Page 2: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT EMOVE COVER (OR BACK). NO USER-SERVICEABLE ART NSIDE EFER SERVICING T UALIFIED ERVICE PERSONNEL. The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of uninsulated dangerous voltage within the product`s enclosure that may be of sufficient magnitude to... - Page 3 IMPORTANT SAFETY INSTRUCTIONS Before using the unit, be sure to read all operating instructions carefully. Please note that these are general precautions and may not pertain to your unit. For example, this unit may not have the capability to be connected to an outdoor antenna. 1) Read these instructions.
- Page 4 IMPORTANT SAFETY INSTRUCTIONS 17) Overloading Do not overload wall outlets and extension cords as this can result in a risk of fire or electric shock. 18) Object and liquid entry Never push objects of any kind into the product through openings as they may touch dangerous voltage points or short out parts that could result in fire or electric shock.
-
Page 5: Location Of Controls
Location of Controls Top View 1. Turntable platter 2. Turntable center spindle 3. 45 RPM adapter 4. Lever 5. Tone arm holder 6. LINE IN jack 7. Speed selector LINE IN 8. Function knob 9. Tone arm 10.Power ON-OFF/ Volume knob INDICATOR 11. - Page 6 Location of Controls Inner Side View 20. Remote Sensor 21. Decorative LED lights Remote Control: LED1 LED2 ON/OFF 1. LED ON/OFF button LED3 LED4 LED5 2. LED 1 button 3. LED 2 button GREEN BLUE 4. LED 3 button 5. LED 4 button 6.
-
Page 7: Remote Control
Remote Control FIRST TIME USE ● Remove and discard the insulation as figure on the right. film ● Replacing the button cell when it is drained: 1. Push and slide out the battery holder as figure 1 below. 2. Replace the button cell with a new CR2025 button cell as the polarity markings on the rear of the Remote Control. -
Page 8: Power Source
Power Source 1. Connect one of the small plug from the supplied AC/DC Adapter to the DC IN jack of Decorative LED lights; connect the other small plug to the DC IN jack of the Main Unit as illustrated below. 2. - Page 9 4. During playback, using the controls on the paired BT Device to skip the tracks; pause; play... etc. Notes: When the external BT Device searched the unit, our model number “MD699” will appear on the display of external BT Device.
- Page 10 Listening a Record 1. For first time use, take out the protective cover from the stylus as the illustrated below: Plastic protective cover (White color) 2. Place the Record on the center spindle. Note: If you are playing a 45 RPM Single (small size record), place the supplied 45 RPM adapter to the center spindle then place the record on it.
-
Page 11: Other Connections
Other Connections LINE IN: LINE OUT: Listen music from the external Audio Player as follows: To listening from external Audio Amplifier: 1. Connect one end of the supplied Audio Connection 1. Connect one end of the RCA Audio Connection Cable Cable to the Phones Jack;... - Page 12 Records Handling Do not touch the record's grooves. Only handle records, by the edges or the label. Make sure your hands are clean. Skin oils from even clean hands can leave a residue on the record surface that will gradually deteriorate the quality of your record.
-
Page 13: Troubleshooting Guide
Troubleshooting Guide Symptom Possible Cause Solution Power AC/DC Adaptor had not Connected the AC/DC connected to unit or wall Adaptor to the unit outlet wall outlet Turn the Power No power ON-OFF/Volume knob Power ON-OFF/Volume clockwise to power on knob is on power off position the unit and set the volume to the desired level... -
Page 14: General Specifications
General Specifications Power Source: 9V, 1300mA, Audio Power: W (RMS) x 2 Impendence of Speakers: 4 Ohm; 3W x 2 BT Version: BT Effective Range: 32 feet in open area Turntable: Speed: 33; 45; 78 rpm selectable Type of Stylus: CSC-015 Accessories 1 x User’s Manual... -
Page 16: Fcc Notice
FCC NOTICE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
