up “LCD Contrast” You can adjust the contrast of the display panel in 16 steps. Resetting the settings made in the operating menu – “Reset” Advanced Menu Reset Call up “Reset”...

  • Page 21: Synchronizing An Sr 300 Iem G3 Transmitter With The Diversity Receiver

    Make sure that the desired frequencies are listed in the enclosed frequency information sheet. You can also contact your Sennheiser partner who will be pleased to calculate intermodulation-free frequencies for you. Make sure that the desired frequencies are approved and legal in your country and, if necessary, apply for an operating license.

  • Page 22: Synchronizing Transmitters With Diversity Receivers (Sync)

    If you are using frequencies from the frequency banks “U1” to “U6”, it might be that the receiving frequencies are not intermod- ulation-free. Contact your Sennheiser partner who will be pleased to calculate intermodulation-free frequencies for you (see www.sennheiser.com). Set each diversity receiver to the same frequency bank (“U1” to “U6”).

  • Page 23: Cleaning The Diversity Receiver

    Cleaning the diversity receiver On one of the receivers, select a channel within this frequency bank and assign this channel a receiving frequency (see page 17). Synchronize a transmitter with this receiver (see the instruction manual of the transmitter). Manually set the transmitter to the same frequency bank and channel that you set on the receiver.

  • Page 24: If A Problem Occurs

    If a problem occurs that is not listed in the above table or if the problem cannot be solved with the proposed solutions, please contact your local Sennheiser partner for assistance. To find a Sennheiser partner in your country, search at www.sennheiser.com under “Service & Support”. Possible solution Deactivate the lock mode (see page 10).

  • Page 25: Accessories

    Accessories Accessories The following EK 300 IEM G3 accessories are available from your specialist dealer: Cat. No. Accessory 009950 BA 2015 accupack 009828 L 2015 charger 500432 IE 4 earphones Specifications RF characteristics Modulation Frequency ranges Receiving frequencies Switching bandwidth...

  • Page 26: Manufacturer Declarations

    Connector assignment 3.5 mm jack plug Manufacturer Declarations Warranty Sennheiser electronic GmbH & Co. KG gives a warranty of 24 months on this product. For the current warranty conditions, please visit our web site at www.sennheiser.com or contact your Sennheiser partner.
  • Page 27 This class B digital device complies with the Canadian ICES-003. Changes or modifications made to this equipment not expressly approved by Sennheiser electronic Corp. may void the FCC authorization to operate this equipment. Before putting the device into operation, please observe the respective...

  • Page 28: Index

    Index Accessories Accupack charging inserting Advanced Menu (extended menu) overview settings Auto Lock (activating/deactivating the lock mode) Balance (adjusting the balance) Batteries battery status inserting Buttons ESC button function of the ~ SET button UP/DOWN button Channel assigning a frequency selecting setting a frequency Displays...
  • Page 29 Sennheiser electronic GmbH & Co. KG Printed in Germany Am Labor 1, 30900 Wedemark, Germany Publ. 01/09 www.sennheiser.com 529681/A01...
