- Page 1 EK 100 Instruction manual Instruction manual Notice d’emploi Istruzioni per l’uso Instrucciones de uso Gebruiksaanwijzing Manual de instruções...
-
Page 2: Table Of Contents
Recommendations and tips ... 21 If a problem occurs ..22 Accessories ... 23 Specifications ... 23 Manufacturer Declarations ... 24 Index ... 26 For further information, visit the EK 100 G3 product page on our website at www.sennheiser.com. -
Page 3: Important Safety Instructions
Replacement parts When replacement parts are required, be sure the service technician uses replacement parts specified by Sennheiser or those having the same characteristics as the original part. Unauthorized substitutions may result in fire, electric shock, or other hazards. -
Page 4: The Ek 100 G3 Diversity Receiver
The EK 100 G3 diversity receiver This diversity receiver is part of the evolution wireless series generation 3 (ew G3). With this series, Sennheiser offers high-quality state-of-the-art RF transmission systems with a high level of operational reliability and ease of use. Transmitters and receivers permit wireless transmission with studio-quality sound. -
Page 5: Areas Of Application
Delivery includes Areas of application The receiver can be combined with the following transmitters: Bodypack transmitter Radio microphone SK 100 SKM 100 These transmitters are available in the same UHF frequency ranges and are equipped with the same frequency bank system with factory-preset frequencies. -
Page 6: Product Overview
Product overview Overview of the EK 100 G3 diversity receiver 3.5 mm jack socket (LINE), lockable (the ground contact is used by antenna II) Antenna I Operation and battery status indicator, red LED lit = flashing = LOW BATT RF signal indication, green LED lit = Charging contacts button... -
Page 7: Overview Of The Displays
Product overview Overview of the displays After switch-on, the diversity receiver displays the “Frequency/Name” standard display. For further illustrations and examples of the different standard displays, refer to page 10. The display backlighting is automatically reduced after approx. 20 seconds. Display RF level “RF”... -
Page 8: Putting The Diversity Receiver Into Operation
Inserting the batteries/accupack For powering the diversity receiver, you can either use two 1.5 V AA size batteries or the rechargeable Sennheiser BA 2015 accupack or the DC 2 power adapter (see “Accessories” on page 23). Open the battery compartment by pushing the two catches direction of the arrows and open the cover Insert the two batteries or the accupack as shown above. - Page 9 Putting the diversity receiver into operation Lift one side of the belt clip Press down the belt clip receiver housing. Repeat for the other side. Place the perforated plate Reinsert the belt clip Use one of the supplied line cables to connect the line input of the camera to the socket The ground connection of the line cable serves as the antenna for the second diversity section.
-
Page 10: Using The Diversity Receiver
Using the diversity receiver To establish a transmission link, proceed as follows: 1. Switch the diversity receiver on (see next section). 2. Switch a transmitter on (see the instruction manual of the transmitter). The transmission link is established and the receiver’s RF level display “RF”... -
Page 11: Deactivating The Lock Mode Temporarily
Using the diversity receiver Deactivating the lock mode temporarily You can activate or deactivate the automatic lock mode via the Lock” menu item (see page 16). If the lock mode is activated, you have to temporarily deactivate it in order to be able to operate the receiver: Press the “Locked”... -
Page 12: Using The Operating Menu
Using the operating menu A special feature of the Sennheiser ew G3 series is the consistent, intuitive menu structure of transmitters and receivers. As a result, adjustments to the settings can be made quickly – even in stressful situations, for example on stage or during a live show or presentation. -
Page 13: Working With The Operating Menu
Using the operating menu Display Function of the menu item Extended menu “Advanced Menu” Tune Sets the receiving frequencies for the frequency bank “U” Sets the channel and the receiving frequency for the frequency bank “U” Pilot Tone* Activates/deactivates the pilot tone evaluation LCD Contrast Adjusts the contrast of the display panel Reset... - Page 14 Canceling an entry Press the ON/OFF ON/OFF The current standard display appears on the display panel. To subsequently return to the last edited menu item: Press the item appears. Exiting a menu item To return to the next higher menu level: Change to the “Exit”...
