Sennheiser Evolution 500203 Specification Sheet

Microphones |
General Description
The condenser e 908 is available for two different applications:
e 908 B especially designed for brass instruments.
e 908 D perfect for drums and percussion.
Features
Exceptionally lively, clear sound
Quick and flexible set-up; comes with suitable mounting clamp
Optimal positioning with long-necked, flexible boom
Integrated shock absorber eliminates handling noise
Intelligent MZA 900 P in-line-preamp
(cable, phantom power & level check)
Each e 908 variant can optionally be used with any
Evolution Wireless bodypack transmitter
Delivery includes: e 908 microphone, microphone clamp, MZA 900 P
in-line-pramp, Pouch, Instructions for use
Product Variants
e 908 B
The e 908 B condenser instrument microphone was specially designed
for brass instruments. Comes with multifunctional MZH 908 B horn
clamp.
e 908 B ew
Wireless version. No in-line-preamp included. Can be used with any Evo-
lution Wireless bodypack transmitter.
e 908 D
The e 908 D condenser instrument microphone was specially designed
for drums and percussion. Comes with multifunctional MZH 908 D drum
clamp.
e 908 T ew
Wireless version of the e 908, developed for trumpets, trombones and
flugelhorns. The e 908 T ew can be used with any evolution wireless
bodypack/instrument transmitter. For turning the e 908 T ew into a
wired mic, please use the MZA 900 P phantom power adaptor (needs
to be ordered separately).
evolution
Cat. No. 500203
Cat. No. 500204
Cat. No. 500205
Cat. No. 500632
Technical Data
Transducer principle .....................................................pre-polarised
Frequency response ................................................. 40 – 20,000 Hz
Sensitivity (free field, no load, 1 kHz) .............................. 4 mV/Pa
Nominal impedance .......................................... 100
Min. terminating impedance ................................................... 2 k *
Max. Sound pressure level (at 1 kHz)..........................147 dB/SPL
Equivalent noise level
A-weighted as per DIN IEC 651
e 908 B, e 908 D ................................................................... 35 dB(A)
e 908 B ew ............................................................................ 30 dB(A)
e 908 T ew ............................................................................. 39 dB(A)
Phantom powering ...............................................12 - 48 V / 3 mA*
Connector
e 908 B, e 908 D ....................................................................... XLR-3*
e 908 B ew, e 908 T ew ..................................................3.5 mm jack
Weight .....................................................................311 g (10.97 oz)
Dimensions ................................ Ø 47 x 193 mm (Ø 1.85˝ x 7.60˝)
* with MZA 900 P (e 980 B / e 908 D)
e 908 B ew / T ew for direct connection to ew transmitters
dBv
-30
-40
-50
-60
-70
-80
20 200 500
50 100 1000
0° 180°
condenser microphone
0.56 mV/Pa (e 908 T ew)
(balanced)*
20000 Hz
2000 5000 10000
e 908
