Sennheiser Evolution 500206 Specification Sheet
Sennheiser Evolution 500206 Specification Sheet

Sennheiser Evolution 500206 Specification Sheet

Sennheiser condenser microphone specification sheet

Advertisement

Quick Links

Microphones |
General Description
The e 914 is a high grade condenser microphone for very demanding
applications. Its outstanding sound properties qualify the e 914 for highly
sophisticated tasks. The e 914 is a perfect microphone for ambitious re-
cordings and live performances. Its main areas of application are acoustic
guitars, cymbals, percussion, overhead, orchestras, grand pianos etc .
Features
Exceptionally lively, clear sound
Three-position sensitivity switch
Three-position bass roll-off/cut-off switch
Very high sound pressure handling capability
Exchangeable microphone capsule
Delivery includes: e 914 microphone
Microphone clamp
Windscreen
Pouch
Instructions for use
evolution
Technical Data
Transducer principle .......... pre-polarised condenser microphone
Pick-up pattern .......................................................................cardioid
Frequency response ..................................................20 - 20,000 Hz
Sensitivity (free field, no load, 1 kHz) ............................. 7 mV/Pa;
Equivalent noise level
A-weighted (DIN IEC 651) ........................................................ 19 dB
CCIR-weighted (CCIR 468-3) .................................................... 30 dB
Pre-attenuation ........................................................... 0, -10, -20 dB
Phantom powering ........................................................48 V/2.2 mA
Bass filter .....................................................................................linear
Max. Sound pressure level at 1 kHz ........... 137/147/157 dB SPL
Nominal impedance ................................................................. 100
Min. terminating impedance ..................................................... 1 k
Connector .................................................................................... XLR-3
Dimensions ................................ Ø 24 x 157 mm (Ø 0.94˝ x 6.18˝)
Weight ....................................................................... 198 g (6.98 oz)
0
30°
5
10
60°
15
20
25
90°
dB
120°
150°
180°
125 Hz
250 Hz
500 Hz
1000 Hz
Frequency response curves with different sensitivities
dBv
-35
-40
-45
-50
-55
-60
-65
-70
20
50
100
200
500
1000
0 dB
-10 db
Frequency response curves with different filters
dBv
-35
-40
-45
-50
-55
-60
-65
-70
1000
20
50
100
200
500
bass
roll off
Cat. No. 500206
2.3 mV/Pa / 0.7 mV/Pa
(with pre-attenuation)
roll-off 130 Hz, 6 dB/oct.
cut-off 85 Hz, 18 dB/oct.
(depending on
pre-attenuation)
30°
60°
90°
120°
150°
2000 Hz
4000 Hz
8000 Hz
16000 Hz
2000
5000 10000 20000 Hz
-20 db
2000
5000 10000 20000 Hz
cut off
e 914