-
Page 15: Adjusting Settings Via The Operating Menu
Adjusting settings via the operating menu Adjusting settings via the operating menu The main menu “Menu” Synchronizing a transmitter with the diversity receiver – “Sync” You can synchronize a suitable transmitter of the ew 100 G3 series with the diversity receiver. During synchronization, the following parameters are transferred to the transmitter: •... - Page 16 If the squelch threshold is set to “High”, the transmission range will be reduced under unfavourable reception conditions. The squelch should only be switched off for servicing purposes. With the squelch threshold set to “Low”, you switch the squelch off by keeping the DOWN rocker button pressed for 3 seconds.
-
Page 17: The Extended Menu "Advanced Menu
Adjusting settings via the operating menu Entering a name – “Name” Menu Name L i c h a e l Call up “Name” Via the “Name” menu, you can enter a freely selectable name (e.g. the name of the performer) for the receiver. The name is displayed on the standard display (see page 6). - Page 18 Via the “Tune” menu item, you can set a receiving frequency to be stored in the current channel frequency bank “U” and assign this channel a receiving frequency. Setting a receiving frequency for the current channel Press the rocker button until the “Tune” menu item appears. Press the The MHz section of the receiving frequency of the channel is highlighted.
- Page 19 Adjusting settings via the operating menu Activating/deactivating the pilot tone evaluation – “Pilot Tone” Advanced Menu Name Pilot Tone A c t i v e Call up “Pilot Tone” The transmitter adds an inaudible signal, known as the pilot tone, to the transmitted signal.
-
Page 20: Synchronizing A Transmitter With The Diversity Receiver
Make sure that the desired frequencies are listed in the enclosed frequency information sheet. You can also contact your Sennheiser partner who will be pleased to calculate intermodulation-free frequencies for you. Make sure that the desired frequencies are approved and legal in your country and, if necessary, apply for an operating license. - Page 21 Synchronizing a transmitter with the diversity receiver On one of the receivers, select a channel within this frequency bank and assign this channel one of the calculated receiving frequencies (see page 17). Synchronize a transmitter with this receiver (see page 14). Manually set the transmitter to the same frequency bank and channel that you set on the receiver.
-
Page 22: Cleaning The Diversity Receiver
Cleaning the diversity receiver CAUTION! Liquids can damage the electronics of the receiver! Liquids entering the housing of the device can cause a short-circuit and damage the electronics. Keep all liquids away from the receiver. Do not use any solvents or cleansing agents. Use a cloth to clean the diversity receiver from time to time. -
Page 23: If A Problem Occurs
If a problem occurs that is not listed in the above table or if the problem cannot be solved with the proposed solutions, please contact your local Sennheiser partner for assistance. To find a Sennheiser partner in your country, search at www.sennheiser.com under “Service & Support”. Possible solution (see page 10). -
Page 24: Accessories
≥ 65 dB ≥ 70 dB Off, Low: 5 dBμV, Middle: 15 dBμV, High: 25 dBμV can be switched off Sennheiser ≥ 60 dBA ≤ 0.9% 3.5 mm jack socket: +11 dBu (mono, unbalanced) 42 dB, adjustable in steps of 6 dB –10°C to +55°C... -
Page 25: Manufacturer Declarations
+ NC Manufacturer Declarations Warranty Sennheiser electronic GmbH & Co. KG gives a warranty of 24 months on this product. For the current warranty conditions, please visit our website at www.sennheiser.com or contact your Sennheiser partner. In compliance with the following requirements •... - Page 26 This class B digital device complies with the Canadian ICES-003. Changes or modifications made to this equipment not expressly approved by Sennheiser electronic Corp. may void the FCC authorization to operate this equipment. Before putting the device into operation, please observe the respective...
-
Page 27: Index
Index Index Accessories Accupack charging inserting Advanced Menu (extended menu) overview settings AF Out (adjusting the audio output level) Auto Lock (activating/deactivating the lock mode) Batteries battery status inserting Buttons function of the ~ ON/OFF button SET button UP/DOWN button Channel assigning a frequency selecting... - Page 28 Sennheiser electronic GmbH & Co. KG Printed in Germany Am Labor 1, 30900 Wedemark, Germany Publ. 01/09 www.sennheiser.com 529667/A01...
