Senco DuraSpin DS200-14v Specifications

NEW!
DuraSpin, the collated screw fastening system from SENCO
is designed to maximize efficiency in a wide variety of screw-
fastening applications. Engineered for comfort and convenience,
the DS200-14v cordless screw driver drives 1" to 2" screws.
Tool Specifications:
Voltage: 14.4 volts
Battery Ampacity: 1700 mAh
RPM: 2300 rev/min
Weight: 4.9 lbs. (2.2 kg)
Height: 10 inches (254 mm)
Length: 13.8 inches (350 mm)
Width: 2.8 inches (70 mm)
Recharge Time: 1 hour
Screw Drives/Charge: see chart on reverse side
Fastener Capacity: 50 screws (one strip)
Torque Delivered: 37 in-lbs
Generated Noise: 74 dBA
Vibration: less than 2.5m/sec
DuraSpin
®
2
Cordless Screw Driver
™
Applications:
For drywallers and remodelers, DuraSpin is the ideal tool for drywall
(to wood or steel studs), floor sheathing, and underlayment.
Features and Benefits:
• 14.4 volt battery provides the optimum balance of power,
weight and run-time across the full range of screws
• 2,300 RPM high-torque motor drives screws without
bogging down
• Patented clutch design means long-lasting durability
• One-hour charger and extra battery ensures a backup battery
with a full charge
• Easy depth-of-drive adjustment regulates the precise
,
amount of countersink
• Easy bit change — from phillips to square
• Wide range of collated screws to speed production
• Belt hook — DuraSpin goes where you go
• One full year warranty
Fastener Specifications:
Screw Lengths: 1" (25 mm) to 2" (50 mm)
Screw Diameters: #6, #7, #8
Drywall
Application:
to Wood
Drive/Head:
#2 Phillips
Bugle
Thread:
Coarse
Point:
Sharp
Grey
Finish:
Phosphate
Screw:
#6 X 1
#6 X 1
#7 X 2"
Model DS200-14v
Drywall to Drywall to
Light Gauge Steel Heavy Gauge Steel
#2 Phillips #2 Phillips
Bugle Bugle
Fine Fine
Sharp Drill
Grey Clear
Phosphate Zinc
/ / /
1 " #6 X 1 1 " #6 X 1 1 "
4 4 4
/
5 "
8
Wood
to Wood
#2 Square
Flat
Coarse 2/3
with Wax
Sharp
Yellow
Zinc
/
#8 X 1 1 "
2
/
#8 X 1 3 "
4
