HME 100 SE
Headsets |
Pilot´s Headset
General Description
Featuring an elegant high-tech finish, closed ear protector headphones
and excellent passive noise attenuation, the HME 100 Special Edition
pilot's headset is ideal for use in propeller and turbo-prop aircraft.
Features
Special edition headset
Constant attenuation of up to 40 dB
Advanced transducer design ensures excellent speech intelligibility
Headphone volume control
Noise-compensated boom microphone for superior speech transmission
Delivery includes: 1 HME 100 Special Edition
1 carrying case for headset and accessories
1 MZQ 2002-1 cable clip
1 MZW 45 windshield
Recommended Accessories
Gel ear pads
Replacement parts
Ear pads (1 pair)
MZW 45 windshield
Technical Data
Headphones
Transducer principle ............................................................ dynamic
Ear coupling........................................................circumaural, closed
Frequency response ................................................ 45 – 15,000 Hz
Nominal impedance active/passive
HME 100/105/120........................................................150 Ω, mono
HME 100 ..................................................300 Ω per system, stereo
Attenuation (passive) .................................................> 10 – 40 dB
NRR (Noise Reduction Rating) ................................................24 dB
Contact pressure ...........................................................approx. 10 N
Weight without cable ...............................................................350 g
Microphone incl. Preamplifier
Type....................................................................................... MKE 45-1
Transducer principle ...............back-electret condenser capsule,
Frequency response ................................................ 300 – 5,000 Hz
Max. SPL ................................................................................... 120 dB
Output voltage ...............................400 mV ± 3 dB at 114 dB/SPL
Terminating impedance...........................................................150 Ω
Operating voltage....................... 8 – 16 V DC, approx. 8 – 25 mA
General Data
Connection cable...........single-sided round cable, length 1.5 m
Connectors
HME 100
– Headphones......................................................... 1/4" stereo jack
– Microphone ................................................... PJ-068 (5.25 mm Ø)
Specials................................................ headphone volume control,
Operating temperature ...................................... – 15 °C ... + 55 °C
Storage temperature ...........................................– 55 °C ... + 55 °C
Cat. No. 083140
Cat. No. 077960
Cat. No. 075823
Cat. No. 500076
Special Edition
noise-compensated
(as per RTCA/DO 214)
(as per RTCA/DO 214)
mono/stereo switch
