Canon Super G3 Fax Board-J1 Service Manual page 24

Off-hook detection PCB (J712)¬
J712 J1059 signal
1 1 OVA
2 2 5VB
3 3 OVD
4 4 CICNT
Off-hook detection PCB (J713)¬ ®Main power supply PCB (J204)
J713 J204 signal
1 9 24VU3
2 10 OVU3
Off-hook detection PCB (J715)¬ ®G3 fax control PCB (J104)
J715 J104 signal
1 13 5VB
2 14 OVA
Off-hook detection PCB (J718)
not used
Modular PCB (J912)¬
J912 Cable signal
1 - L22
2 - L21
3 - L12
4 - L11
5 - T2
6 - T1
