- Page 1 ® CDRPan FOR PANORAMIC SYSTEMS Installation Instructions for Villa Rotograph Schick Technologies, Inc. 31-00 47 Avenue Long Island City, New York 11101 (718) 937-5765 (718) 937-5962 (FAX) Part Number B1051105 Rev. – F:\GENERAL\DEPTS\QA\DOCUMENT\B1051105Rev-.doc...
- Page 2 Many of the designations used by manufacturers and sellers to distinguish their products are claimed as trademarks. Where those designations appear in this document, and Schick Technologies, Inc. was aware of a trademark claim, the designations have been printed in caps or initial caps.
-
Page 3: Table Of Contents
Contents 1. Introduction....................1 1.1. Welcome...........................1 1.2. CDRPan System .......................1 1.3. Overview for Installing CDRPan ..................1 1.4. Before You Start Installing CDRPan................2 2. What You Will Need For Installation............3 2.1. CDRPan System .......................3 2.2. Tools..........................6 3. Sensor and Codestrip.................7 3.1. Remove Rotation Arm Cover Plate ..................7 3.2. - Page 4 A complete list of specifications can be found in the CDRPan User’s Guide. Mechanical Considerations The sensor package, the remote module, and the cables of the CDRPan system are mounted outside of the patient area to ensure patient safety and reliable equipment operation.
-
Page 5: Introduction
1.3. Overview for Installing CDRPan This Installation Manual is one of two documents you will need to install the CDRPan system completely. After performing the installation procedures in this document, you should refer to the CDRPan User’s Guide (P/N B1051008) to install the software for the CDRPan system. -
Page 6: Before You Start Installing Cdrpan
1.4. Before You Start Installing CDRPan Prior to installing CDRPan on your panoramic system, please perform the following checks. A. Make sure your panoramic system is operating properly. B. Familiarize yourself with the installation steps before performing them. C. Determine the location of your computer. This will be useful when you install the Remote Module and need to run cables between it and your computer. -
Page 7: What You Will Need For Installation
2. What You Will Need For Installation 2.1. CDRPan System To perform the installation procedures in this manual, you will need the following CDRPan parts and assemblies. A. Sensor Assembly B. Curved Cassette Codestrip Assembly (A), Mounting Clip (B), and Interlock... - Page 8 C. Remote Module D. Cable Holders and Clamps E. Power Supply B1051105 Rev. – Rotograph Installation...
- Page 9 F. PCI Board G. Data Cable for PCI Board H. X-ray Filter and Allen Keys Rotograph Installation B1051105 Rev. –...
-
Page 10: Tools
2.2. Tools To install the sensor and codestrip, you will need the following tools. A. Phillips screwdriver to remove and replace rotation arm cover plate, and to install sensor clip, codestrip assembly, and interlock defeater. B. Allen wrench (hex key, 3/32 in.) to adjust clearance between encoder and codestrip. C. -
Page 11: Sensor And Codestrip
3. Sensor and Codestrip 3.1. Remove Rotation Arm Cover Plate Using a Phillips screwdriver, remove screw from bottom of plate and remove plate from rotation arm. Rotograph Installation B1051105 Rev. –... -
Page 12: Install Sensor Assembly
3.2. Install Sensor Assembly Carefully slide sensor assembly into faceplate until upper guide is seated firmly at top of aperture slit and lower guide fits in bottom of aperture. UPPER GUIDE LOWER GUIDE B1051105 Rev. – Rotograph Installation... -
Page 13: Install Sensor Clip
3.3. Install Sensor Clip Install the sensor clip at the bottom of the aperture and secure it in place using the Allen key (.050 in) to tighten 2 screws. CAUTION: Light tension on the set screws is all that is needed to secure the sensor clip. Do not apply excessive torque. -
Page 14: Route Sensor Cable
3.4. Route Sensor Cable Use cable clamps and holders to route sensor cable to the top of the panoramic machine. Allow enough slack in the cable for the rotation arm of the panoramic machine to move freely. Sensor cable secured along faceplate Sensor cable secured across faceplate B1051105 Rev. -
Page 15: Check Sensor Cable Run
3.5. Check Sensor Cable Run Swivel the arm of the panoramic machine to ensure there is enough slack in the cable for the rotation arm to move freely. Adjust cable if necessary. Sensor cable secured along rotation arm Rotograph Installation B1051105 Rev. -
Page 16: Install Codestrip Assembly
3.6. Install Codestrip Assembly A. Install the codestrip assembly on the drum cassette holder by tightening screws with a Phillips screwdriver. B. Align the codestrip assembly with the encoder window. CODESTRIP CASSETTE HOLDER CODESTRIP ENCODER WINDOW B1051105 Rev. – Rotograph Installation... -
Page 17: Install Interlock Defeater
3.7. Install Interlock Defeater A. Slide the interlock defeater onto the drum cassette holder. Make sure that it fits over and depresses the interlock limit switch on the panoramic machine. Rotograph Installation B1051105 Rev. –... - Page 18 B. When the interlock defeater is firmly in place, secure it to the cassette holder using a Phillips screwdriver to tighten 4 screws. B1051105 Rev. – Rotograph Installation...
-
Page 19: Secure Sensor Assembly
3.8. Secure Sensor Assembly Adjust the encoder section of the sensor assembly to approximately 1 mm from the codestrip on the drum cassette. Use the Allen key (3/32 in.) to tighten the hinge links on the encoder. Rotograph Installation B1051105 Rev. –... -
Page 20: Check Codestrip Alignment
3.9. Check Codestrip Alignment A. Check the encoder-to-codestrip alignment. The proper distance between these two parts should be approximately 1 mm when the arm of the panoramic machine is rotated. Verify this distance at the start and at the end of motion. Start of Panoramic Motion End of Panoramic Motion B1051105 Rev. - Page 21 B. If necessary, shim the codestrip assembly for proper alignment. As in the previous step, recheck the distance between the encoder and the codestrip. At the start and end of motion, the distance should be approximately 1 mm. SHIM Rotograph Installation B1051105 Rev.
-
Page 22: Reinstall Rotation Arm Cover Plate
3.10. Reinstall Rotation Arm Cover Plate A. Reinstall cover plate. B. Proceed to Chapter 4 to continue with CDRPan system installation. B1051105 Rev. – Rotograph Installation... -
Page 23: Remote Module, Power Supply, And Pci Board
4. Remote Module, Power Supply, and PCI Board 4.1. Install Remote Module 4.1.1. Tools and Materials To install the remote module, you will need velcro patches to secure the module to the top of the panoramic machine, and a screwdriver to secure the sensor cable connector to the remote module. -
Page 24: Install Power Supply
4.2. Install Power Supply 4.2.1. Tools and Materials To install the power supply, you will need cable holders and clamps (P/N B4700140) to secure the cable along the side of the panoramic machine and up to the remote module. 4.2.2. Step-by-Step Instructions NOTE: Verify that the power supply voltage selector is set correctly for the power requirements in your area. - Page 25 E. Connect the other end of the data cable to the remote module. Then, use a small secrewdriver to tighten the screws on the connector. F. Refer to the CDRPan User’s Guide (P/N B1051008) to continue with CDRPan system installation.
- Page 26 Also Supplied CDRPan Board Cable holders and clamps (Installed in computer PCI slot) X-ray filter Allen key(s) Connects to Remote Module Other items as needed Figure 2. Installing CDRPan on Curved Cassette-Type Machine B1051105 Rev. – Rotograph Installation...
