Sennheiser Evolution 009422 Specification Sheet

Microphones |
General Description
The e 945 is a fully professional super-cardioid vocal microphone which
cuts through the mix and offers a smooth, natural sound. Its warm tonal
response is matched with rugged construction and excellent feedback re-
jection.
Features
Rugged metal body
Advanced shock-mount design
Consistent on-/off-axis response
Hum compensating coil
Delivery includes a pouch and a microphone clamp
evolution
Technical Data
Transducer principle ............................................................dynamic
Pick-up pattern ...........................................................super-cardioid
Frequency response ................................................. 40 – 18,000 Hz
Sensitivity
(free field, no load, 1 kHz) ...........................2.0 mV/Pa at 1 kHz =
Nominal impedance ................................................................. 350
Min. terminating impedance ..................................................... 1 k
Dimensions ....................................... 47 x 186 mm (1.85˝ x 7.32˝)
Weight ....................................................................330 g (11.64 oz)
0°
0
30°
5
10
60°
15
20
25
90°
dB
120°
150°
125 Hz
180°
250 Hz
500 Hz
1000 Hz
dBv
-30
-40
-50
-60
-70
-80
20 50 100 200 1000
500
Profile
Super-cardioid professional vocal microphone, hum compen-
sating coil, frequency response 40 – 18,000 Hz, sensitivity
(free field, no load) 2.0 mV/Pa at 1 kHz = -54 dB (0 dB = 1V/Pa),
nominal impedance 350 , min. terminating impedance 1 k
dimensions 47 x 186 mm, weight 330 g (11.64 oz).
Cat. No. 009422
-54 dB (0 dB = 1V/Pa)
30°
60°
90°
120°
150°
2000 Hz
4000 Hz
8000 Hz
16000 Hz
2000 5000 10000 20000 Hz
e 945
