Sennheiser 502061 Specification Sheet

WiCOS C
Conference Systems |
General Description
The wireless WiCOS C chairman unit is an ideal choice for mobile conference systems
where flexibility and reliability is a must. Its compact and elegant design harmo-
niously blends in with any conference room.
The high-performance battery pack offers an operating time of 20+ hours. WiCOS
C offers all the features of the standard delegate unit along with a number of extra
conference management functions. Permission to speak and request list control can
be handled easily. The MIC key allows the chairman to speak at any time.
If required, the PRIORITY key mutes all other open microphones. Two further keys
can be programmed with various additional management functions, for instance to
control the audio level. The wireless signal transmission of WiCOS is completely enc-
rypted to be safe from unauthorized listeners.
Features
interference resistant transmission in the 2,4 and 5 GHz band
j
encrypted transmission with 128 bit key
j
detachable gooseneck microphone with LED ring (to be ordered separately)
j
built-in high fidelity loudspeaker
j
two 3,5 mm headphone sockets
j
two conference management function keys
j
two programmable function keys
j
prominent MIC key with status-LED
j
20+ hours operating time via Lithium-Ion battery pack
j
Delivery Includes: WiCOS C chairman unit
j
Battery pack
Quick-Guide
Recommended Accessories
WiCOS MIC
j
Gooseneck microphone
WiCOS NT-BA
j
Battery charging adapter
WiCOS
Article No. 502883
Article No. 502885
Technical Data
Frequency response ................................. 150.....15,000 Hz
Max. Mic. Sound pressure level (aktiv) ...........133 dB SPL
Headphone connector ... 3,5 mm mono ( > 32 O < 1 kO)
Current consumption ............................................ max. 3 W
Operating time (Accupack) ..................> 20 h (WiCOS BA)
Operating temperature ...............................+5 °C ... +45 °C
Colour ........................................................................ RAL 9011
Dimensions ............................................ 230 x 130 x 60 mm
Weight incl. Accu ............................................. approx. 830g
Profile
A wireless chairman unit shall be easy to operate and set
up. It shall work safely encrypted in both, the 2,4 GHz and
5 GHz band to avoid interference from other devices. The
operating time shall cover more than 20 hours, the battery
shall be chargeable within the delegate unit or via an ex-
ternal charging device. Two 3.5mm headphone connectors
with one volume control shall be supplied. The operation
mode of the microphone shall be indicated by a LED-ring.
The chairman shall have the option keys to activate next
delegate on request to speak list and to mute all active
microphones. Further two programmable function keys
shall be provided for floor volume control, vote control and
media control options
Art.-No. 502061
