CHAPTER 5 SERVICE MODE
[Bit 4]
Use it to select the time length during which low-speed signals are ignored after transmis-
sion of the CFR signal.
If the condition of the line is not good and, therefore, the reception of image signals is
difficult, select '1500 ms'.
[Bit 6]
Use it to enable/disable transmission of the CNG signal in manual mode.
Select [TRANSMIT] if errors in which a switch-over to fax mode fails when a fax com-
munication is transmitted manually (FAX/TEL switch-over mode).
[Bit 7]
Use it to enable/disable transmission of the CED signal in manual reception mode.
Select 'transmit' if the other party doe not start transmission when manual reception is
started.
